Ignition Switch Assembly Hyundai Santa Fe III

Scheme 15

Scheme 16

1. Disconnect the ignition switch connector (B) and key warning switch connector (A) from under the steering column.
2. Check for continuity between the terminals.
3. If continuity is not specified, replace the switch.

Scheme 17

Scheme 18

Scheme 19

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel. (Refer to " «CRASH PAD LOWER PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) ")
3. Remove the steering column upper and lower shrouds. (Refer to " «STEERING COLUMN SHROUD PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) ")
4. Remove the ignition switch (A) after disconnecting the 6P connector (B).
5. Remove the key warning and immobilizer connector (A).
6. If it is necessary to remove the key lock cylinder (A), remove the key lock cylinder with key ACC.

Scheme 20

Installation

1. Install the key lock cylinder.
2. Install the key warning and immobilizer connector.
3. Install the ignition switch.
4. Install the steering column shrouds and crash pad lower panel.
