Engine Lubrication System Hyundai Santa Fe III

Replacement

Scheme 1

Scheme 2

1. Park the car on level ground. Start the engine and let it warm up.
2. Turn the engine off and open the hood. Remove the engine cover.
3. Wait for 5 minutes after loosening the oil filter cap to drain fully the oil in the oil filter.
4. Drain engine oil. Remove the oil filler cap. After lifting the car, remove the oil drain plug and drain oil into a container.
5. Replace the oil filter. Disconnect the oil filter cap from the oil filter body. Remove the oil filter element. Check and clean the oil filter installation surface. Check the part number and shape of a new oil filter is same as old one. Install a new oil filter element (A) and a new O-ring (B). Apply clean engine oil to the new O-rings. Lightly screw the oil filter cap into place, and tighten it until the O-ring contacts the seat. Finally tighten it again by specified tightening torque. Tightening torque: 24.5 N.m (2.5 kgf.m, 18.1 lb-ft)
6. Fill new engine oil. Install the oil drain plug (A) with a new gasket. Tightening torque: 34.3 ~ 44.1N.m (3.5 ~ 4.5kgf.m, 25.3 ~ 32.5lb-ft) Fill with new engine oil, after removing the engine oil level gauge. Capacity Total: 6.5 L (6.87 U.S qt., 5.71 lmp.qt., 1.71 U.S.gal.) Oil pan: 6.0 L (6.34 U.S qt., 5.28 lmp.qt., 1.58 U.S.gal.) Drain and refill including oil filter: 5.7 L (6.02 U.S.qt., 5.01 lmp.qt., 1.50 U.S.gal.) CAUTION: Fill the crankcase to about half the capacity and then fill the remainder after waiting about one minute. Do not fill oil over the 'F' line, checking the level with the oil level gauge frequently to ensure no over filling. Install the oil filler cap and oil level gauge.
7. Start the engine and check to be sure no oil is leaking from the drain plug or oil filter.
8. Recheck the engine oil level.

Inspection

1. Check the engine oil quality. Check the oil deterioration, addition of water or coolant, discoloring or thinning. If the quality is visibly poor, replace the oil.
2. Check the engine oil level. After warming up the engine and then 5 minutes after the engine stop, oil level should be between the "L" and "F" marks in the dipstick. If low, check for leakage and add oil up to the "F" mark. NOTE: Do not fill with engine oil above the "F" mark.

Selection Of Engine Oil

Recommendation

1. 5W-30/ACEA A5 (If not available, refer to the recommended API, ILSAC or ACEA and SAE classification).

API classification: SM or above

ILSAC classification: GF4 or above

ACEA classification: A5 or above

SAE viscosity grade: Refer to the recommended SAE viscosity number

* If not available, API SL, ILSAC GF3, ACEA A3 can be used.

Scheme 3

Note. For best performance and maximum protection of all types of operation, select only those lubricants which: Satisfy the requirement of the API or ILSAC classification. Have proper SAE grade number for expected ambient temperature range. Lubricants that do not have both an SAE grade number and API or ILSAC service classification on the container should not be used.

Scheme 4

Scheme 5

Scheme 6

1. Disconnect the battery "-" terminal.
2. Remove the engine under cover.
3. Drain engine oil. Refer to «ENGINE OIL»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
4. Remove the water center pipe. Refer to «WATER TEMPERATURE CONTROL ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/cooling-system-mechanical/#engine-cooling-system) .
5. Wait for 5 minutes after loosening the oil filter cap to drain well the oil in the oil filter.
6. Remove the oil filter body (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) NOTE: All rubber gaskets must not be damaged by assembling parts. Do not reuse oil filter body O-ring.
7. Install in the reverse order of removal.
8. Start engine and check for oil leaks.
9. Recheck the engine oil level.

Scheme 7

1. Disconnect the battery "-" terminal.
2. Replace the oil filter. Disconnect the oil filter cap from the oil filter body. Remove the oil filter element. Check and clean the oil filter installation surface. Check the part number and shape of a new oil filter is same as old one. Install a new oil filter element (A) and a new O-ring (B). Apply clean engine oil to the new O-rings. Lightly screw the oil filter cap into place, and tighten it until the O-ring contacts the seat. Finally tighten it again by specified tightening torque. Tightening torque: 24.5 N.m (2.5 kgf.m, 18.1 lb-ft)
3. Fill new engine oil. Refer to «ENGINE OIL»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
4. Install in the reverse order of removal.
5. Start engine and check for oil leaks.
6. Recheck the engine oil level.

Scheme 8

Scheme 9

1. Disconnect the battery "-" terminal.
2. Remove the engine under cover.
3. Drain the engine oil. Refer to «ENGINE OIL»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
4. Remove the lower oil pan (A). NOTE: Insert the blade of SST(09215-3C000) between the upper oil pan and lower oil pan. Cut off applied sealer and remove the lower oil pan. Insert the SST between the oil pan and the ladder frame by tapping it with a plastic hammer in the direction of arrow. After tapping the SST with a plastic hammer along the direction of arrow around more than 2/3 edge of the oil pan, remove it from the ladder frame. Do not use the SST as a prybar. Hold the tool in position (on the gasket line) and tap in with a light hammer. Be careful not to damage the contact surfaces of Upper oil pan and lower oil pan.

