PROBLEM VERIFICATION Hyundai Santa Fe II

Esc (electronic Stability Control) System 1 illustration

PROBLEM VERIFICATION

Disconnect the connector from the ESC control module and turn the ignition switch ON.

Does the ABS warning lamp light up?

YES

  1. It is normal. Recheck the ESC control module.

NO

  1. Check the power source for the ABS warning lamp.

Scheme 29

Scheme 29: CHECK THE POWER SOURCE FOR THE ABS WARNING LAMP
Scheme 29: CHECK THE POWER SOURCE FOR THE ABS WARNING LAMP
  1. Disconnect the instrument cluster connector and turn the ignition switch ON.
  2. Measure the voltage between terminal 2 of the cluster harness side connector (M15-A) and body ground. Specification: approximately B+ Is voltage within specification? YES Repair bulb or instrument cluster assembly. NO Check for blown fuse.
