REMOVAL Hyundai Santa Fe II

REMOVAL

Note. Mark wires or hoses for identification.

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

1. Remove the engine cover, (see «CHARGING SYSTEM (ENGINE ELECTRICAL SYSTEM (G6EA-GSL 2.7))»(/hyundai/santa-fe/ii-2005-2010/remont/charging-system/#charging-system-engine-electrical-system-g6ea-gsl-27) )
2. Remove the battery (A).
3. Disconnect the AFS connector (A).
4. Remove the air cleaner assembly (B) by loosening the clamp bolt (C) and the clips and removing the two mounting bolts (D).
5. Remove the battery tray (B) by removing the four mounting bolts (A-4ea).
6. Remove the ECM (A).
7. Remove the inhibitor switch connector (A).
8. Remove the solenoid valve connector (A).
9. Remove the input speed sensor connector (A).
10. Remove the output speed sensor connector (A).
11. Remove the vehicle speed sensor connector (A).
12. Remove the control cable assembly (C) by removing the nut (A) and clip (B).
13. Disconnect the transaxle oil cooler hoses (B) from the tubes by loosening the clamps (A).
14. Remove the CKP sensor connector (A).
15. Remove the transaxle mounting bolts (A-3ea).
16. Using the special tool (09200-38001), hold the engine and transaxle assembly safely.
17. Remove the transaxle insulator mounting bolts (A-4ea).
18. Remove the front wheels, (see «FRONT SUSPENSION SYSTEM»(/hyundai/santa-fe/ii-2005-2010/remont/suspension-front/#front-suspension-system) )
19. Lift up the vehicle.
20. Remove the power steering column joint bolt and the EPS connector, (see «GENERAL (STEERING SYSTEM)»(/hyundai/santa-fe/ii-2005-2010/remont/electronic-steering/#general-steering-system) )
21. Remove the under cover (A).
22. Drain the transaxle fluid by removing the oil drain plug (A).
23. Drain power steering fluid through the return tube (A). (see «GENERAL (STEERING SYSTEM)»(/hyundai/santa-fe/ii-2005-2010/remont/electronic-steering/#general-steering-system) )
24. Disconnect the power steering pressure tube (A) from the power steering oil pump.
25. Disconnect the lower arm, the tie rod end ball joint, the stabilizer bar link from the front knuckle, (see «FRONT SUSPENSION SYSTEM»(/hyundai/santa-fe/ii-2005-2010/remont/suspension-front/#front-suspension-system) )
26. Remove the roll stopper mounting bolts (A-3ea, B-3ea).
27. Remove the muffler hanger rubber (A).
28. Remove the mounting bolts from the sub frame by supporting the sub frame by using the special tool (09624-38000). (see «FRONT SUSPENSION SYSTEM»(/hyundai/santa-fe/ii-2005-2010/remont/suspension-front/#front-suspension-system) )
29. Remove the front roll support (A) from the transaxle.
30. Remove the front muffler assembly (A).
31. Remove the inner shaft bracket bolts (A-3ea).
32. Remove drive shaft (A, B) from transaxle. (see «DRIVESHAFT»(/hyundai/santa-fe/ii-2005-2010/remont/driveshaft-universal-joints/#driveshaft) ).
33. Install a jack for supporting the transaxle assembly.
34. In case of 4WD, remove the transfer case assembly, (see «MANUAL TRANSAXLE (M5GF2)»(/hyundai/santa-fe/ii-2005-2010/remont/manual-trans/#manual-transaxle-system-m5gf2) ' «TRANSFER CASE»(/hyundai/santa-fe/ii-2005-2010/remont/manual-trans/#manual-transaxle-system-m5gf2) ')
35. Remove the left side cover (A).
36. Remove the ground (A).
37. Remove the starter motor mounting bolts (A) and the two bolts (B).
38. Remove the cover (A).
39. Remove the drive plate bolts (A) and the transaxle lower mounting bolts (B-6ea).
40. Lifting the vehicle up and lowering the jack slowly, remove the transaxle assembly.
