General Information - Engine Mechanical - g2.4 DOHC — Engine — Mechanical — Hyundai Santa Fe II рестайлинг (2010-2012)

Specifications

Description			Specifications	Limit
General
Type			In-line, Double Overhead Camshaft
Number of cylinder			4
Bore			88mm (3.464in)
Stroke			97mm (3.819in)
Total displacement			2359cc (143.90cu.in)
Compression ratio			10.5 : 1
Firing order			1-3-4-2
Valve timing
Intake valve
Opens (ATDC/BTDC)			ATDC 7° ~ BTDC 38°
Closes (ABDC)			ABDC 67° ~ 22°
Exhaust
Opens (BBDC)			BBDC 44° ~ 4°
Closes (ATDC)			ATDC 0° ~ 40°
Valve
Valve length
Intake			113.18mm (4.4559in.)	112.93mm (4.4460in)
Exhaust			105.84mm (4.1669in.)	105.59mm (4.1571in)
Stem O.D.
Intake			5.465 ~ 5.480mm (0.2151 ~ 0.2157in.)
Exhaust			5.458 ~ 5.470mm (0.2149 ~ 0.2153in.)
Face angle			45.25° ~ 45.75°
Margin
Intake			1.02mm (0.0401in.)
Exhaust			1.09mm (0.0429in.)
Valve stem to valve guide clearance
Intake			0.020 ~ 0.047mm (0.00078 ~ 0.00185in.)	0.07mm (0.00275in.)
Exhaust			0.030 ~ 0.054mm (0.00118 ~ 0.00212in.)	0.09mm (0.00354in.)
Valve guide
Length
Intake			43.8 ~ 44.2mm (1.7244 ~ 1.7401in.)
Exhaust			43.8 ~ 44.2mm (1.7244 ~ 1.7401in.)
Valve guide I.D			5.500 ~ 5.512mm (0.2165 ~ 0.2170in.)
Valve seat
Width of seat contact
Intake			1.16 ~ 1.46mm (0.0457 ~ 0.0575in.)
Exhaust			1.35 ~ 1.65mm (0.0531 ~ 0.0649in.)
Seat angle			44.75° ~ 45.10°
Valve spring
Free length			47.44mm (1.8677in.)
Load			19.0 ± 0.6kg/35.0mm (41.88 ± 1.32lb/1.3779in
Load			39.8 ± 1.2kg/26.0mm (87.74 ± 2.64lb/1.0236in.)
Squareness			1.5° MAX.
Valve clearance
Cold (20°C[68°F])
Intake			0.17 ~ 0.23mm (0.0067 ~ 0.0090in.)	0.10 ~ 0.30mm (0.0039 ~ 0.0118in.)
Exhaust			0.27 ~ 0.33mm (0.0106 ~ 0.0129in,)	0.20 ~ 0.40mm (0.0078 ~ 0.0157in.)
Cylinder head
Flatness of gasket surface			Max. 0.05mm (0.0019in.)
Flatness of manifold mounting surface			Max. 0.10mm (0.0039in.)
Cylinder block
Cylinder bore			88.00 ~ 88.03mm (3.4645 ~ 3.4657in.)
Out-of-round and taper of cylinder bore			Less than 0.05mm (0.0019in.)
Clearance with piston (To set limits to new parts)			0.015 ~ 0.035mm (0.0005 ~ 0.0013in.)
Piston
O.D (To set limits to new parts)			87.975 ~ 88.005mm (3.4635 ~ 3.4647in.)
Ring groove width
No. 1			1.235 ~ 1.250mm (0.0486 ~ 0.0492in.)	1.26mm (0.0496in.)
No. 2			1.230 ~ 1.250mm (0.0484 ~ 0.0492in.)	1.26mm (0.0496in.)
Oil ring			2.01 ~ 2.03mm (0.0791 ~ 0.0799in.)	2.05mm (0.0807in.)
Piston ring
Side clearance
No. 1			0.05 ~ 0.08mm (0.0019 ~ 0.0031in.)	0.1mm (0.004in.)
No. 2			0.04 ~ 0.08mm (0.0015 ~ 0.0031in.)	0.1mm (0.004in.)
Oil ring			0.06 ~ 0.15mm (0.0023 ~ 0.0059in.)	0.2mm (0.008in.)
