Cooling System - g2.4 DOHC Hyundai Santa Fe II рестайлинг

Replacement And Air Bleeding

1. Make sure the engine and radiator are cool to the touch.
2. Remove radiator cap.
3. Loosen the drain plug, and drain the coolant.
4. Tighten the radiator drain plug securely.
5. After draining engine coolant in the reservoir tank, clean the tank.
6. Fill the radiator with water through the radiator cap and tighten the cap. NOTE: To most effectively bleed the air, pour the water slowly and press on the upper/lower radiator hoses.
7. Start the engine and allow to come to normal operating temperature. Wait for the cooling fans to turn on several times. Accelerate the engine to aid in purging trapped air. Shut engine off.
8. Wait until the engine is cool.
9. Repeat steps 1 to 8 until the drained water runs clear.
10. Fill fluid mixture with coolant and water (5 : 5) (Tropical region - 4:6) slowly through the radiator cap. Push the upper/lower hoses of the radiator so as bleed air easily. NOTE: Use only genuine antifreeze/coolant. For best corrosion protection, the coolant concentration must be maintained year-round at 35% minimum. Coolant concentrations less than 35% may not provide sufficient protection against corrosion or freezing. Coolant concentrations greater then 60% will impair cooling efficiency and are not recommended. CAUTION: Do not mix different brands of antifreeze/coolants. Do not use additional rust inhibitors or antirust products; they may not be compatible with the coolant.
11. Start the engine and run until coolant circulates. When the cooling fan operates and coolant circulates, refill coolant through the radiator cap.
12. Repeat 11 until the cooling fan 3 ~ 5 times and bleed air sufficiently out of the cooling system.
13. Install the radiator cap and fill the reservoir tank to the "MAX" line with coolant.
14. Run the vehicle under idle until the cooling fan operates 2 ~ 3 times.
15. Stop the engine and wait coolant gets cool.
16. Repeat 10 to 15 until the coolant level doesn't fall any more, bleed air out of the cooling system. NOTE: It takes time to bleed out all the air in the cooling system. Refill coolant when coolant gets cool completely, when recheck the coolant level in the reservoir tank for 2~3 days after replacing coolant. Coolant capacity : 6.8 L (7.2US qt, 5.9lmp qt)

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Disconnect the battery negative terminal.
2. Remove the air cleaner assembly.
3. Remove the battery and battery tray.
4. Remove the under cover.
5. Loosen the drain plug (A), and drain the coolant. Remove the radiator cap to speed draining.
6. Remove the radiator upper hose (A), lower hose (B) and then disconnect the fan motor connector (C).
7. Disconnect the ATF cooler hoses (A/T only). (Refer to «AUTOMATIC TRANSAXLE SYSTEM - (A6MF2) - 2.4L»(/hyundai/santa-fe/ii-2010-2012/remont/automatic-trans/#automatic-transaxle-system-a6mf2-g24-dohc) .)
8. Remove the front bumper. (Refer to «FRONT BUMPER»(/hyundai/santa-fe/ii-2010-2012/remont/exterior-body-panels/#front-rear-bumpers) .)
9. Disconnect the over flow hose (A) from the radiator.
10. Remove the upper cover (A) and ATF cooler (B).
11. Remove the guide (C) and radiator mounting bracket (D). Tightening torque: 8.8 ~ 10.8 N.m (0.9 ~ 1.1 kgf.m, 6.5 ~ 7.9 lb-ft)
12. Remove the A/C high pressure pipe bracket mounting bracket (A). Tightening torque : 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
13. Separate the condenser from the radiator and then remove the upper cover (A) and cooling fan assembly (B). Tightening torque: 8.8 ~ 10.8 N.m (0.9 ~ 1.1 kgf.m, 6.5 ~ 7.9 lb-ft)
14. Pull radiator upper from engine room.
15. Installation is in the reverse order of removal.
16. Fill the radiator with coolant and check for leaks. NOTE: Bleed air from the cooling system. Start engine and let it run until it warms up. (Until the radiator fan operates 3 or 4 times.) Turn off engine. Check the coolant level and add coolant if needed. This will allow trapped air to be removed from the cooling system. Put the radiator cap on tightly, then run engine again and check for leaks.

Scheme 8

1. Remove the radiator cap, wet its seal with engine coolant, and then install it on a pressure tester.
2. Apply a pressure of 93.16 ~ 122.58kpa (0.95 ~ 1.25kg/cm 2 , 13.51 ~ 17.78psi).
3. Check for a drop in pressure.
4. If the pressure drops, replace the cap.

Scheme 9

1. Wait until engine is cool, then carefully remove the radiator cap and fill the radiator with engine coolant, then install it on the pressure tester.
2. Apply a pressure tester to the radiator and apply a pressure of 93.16 ~ 122.58kpa (0.95 ~ 1.25kg/cm 2 , 13.51 ~ 17.78psi).
3. Inspect for engine coolant leaks and a drop in pressure.
4. Remove the tester and reinstall the radiator cap. NOTE: Check for engine oil in the coolant and/or coolant in the engine oil.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Loosen the drain plug (A), and then drain the engine coolant. CAUTION: Never remove the radiator cap when the engine is hot. Serious scalding could be caused by hot fluid under high pressure escaping from the radiator.
2. Remove the drive belt (A).
3. Remove the water inlet pipe bolt. Tightening torque : 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
4. Remove the water pump (A) and the water pump gasket. Tightening torque : 18.6 ~ 23.5N.m (1.9 ~ 2.4kgf.m, 13.7 ~ 17.4lb-ft)
5. Installation is reverse order of removal with a new water pump gasket.

Inspection

1. Check each part for cracks, damage or wear, and replace the coolant pump assembly if necessary.
2. Check the bearing for damage, abnormal noise and sluggish rotation, and replace the coolant pump assembly if necessary.
3. Check for coolant leakage. If coolant leaks from hole, the seal is defective. Replace the coolant pump assembly. NOTE: A small amount of "weeping" from the bleed hole is normal.

Troubleshooting

Water Pump

WATER PUMP TROUBLESHOOTING CHART

Removal

Note. Removal of the thermostat would have an adverse effect, causing a lowering of cooling efficiency. Do not remove the thermostat, even if the engine tends to overheat.

Scheme 14

Scheme 15

1. Drain engine coolant so its level is below thermostat.
2. Remove the radiator lower hose (A).
3. Remove water inlet fitting (A), gasket (B) and thermostat (C). Tightening torque : 7.8 ~ 11.8N.m (0.8 ~ 1.2kgf.m, 5.8 ~ 8.7lb-ft)
4. Installation is reverse order of removal. NOTE: Install the thermostat with the jiggle valve upward.
5. Fill the engine coolant.
6. Start the engine and check for leaks.
7. Recheck the coolant level.

Scheme 16

1. Immerse the thermostat in water and gradually heat the water.
2. Check the valve opening temperature. Valve opening temperature: 82°C (177°F) Full opening temperature: 95°C (205°F) If the valve opening temperature is not as specified, replace the thermostat.
3. Check the valve lift. Valve lift : 8mm (0.3in.) or more at 95°C (205°F) If the valve lift is not as specified, replace the thermostat.

THERMOSTAT TROUBLESHOOTING CHART
