SPECIFICATIONS
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 30°C ~ + 80°C (-22 ~ + 176°F) | |
| Rated load | Dimmer & passing switch | High : 1A (Relay load) Low : 1A (Relay load) Passing : 1A (Relay load) |
| Lighting switch | Lighting : 1A (Relay load) | |
| Turn signal switch | 6.6 ± 0.5A (Lamp load) | |
| Wiper & mist switch | Low, High : 4A (Motor load) Intermittent : 0.22 ± 0.05A (Relay load) Lock : Max. 23A (Motor load) Mist : 4A (Motor load) | |
| Washer switch | 4A (Motor load) | |
| Variable intermittent volume switch | Max. 25mA | |
| Rear wiper & washer switch | Rear wiper: 200mA (Relay load) Rear washer : 4A (Motor load) | |
MULTI FUNCTION SWITCH SPECIFICATIONS
Scheme 73
Scheme 74
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch
Scheme 75
Scheme 76
Scheme 77
HU : Head lamp high beam
HL : Head lamp low beam
P : Head lamp passing switch
Scheme 78
Scheme 79
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch (A) by pushing the lock pin (B) after disconnecting the connector (C).
- Remove the wiper switch (A) by pushing the lock pin (B) after disconnecting the connector (C).
- Installation is the reverse of removal.