End gap
No. 1			0.15 ~ 0.30mm (0.0059 ~ 0.0118in.)	0.6mm (0.0236in.)
No. 2			0.37 ~ 0.52mm (0.0145 ~ 0.0204in.)	0.7mm (0.0275in.)
Oil ring side rail			0.20 ~ 0.70mm (0.0078 ~ 0.0275in.)	0.8mm (0.0315in.)
Connecting rod
Bend			0.05mm (0.0020in.) or less
Twist			0.1mm (0.004in.) or less
Connecting rod big end to crankshaft side clearance			0.100 ~ 0.250mm (0.0039 ~ 0.010in.)	0.35mm (0.0138in.)
Connecting rod bearing
Oil clearance (To seat limits to new parts)			0.031 ~ 0.045mm (0.0012 ~ 0.0017in.)	0.05mm (0.0078in.)
Camshaft
Cam height	Intake		44.2mm (1.7401in.)
Cam height	Exhaust		45.0mm (1.7716in.)
Journal O.D	Intake	No. 1	Ø 30mm (1.1811in.)
	Intake	No. 2, 3, 4, 5	Ø 24mm (0.9449in.)
	Exhaust	No. 1	Ø 36mm (1.4173in.)
	Exhaust	No. 2, 3, 4, 5	Ø 24mm (0.9449in.)
Bearing oil clearance	Intake	No. 1	0.022 ~ 0.057mm (0.0008 ~ 0.0022in.)	0.09mm (0.0035in.)
	Intake	No. 2, 3, 4, 5	0.045 ~ 0.082mm (0.0017 ~ 0.0032in.)	0.12mm (0.0047in.)
	Exhaust	No. 1	0 ~0.032mm (0 ~ 0.0012in.)	0.12mm (0.0047in.)
	Exhaust	No. 2, 3, 4, 5	0.045 ~ 0.082mm (0.0017 ~ 0.0032in.)
End play			0.04 ~ 0.16mm (0.0015 ~ 0.0062in.)	0.20mm (0.0078in.)
Crankshaft
Pin O.D.			47.954 ~ 47.972mm (1.8879 ~ 1.8886in.)
Journal O.D.			51.942 ~ 51.960mm (2.0449 ~ 2.0456in.)
End play			0.07 ~ 0.25mm (0.0027 ~ 0.0098in.)
Crankshaft bearing
Oil clearance			0.020 ~ 0.038mm (0.0007 ~ 0.0014in.)	0.1mm (0.0039in.)
Radiator
Type			Pressurized corrugated fin type
Cooling method			Water-cooled, pressurized. Forced circulation with water pump
Coolant quantity			6.8 L (7.2 US qt, 5.9 lmp qt)
Radiator cap
Main valve opening pressure			83 ~ 110kpa (12 ~ 16psi, 0.83 ~ 1.1kg/cm 2 )
Vacuum valve opening pressure			7kpa (-100psi, -0.07kg/cm 2 ) or less
Thermostat
Type			Wax pellet type with jiggle valve
Valve opening temperature			82°C (177°F)
Full-opening temperature			95°C (201°F)
Coolant pump			Centrifugal type impeller
Engine oil
Oil quantity	Total		5.5 L (5.8 US qt, 4.8 lmp qt)	When replacing a short engine or block assembly
	Oil pan		4.2 L (4.4 US qt, 3.7 lmp qt)
	Drain and refill		4.6 L (4.9 US qt, 4.0 lmp qt)	Including oil filter
Oil grade	Recommendation		5W-20/GF4&SM	If not available, refer to the recommended API or ILSAC classification and SAE viscosity number.
	Classification		API SL, SM or above ILSAC GF3, GF4 or above	Satisfy the requirement of the API or ILSAC classification.
	SAE viscosity grade		Recommended SAE viscosity number	Refer to the LUBRICATION SYSTEM .
Oil pressure (at 1, 000rpm)			147.10kPa (1.5kgf/cm 2 , 21.33psi) or above	Oil temperature (oil pan): 110±2°C (230±35.6°F)

