Engine Electrical System - General Information — Hyundai Santa Fe III (2012-2016)

Ignition System

Item	Specification
Primary Coil Resistance (ohms)	0.62 ± 10% [20°C (68°F)]
Secondary Coil Resistance (kohms)	7.0 ± 15% [20°C (68°F)]

IGNITION COIL SPECIFICATION

Item	Specification
Type	SILZKR7B11
Gap	1.0 ~ 1.1 mm (0.0394 ~ 0.0433 in.)

SPARK PLUG SPECIFICATION

Item	Specification
Capacitance (uF)	0.47 [1KHz]
Insulation resistance (Mohms)	1, 000 [DC 500 V/1 Min]

CONDENSER SPECIFICATION

Item	Specification
Rated voltage	13.5V, 150A
Speed in use	1, 500 ~ 18, 000rpm
Voltage regulator	IC Regulator built in type
Default regulated voltage (V) [COM terminal]	14.0 ~ 15.5 (-35°C)
	14.0 ~ 15.0 (25°C)
	13.1 ~ 15.0 (140°C)
Regulated Voltage (V) [COM terminal]	11.6 ~ 15.4

ALTERNATOR SPECIFICATION

BATTERY SPECIFICATION

Information

Model type description
Cold Cranking Ampere (CCA): Cold Cranking Amps is a rating used in the battery industry to define a battery's ability to start an engine in cold temperatures. The rating is the number of amps a new, fully charged battery can deliver at -18 °C (-0.4 °F) for 30 seconds, while maintaining a voltage of at least 7.2 volts for a 12 volt battery. The higher the CCA rating, the greater the starting power of the battery.
RESERVE CAPACITY (RC): Reserve Capacity is a battery industry rating, defining a battery's ability to power a vehicle with an inoperative alternator or fan belt. The rating is the number of minutes a battery at 26.7 °C (80 °F) can be discharged at 25 amps and maintain a voltage of 10.5 volts for a 12 volt battery. The higher the reserve rating, the longer your vehicle can operate should your alternator or fan belt fail.

STARTER SPECIFICATION

Item	N.m	Kgf.m
Ignition coil installation bolt	9.8 ~ 11.8	1.0 ~ 1.2
Spark plug installation	14.7 ~ 24.5	1.5 ~ 2.5
Condenser & Hanger bracket installation bolt	6.9 ~ 10.8	0.7 ~ 1.1
Alternator installation bolt	26.5 ~ 33.3	2.7 ~ 3.4
Battery (+) terminal tightening nut	7.8 ~ 9.8	0.8 ~ 1.0
Battery (-) terminal l tightening nut	3.9 ~ 5.9	0.4 ~ 0.6
Battery mounting bracket installation bolt	8.8 ~ 13.7	0.9 ~1.4
Battery tray installation bolt	8.8 ~ 13.7	0.9 ~1.4
Battery sensor cable installation bolt	10.0 ~ 12.0	1.0 ~ 1.2
Starter installation bolt	49.0 ~ 63.7	5.0 ~ 6.5
Starter cover installation bolt	8.8 ~ 13.7	0.9 ~ 1.4

Symptom	Suspect Area	Remedy
Engine will not start or is hard to start (Cranks OK)	Ignition lock switch	Inspect ignition lock switch, or replace as required
	Ignition coil	Inspect ignition coil, or replace as required
	Spark plugs	Inspect spark plugs, or replace as required
	Ignition wiring disconnected or broken	Repair wiring, or replace as required
Rough idle or stalls	Ignition wiring	Repair wiring, or replace as required
Rough idle or stalls	Ignition coil	Inspect ignition coil, or replace as required
Engine hesitates/poor acceleration	Spark plugs and spark plug cables	Inspect spark plugs/cable, or replace as required
Engine hesitates/poor acceleration	Ignition wiring	Repair wiring, or replace as required
Poor mileage	Spark plugs and spark plug cables	Inspect spark plugs/cable, or replace as required

Symptom	Suspect Area	Remedy
Charging warning indicator does not light with ignition switch "ON" and engine off.	Fuse blown	Check fuses
	Light burned out	Replace light
	Wiring connection loose	Tighten loose connection
	Electronic voltage regulator	If light turns off, replace voltage regulator.
Charging warning indicator does not go out with engine running. (Battery requires frequent recharging)	Drive belt loose or worn	Adjust belt tension or replace belt
	Battery cable loose, corroded or worn	Inspect cable connection, repair or replace cable
	Electronic voltage regulator or alternator	If light turns off, replace voltage regulator or alternator
	Wiring	Repair or replace wiring
Overcharge	Electronic voltage regulator	If light turns off, replace voltage regulator.
Overcharge	Voltage sensing wire	Repair or replace wiring
Discharge	Drive belt loose or worn	Adjust belt tension or replace belt
	Wiring connection loose or short circuit	Inspect wiring connection, repair or replace wiring
	Electronic voltage regulator or alternator	If light turns off, replace voltage regulator or alternator
	Poor grounding	Inspect ground or repair
	Worn battery	Replace battery

Symptom	Suspect Area	Remedy
Engine will not crank	Battery charge low	Charge or replace battery
	Battery cables loose, corroded or worn out	Repair or replace cables
	Transaxle range switch (Vehicle with automatic transaxle only)	Refer to AUTOMATIC TRANSAXLE
	Fuse blown	Replace fuse
	Starter motor faulty	Replace
	Ignition switch faulty	Replace
Engine cranks slowly	Battery charge low	Charge or replace battery
	Battery cables loose, corroded or worn out	Repair or replace cables
	Starter motor faulty	Replace
Starter keeps running	Starter motor faulty	Replace
Starter keeps running	Ignition switch	Replace
Starter spins but engine will not crank	Short in wiring	Repair or replace wiring
	Pinion gear teeth broken or starter motor	Replace
	Ring gear teeth broken	Replace flywheel or torque converter
