Windshield Deicer: Overview Hyundai Genesis I рестайлинг

Scheme 28

Description

Windshield deicer system prevent windshield wiper from freezing in the winter season. It consists of deicer in the lower part of windshield, switch and relay. Body control module receives an input signal from the deicer switch, then controls relay. Operating condition is the same that of rear window defogger system.

Since the generator "L" is switched ON, if the deicer switch is ON, then deicer output is ON for 20 minutes.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Remove the cowl top cover (A).
2. Disconnect the windshield deicer connector (A) from the wiper motor linkage.
3. Check for continuity between the terminals of deicer lines.
4. Turn the ignition switch ON and the windshield deicer switch ON, then measure the voltage between the terminals of harness side deicer connector. OK: approx. Battery voltage

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel (Refer to the «CRASH PAD»(ref-590392-S04150349602013121700000) )
3. Remove the cluster fascia panel.
4. Remove the crash pad side garnish (A) after removing the screws.
5. Remove the center fascia panel (A) after removing the screws.
6. Remove the connectors (A).
7. Remove the screws and heater control unit keyboard (A).