SPECIFICATIONS

Tightening Torques

Item	N.m	Kgf.m
Ladder frame bolt	(8.8~9.8) + (17.7~20.6) + (27.5~31.4)	(0.9~1.0) + (1.8~2.1) + (2.8~3.2)
Timing chain cover bolt (M8)	18.6 ~ 22.5	1.9 ~ 2.3
Timing chain cover bolt (M6)	7.8 ~ 9.8	0.8 ~ 1.0
Oil pan bolt (M6 x 10)	9.8 ~ 11.8	1.0 ~ 1.2
Oil pan bolt (M9 x 55)	30.4 ~ 34.3	3.1 ~ 3.5
Engine support bracket bolt (M8 x 30)	19.6 ~ 24.5	2.0 ~ 2.5
Engine support bracket bolt (M10 x 40)	39.2 ~ 44.1	4.0 ~ 4.5
Engine support bracket bolt (M10 x 45)	39.2 ~ 44.1	4.0 ~ 4.5
Camshaft bearing cap bolt (M6)	(5.9) + (10.8~12.7)	(0.6) + (1.1~1.3)
Camshaft bearing cap bolt (M8)	(14.7) + (27.4~31.4)	(1.5) + (2.8~3.2)
Cylinder head bolt	(32.4~36.3) + (90~95°) + (90~95°)	(3.3~3.7) + (90~95°) + (90~95°)
Engine hanger bolt	27.5 ~ 31.4	2.8 ~ 3.2
Cylinder head cover bolt	(3.9~5.9) + (7.8~9.8)	(0.4~0.6) + (0.8~1.0)
Crankshaft pulley bolt	166.6 ~ 176.4	17.0 ~ 18.0
Connecting rod bearing cap bolt	(17.7~21.6) + (88~92°)	(1.8~2.2) + (88~92°)
Main bearing cap bolt	14.7 + (27.5~31.4) + (120~125°)	1.5 + (2.8~3.2) + (120~125°)
Flywheel bolt	117.6 ~ 127.4	12.0 ~ 13.0
Drive plate bolt	117.6 ~ 127.4	12.0 ~ 13.0
Timing chain tensioner bolt	9.8 ~ 11.8	1.0 ~ 1.2
Timing chain tensioner arm bolt	9.8 ~ 11.8	1.0 ~ 1.2
Timing chain guide bolt	9.8 ~ 11.8	1.0 ~ 1.2
OCV bolt	9.8 ~ 11.8	1.0 ~ 1.2
CVVT bolt	53.9 ~ 63.7	5.5 ~ 6.5
BSM chain tensioner arm bolt	9.8 ~ 11.8	1.0 ~ 1.2
BSM chain guide bolt	9.8 ~ 11.8	1.0 ~ 1.2
BSM chain tensioner bolt	9.8 ~ 11.8	1.0 ~ 1.2
Water pump bolt	18.6 ~ 23.5	1.9 ~ 2.4
A/C compressor bracket bolt	19.6 ~ 23.5	2.0 ~ 2.4
P/S pump bracket bolt	44.1 ~ 53.9	4.5 ~ 5.5
Tensioner assembly integrated bracket bolt	39.2 ~ 44.1	4.0 ~ 4.5
Water temperature control assembly nut	18.6 ~ 23.5	1.9 ~ 2.4
Balance shaft module bolt	(22.6~26.5) + (103~107°)	(2.3~2.7) + (103~107°)
Water temperature control assembly bolt	14.7 ~ 19.6	1.5 ~ 2.0
Water inlet pipe bolt	9.8 ~ 11.8	1.0 ~ 1.2
Oil level gauge assembly bolt	7.8 ~ 11.8	0.8 ~ 1.2
Ignition coil bolt	3.9 ~ 5.9	0.4 ~ 0.6
Intake manifold bolt	18.6 ~ 23.5	1.9 ~ 2.4
Intake manifold nut	18.6 ~ 23.5	1.9 ~ 2.4
Intake manifold stay bolt	18.6 ~ 23.5	1.9 ~ 2.4
Exhaust manifold heat protector bolt	7.8 ~ 11.8	0.8 ~ 1.2
Exhaust manifold nut	49.0 ~ 53.9	5.0 ~ 5.5
Exhaust manifold stay bolt (M8)	18.6 ~ 27.5	1.9 ~ 2.8
Exhaust manifold stay bolt (M10)	51.9 ~ 57.8	5.3 ~ 5.9
Muffler nut	39.2 ~ 58.8	4.0 ~ 6.0
Engine cover mounting bracket bolt	9.8 ~ 11.8	1.0 ~ 1.2
Crankshaft position sensor bolt	9.8 ~ 11.8	1.0 ~ 1.2
Oxygen sensor	39.2 ~ 49.0	4.0 ~ 5.0
Knock sensor	18.6 ~ 23.5	1.9 ~ 2.4
Camshaft position sensor	3.9 ~ 5.9	0.4 ~ 0.6
Oil pressure switch	7.8 ~ 11.8	0.8 ~ 1.2
Oil filter	11.8 ~ 15.7	1.2 ~ 1.6
Oil cooler fix bolt	44.1 ~ 53.9	4.5 ~ 5.5
Oil cooler hose & pipe bolt	18.6 ~ 23.5	1.9 ~ 2.4

