Evaporative Emission Control System — Hyundai Santa Fe III (2012-2016)

Description

Evaporative Emission Control System prevents fuel vapor stored in fuel tank from vaporizing into the atmosphere. When the fuel evaporates in the fuel tank, the vapor passes through vent hoses or tubes to canister filled with charcoal. The canister temporarily holds the vapor in the charcoal. If ECM determines to draw the gathered vapor into the combustion chambers during certain operating conditions, it will vacuum into intake manifold.

Scheme 141

Scheme 141: Evaporative System Monitoring

Evaporative And ORVR Emission Control System

This system consists of below items

Fill vent valve
Fuel shut-off valve
Fuel cut valve (for roll over)
Two way valve (pressure/vacuum relief)
Fuel liquid/vapor separator which is installed beside the filler pipe
Charcoal canister which is mounted under the rear floor LH side member and protector
Tubes and miscellaneous connections

While refueling, ambient air is drawn into the filler pipe so as not to emit fuel vapors in the air. The fuel vapor in the tank is then forced to flow into the canister via the fill vent valve. The fuel liquid/vapor separator isolates liquid fuel and passes the pure vapor to the charcoal canister.

While the engine is operating, the trapped vapor in the canister is drawn into the intake manifold and then into the engine combustion chamber.

According to this purge process, the charcoal canister is purged and recovers its absorbing capability.

Scheme 142

Scheme 143

Scheme 143: Schematic Diagram

Canister

Canister is filled with charcoal and absorbs evaporated vapor in fuel tank. The gathered fuel vapor in canister is drawn into the intake manifold by the ECM/PCM when appropriate conditions are set.

Purge Control Solenoid Valve (PCSV)

Purge Control Solenoid Valve (PCSV) is installed in the passage connecting canister and intake manifold. It is a duty type solenoid valve and is operated by ECM/PCM signal.

To draw the absorbed vapor into the intake manifold, the ECM/PCM will open the PCSV, otherwise the passage remains closed.

Fuel Filler Cap

A ratchet tightening device on the threaded fuel filler cap reduces the chances of incorrect installation, seals the fuel filler. After the gasket on the fuel filler cap and the fill neck flange make contact, the ratchet produces a loud clicking noise indicating the seal has been set.

Fuel Tank Pressure Sensor (FTPS)

The Fuel Tank Pressure Sensor (FTPS) is an integral part of the monitoring system. The FTPS checks Purge Control Solenoid Valve (PCSV) operation and leaks in the Evaporative Emission Control System by monitoring pressure and vacuum level in the fuel tank during PCSV operating cycles.

Canister Close Valve (CCV)

The Canister Close Valve (CCV) is located between the canister and the fuel tank air filter. It closes off the air inlet to the canister for the Evaporative Emissions System and also prevents fuel vapors from escaping from the Canister when the vehicle is not operating.

Evaporative System Monitoring

Evaporative Emission Control Monitoring System consists of fuel vapor generation, evacuation, and leakage check step. At first, the OBD-II system checks if vapor generation due to fuel temperature is small enough to start monitoring. Then it evacuates the evaporative system by means of PCSV with ramp in order to maintain a certain vacuum level. The final step is to check if there is vacuum loss by any leakage of the system.

Vapor Generation Checking

During stabilization period, the PCSV and the CCV are closed. The system pressure is measured as starting pressure (DP_A). After a certain defined period (T1), the system pressure (DP_B) is measured again and the difference from the starting pressure is calculated. If this difference (DP_B - DP_A) is bigger than a threshold, there should be excessive vapor and the monitor is aborted for next checking. On the contrary, if the difference is lower than another negative threshold, PCSV is regarded as malfunction such as clogged at open position.

Evacuation

PCSV is opened with a certain ramp for the pressure to reach down to a certain level. If pressure can't be lowered below a threshold, the system is regarded as fuel cap-opened or having a large leakage.

Leaking Checking

PCSV is closed and the system waits for a period to get stabilized pressure. During checking period (T2), the system measures the beginning and the end of the system pressure (DP_C, DP_D). The diagnosis value is the pressure difference corrected by natural vapor generation (DP_B - DP_A) rate from the vapor generation checking step.

Scheme 144

Scheme 144: Components Location

Scheme 145

Scheme 145: Removal

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Turn the ignition switch OFF and disconnect the battery negative (-) cable.
Lift the vehicle.
Disconnect the canister close valve extension connector (A).
Disconnect the vapor tube quick-connector (A) from the canister.
Disconnect the ventilation tube quick-connector (B) from the fuel tank air filter.
Remove the canister assembly (C) after removing the mounting bolts and nut.
Remove the canister protector (A) from the canister (B) after removing the installation 4 bolts.
Remove the canister close valve connector (A).
Remove the fuel tank air filter & canister close valve assembly (A) after rotating it in the direction of the arrow shown in the illustration.

Scheme 152

Scheme 152: Inspection

Check for the following items visually. Cracks or leakage of the canister Loose connection, distortion, or damage of the vapor hose/tube

Installation

Note. Install the component with the specified torques. Note that internal damage may occur when the component is dropped. If the component has been dropped, inspect before installing.

Install in the reverse order of removal. Canister protector installation bolt: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft) Canister assembly installation bolt/nut: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)

A ratchet tightening device on the threaded fuel filler cap reduces the chances of incorrect installation, which would seal the fuel filler. After the gasket on the fuel filler cap and the filler neck flange contact each other, the ratchet produces a loud clicking noise indicating the seal has been set.

Scheme 153

Scheme 153: Description

Scheme 154

Scheme 154: Removal

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Turn the ignition switch OFF and disconnect the battery negative (-) cable.
Lift the vehicle.
Disconnect the canister close valve extension connector (A).
Disconnect the vapor tube quick-connector (A) from the canister.
Disconnect the ventilation tube quick-connector (B) from the fuel tank air filter.
Remove the canister assembly (C) after removing the mounting bolts and nut.
Remove the canister protector (A) from the canister (B) after removing the installation 4 bolts.
Remove the canister close valve connector (A).
Remove the fuel tank air filter & canister close valve assembly (A) after rotating it in the direction of the arrow shown in the illustration.
Release the lever (A), and then separate the canister close valve (B) from the fuel tank air filter (C) after rotating it in the direction of the arrow shown in the illustration.