Scheme 10

1. Remove the engine assembly from the vehicle. Refer to «ENGINE AND TRANSMISSION ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/mechanical/#engine-and-transmission-assembly) .
2. Attach the engine to engine stand for disassembly.
3. Remove the timing chain. Refer to «TIMING CHAIN»(/hyundai/santa-fe/iii-2012-2016/remont/mechanical/#timing-system) .
4. Remove the lower oil pan. Refer to «OIL PAN»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
5. Remove the oil pump. Refer to «OIL PUMP»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
6. Remove the oil level gauge. Refer to «OIL LEVEL GAUGE & PIPE»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
7. Remove the air conditioning compressor. Refer to «COMPRESSOR»(/hyundai/santa-fe/iii-2012-2016/remont/automatic-hvac-system/#air-conditioning-system) .
8. Remove the LH/RH exhaust manifold stays. Refer to «EXHAUST MANIFOLD»(/hyundai/santa-fe/iii-2012-2016/remont/exhaust/#intake-and-exhaust-system) .
9. Remove the upper oil pan (A). NOTE: Insert the blade of SST(09215-3C000) between the upper oil pan and lower oil pan. Cut off applied sealer and remove the lower oil pan.

Scheme 11

Scheme 12

1. Install the lower oil pan (A). Using a gasket scraper, remove all the old packing material from the gasket surfaces. Before assembling the oil pan, the liquid sealant THREE BOND 1217H should be applied on oil pan. The part must be assembled within 5 minutes after the sealant was applied. Bead width : 2.5 mm (0.1 in.) CAUTION: Clean the sealing face before assembling two parts. Remove harmful foreign matters on the sealing face before applying sealant. When applying sealant gasket, sealant must not protrude into the inside of oil pan. To prevent leakage of oil, apply sealant gasket to the inner threads of the bolt holes. After assembly, wait at least 30 minutes before filling the engine with oil. Install the oil pan (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
2. After assembly, wait at least 30 minutes before filling the engine with oil. Refer to «ENGINE OIL»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
3. Install all other parts in reverse order of removal.

Scheme 13

Scheme 14

1. Install the upper oil pan. Using a gasket scraper, remove all the old gasket material from the gasket surfaces. Before assembling the oil pan, the liquid sealant THREE BOND 1217H should be applied on upper oil pan. The part must be assembled within 5 minutes after the sealant was applied. Bead width : 2.5 mm (0.1 in.) NOTE: Clean the sealing face before assembling two parts. Remove harmful foreign materials on the sealing face before applying sealant When applying sealant gasket, sealant must not protrude into the inside of oil pan. To prevent leakage of oil, apply sealant gasket to the inner threads of the bolt holes. After assembly, wait at least 30 minutes before filling the engine with oil. Install the upper oil pan. Uniformly tighten the bolts in several passes. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
2. Install all other parts in reverse order of removal.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Remove the lower oil pan. Refer to «OIL PAN»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
2. Remove the oil pump chain cover (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
3. Remove the bolt (A) and then separate the chain with sprocket from the oil pump. Tightening torque: 18.6 ~ 21.6 N.m (1.9 ~ 2.2 kgf.m, 13.7 ~ 15.9 lb-ft)
4. Remove the oil pump (A). Tightening torque: 20.6 ~ 22.6 N.m (2.1 ~ 2.3 kgf.m, 15.2 ~ 16.6 lb-ft) NOTE: When installing, use a new O-ring (B).
5. After assembly, wait at least 30 minutes before filling the engine with oil. Refer to «ENGINE OIL»(/hyundai/santa-fe/iii-2012-2016/remont/lubrication-system/#engine-lubrication-system) .
6. Install in the reverse order of removal.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. Remove the intake manifold. Refer to «INTAKE MANIFOLD»(/hyundai/santa-fe/iii-2012-2016/remont/exhaust/#intake-and-exhaust-system) .
2. If necessary, remove the RH knock sensor. Refer to «KNOCK SENSOR (KS)»(/hyundai/santa-fe/iii-2012-2016/remont/testing-diagnostics/#engine-control-system) .
3. Remove the oil pressure switch (A). Tightening torque: 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.5 lb-ft) NOTE: To remove and install the oil pressure switch, use a deep socket (A) and a universal joint (B).
4. Install in the reverse order of removal. NOTE: When installing the oil pressure switch, apply seal lock to the thread. Seal lock : THREE BOND 2403 Thickness : 0.2 ~ 0.4 mm (0.008 ~ 0.016 in)

Scheme 23

Scheme 24

1. Check the continuity between the terminal and the body with an ohmmeter. If there is no continuity, replace the oil pressure switch.
2. Check the continuity between the terminal and the body when the fine wire is pushed. If there is continuity even when the fine wire is pushed, replace the switch.
3. If there is no continuity when a 19.6 ~ 39.2 kpa (2.8 ~ 5.7psi) is applied through the oil hole the switch is operating properly. Check for air leakage. If air leaks, the diaphragm is broken. Replace it.

Scheme 25

Scheme 26

1. Disconnect the battery "-" terminal.
2. Remove the engine oil level gauge (A) and oil level gauge rod (B). Tightening torque: 18.6 ~ 22.6 N.m (1.9 ~ 2.3 kgf.m, 13.7 ~ 16.6 lb-ft) NOTE: When installing, apply engine oil to the O-ring and take care the O-ring not to be damaged. Always use a new O-ring.
3. Install in the reverse order of removal.