TIGHTENING TORQUE SPECIFICATIONS

Compression Pressure Inspection

Note. If the there is lack of power, excessive oil consumption or poor fuel economy, measure the compression pressure.

Scheme 1

Scheme 1: Compression Pressure Inspection

Warm up and stop engine. Allow the engine to warm up to normal operating temperature.
Disconnect the injector connectors and ignition coil connectors.
Remove ignition coils.
Remove spark plugs. Using a 16mm plug wrench, remove the 4 spark plugs.
Check cylinder compression pressure. Insert a compression gauge into the spark plug hole. Fully open the throttle. While cranking the engine, measure the compression pressure. NOTE: Always use a fully charged battery to obtain engine speed of 200 rpm or more. Repeat steps ( A ) through ( C ) for each cylinder. NOTE: This measurement must be done in as short a time as possible. Compression pressure : 1, 283kPa (13.0kgf/cm 2 , 185psi) Minimum pressure : 1, 135kPa (11.5kgf/cm 2 , 164psi) Difference between each cylinder : 100kPa (1.0kgf/cm 2 , 15psi) or less If the cylinder compression in 1 or more cylinders is low, pour a small amount of engine oil into the cylinder through the spark plug hole and repeat steps ( A ) through ( C ) for cylinders with low compression. If adding oil helps the compression, it is likely that the piston rings and/or cylinder bore are worn or damaged. If pressure stays low, a valve may be sticking or seating is improper, or there may be leakage past the gasket.
Reinstall spark plugs.
Install ignition coils.
Connect the injector connectors and ignition coil connectors.

Valve Clearance Inspection And Adjustment

Note. Inspect and adjust the valve clearance when the engine is cold (Engine coolant temperature : 20°C (68°F)) and cylinder head is installed on the cylinder block.

Scheme 2

Scheme 2: Valve Clearance Inspection And Adjustment

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Remove the cylinder head cover (A). (Refer to «TIMING SYSTEM»(/hyundai/santa-fe/ii-2010-2012/remont/mechanical/#timing-system-g24-dohc) .)
Set No. 1 cylinder to TDC/compression. Turn the crankshaft pulley and align its groove with the timing mark "T" of the lower timing chain cover. Check that the mark (A) of the CVVT sprockets are in straight line on the cylinder head surface as shown in the illustration. If not, turn the crankshaft one revolution (360°)
Inspect the valve clearance. Check only the valve indicated as shown in the illustration. [No. 1 cylinder : TDC/Compression] measure the valve clearance. Using a thickness gauge, measure the clearance between the tappet and the base circle of camshaft. Record the out-of-specification valve clearance measurements. They will be used later to determine the required replacement adjusting tappet. Valve clearance Specification Engine coolant temperature : 20°C [68°F] Limit Intake : 0.10 ~ 0.30mm (0.0039 ~ 0.0118in.) Exhaust : 0.20 ~ 0.40mm (0.0079 ~ 0.0157in.) Turn the crankshaft pulley one revolution (360°) and align the groove with timing mark "T" of the lower timing chain cover. Check only valves indicated as shown in the illustration. [NO. 4 cylinder : TDC/compression]. Measure the valve clearance.
Adjust the intake and exhaust valve clearance. Set the No. 1 cylinder to the TDC/compression. Marks on the timing chain and camshaft timing sprockets. Remove the service hole bolt (A) of the timing chain cover. CAUTION: The bolt must not be reused once it has been assembled. Insert the SST (A) (09240-2G000) in the service hole of the timing chain cover and release the ratchet. Remove the front camshaft bearing cap (A). Remove the exhaust camshaft bearing cap and exhaust camshaft. Remove the intake camshaft bearing cap and intake camshaft. CAUTION: When disconnecting the timing chain from the CVVT sprocket, tie or hold the timing chain so it does not fall into the timing chain cover. Tie down timing chain so that it doesn't move. CAUTION: Be careful not to drop anything inside timing chain cover. Measure the thickness of the removed tappet using a micrometer. Calculate the thickness of a new tappet so that the valve clearance comes within the specified value. Valve clearance (Engine coolant temperature : 20°C (68°F)) T : Thickness of removed tappet A : Measured valve clearance N : Thickness of new tappet Intake : N = T + [A - 0.20mm (0.0079in.)] Exhaust : N = T + [A-0.30mm (0.0118in.)] Select a new tappet with a thickness as close as possible to the calculated value. NOTE: Shims are available in 41 size increments of 0.015mm (0.0006in.) from 3.00mm (0.118in.) to 3.690mm (0.1452in.) Place a new tappet on the cylinder head. Hold the timing chain, and install the intake camshaft and CVVT assembly. Align the matchmarks on the timing chain and CVVT sprocket. Install the exhaust camshaft and CVVT assembly. Install the front bearing cap. Tightening torque : 14.7N.m (1.5kgf.m, 10.8lb-ft) + 27.4 ~ 31.4N.m (2.8 ~ 3.2kgf.m, 20.3 ~ 23.1lb-ft) Install the service hole bolt. Tightening torque : 11.8 ~ 14.7N.m (1.2 ~ 1.5kgf.m, 8.7 ~ 10.8lb-ft) Turn the crankshaft two turns in the operating direction (clockwise) and realign crankshaft sprocket and camshaft sprocket timing marks (A). Recheck the valve clearance. Valve clearance (Engine coolant temperature : 20°C (68°F)) [Specification] Intake : 0.17 ~ 0.23mm (0.0067 ~ 0.0090in.) Exhaust : 0.27 ~ 0.33mm (0.0106 ~ 0.0129in.)

Troubleshooting

Symptom	Suspect area	Remedy
Engine misfire with abnormal internal lower engine noises.	Worn crankshaft bearings Loose or improperly engine flywheel	Replace the crankshaft and bearings as required. Repair or replace the flywheel as required.
	Worn piston rings (Oil consumption may or may not cause the engine to misfire.)	Inspect the cylinder for a loss of compression. Repair or replace as required.
	Worn crankshaft thrust bearings	Replace the crankshaft and bearings as required
Engine misfire with abnormal valve train noise.	Stuck valves. (Carbon build up on the valve stem)	Repair or replace as required
	Excessive worn or mis-aligned timing chain	Replace the timing chain and sprocket as required.
	Worn camshaft lobes.	Replace the camshaft and valve lifters.
Engine misfire with coolant consumption	Faulty cylinder head gasket or other damage to the cylinder head and engine block cooling system. Coolant consumption may or may not cause the engine to overheat.	Inspect the cylinder head and engine block for damage to the coolant passages and/or a faulty head gasket. Repair or replace as required.
Engine misfire with excessive oil consumption	Worn valves, guides and/or valve stem oil seals.	Repair or replace as required.
Engine misfire with excessive oil consumption	Worn piston rings. (Oil consumption may or may not cause the engine to misfire)	Inspect the cylinder for a loss of compression. Repair or replace as required.
Engine noise on start-up, but only lasting a few seconds.	Incorrect oil viscosity	Drain the oil. Install the correct viscosity oil.
Engine noise on start-up, but only lasting a few seconds.	Worn crankshaft thrust bearing.	Inspect the thrust bearing and crankshaft. Repair or replace as required.
Upper engine noise, regardless of engine speed.	Low oil pressure	Repair or replace as required.
	Broken valve spring.	Replace the valve spring.
	Worn or dirty valve lifters.	Replace the valve lifters.
	Stretched or broken timing chain and/or damaged sprocket teeth.	Replace the timing chain and sprockets.
	Worn timing chain tensioner, if applicable.	Replace the timing chain tensioner as required.
	Worn camshaft lobes.	Inspect the camshaft lobes. Replace the timing camshaft and valve lifters as required.
	Worn valve guides or valve stems.	Inspect the valves and valve guides, then repair or replace as required.
	Stuck valves. (Carbon on the valve stem or valve seat may cause the valve to stay open.	Inspect the valves and valve guides, then repair or replace as required.
	Worn drive belt, idler, tensioner and bearing.	Replace as required
Lower engine noise, regardless of engine speed	Low oil pressure	Repair or required.
	Loose or damaged flywheel.	Repair or replace the flywheel.
	Damaged oil pan, contacting the oil pump screen.	Inspect the oil pan. Inspect the oil pump screen. Repair or replace as required.
	Oil pump screen loose, damaged or restricted.	Inspect the oil pump screen. Repair or replace as required.
	Excessive piston-to-cylinder bore clearance.	Inspect the piston, piston pin and cylinder bore. Repair or replace as required.
	Excessive piston pin-to-piston clearance	Inspect the piston, piston pin and the connecting rod. Repair or replace as required.
	Excessive connecting rod bearing clearance	Inspect the following components and repair or replace as required. The connecting rod bearings. The connecting rods. The crankshaft pin journals.
	Excessive crankshaft bearing clearance	Inspect the following components, and repair or replace as required. The crankshaft bearings. The crankshaft main journals. The cylinder block
	Incorrect piston, piston pin and connecting rod installation	Verify the piston pins and connecting rods are installed correctly. Repair as required.
Engine noise under load	Low oil pressure	Repair or replace as required.
	Excessive connecting rod bearing clearance	Inspect the following components and repair or replace as required: The connecting rod bearings. The connecting rods. The crankshaft
	Excessive crankshaft bearing clearance	Inspect the following components, and repair or replace as required. The crankshaft bearings. The crankshaft main journals. The cylinder block.
Engine will not crank-crankshaft will not rotate	Hydraulically locked cylinder Coolant/antifreeze in cylinder. Oil in cylinder. Fuel in cylinder	Remove spark plugs and check for fluid. Inspect for broken head gasket. Inspect for cracked engine block or cylinder head. Inspect for a sticking fuel injector and/or leaking fuel regulator.
	Broken timing chain and/or timing chain and/or timing chain gears.	Inspect timing chain and gears. Repair as required.
	Material in cylinder Broken valve Piston material Foreign material	Inspect cylinder for damaged components and/or foreign materials. Repair or replace as required.
	Seized crankshaft or connecting rod bearings.	Inspect crankshaft and connecting rod bearing. Repair as required.
	Bent or broken connecting rod.	Inspect connecting rods. Repair as required.
	Broken crankshaft	Inspect crankshaft. Repair as required.

TROUBLESHOOTING

Special Service Tools

SPECIAL SERVICE TOOLS Tool (Number and name) Illustration Use Crankshaft front oil seal installer (09214-3K000) (09231-H1100) Installation of the front oil seal 09214-3K000 09231-H1100 Flywheel stopper (09231-3K000) Holds flywheel so that engine doesn't turn/move. Torque angle adapter (09221-4A000) Installation of bolts & nuts needing an angular method of adjustment. Valve stem oil seal installer (09222-4A000) Installation of the valve stem oil seal Valve spring compressor & holder (09222-3K000) (09222-3K100) Removal and installation of the intake or exhaust valve 09222-3K100 (holder) Crankshaft rear oil seal installer (09214-3K100) (09231-H1100) Installation of the crankshaft rear oil seal 09214-3K100 09231-H1100 Timing chain tensioner ratchet holder (09240-2G000) Timing chain tension release In vehicle inspection and adjustment of valve clearance. Oil pan remover (09215-3C000) Removal of oil pan Oxygen sensor socket wrench (09392-2H100) Removal and installation of oxygen sensor
