Power Windows: Other Hyundai Genesis I рестайлинг

Function Of Safety Power Window

When driver door power window auto-up switch is operated, safety function is activated.

Scheme 2

Scheme 3

Scheme 4

1. Safety function condition When detect the force of 100N (using the 10N/mm spring) during the window rising, window is reversed.
2. Length of window reversing (except holding the auto-up switch) When detect the jamming during the 4mm ~ 250mm(0.15 ~ 9.84 in) from top of the door. --> Window is reversed until 300mm(11.81 in) from top of the door. When detect the jamming over the 250mm(9.84 in) from top of the door. --> Window is reversed until 50mm(1.96 in) from jamming position.
3. Length of window reversing (holding the auto-up switch) When detect the jamming during holding the auto-up switch. --> Window is reverse until 25mm(0.98 in) from jamming position. Auto-up function is not available during the 5 seconds from above condition. --> When holding the auto-up switch, window is operated as a manual-up function. (Safety function is not activated.) When holding the auto-up switch after 5 seconds from above condition. --> Window is reverse until 25mm(0.98 in) from jamming position.
4. Safety function is not available area Safety function is not available during the 4mm(0.15 in) from top of the door.

Initializing Method Of The Safety Power Window

1. Initializing of Battery Connection When the battery is not connected after disconnecting the battery, safety power window switch need the initializing. Power window operation before initializing Manual-Up/Safety function is available Auto-Up function is not available (When holding the auto-up/down switch, window is operated as a manual-up/down.) Initializing method Close the window in window open position, and holding the switch in window full close position over the 0.2 second. (If start the closing the window in window full close position, initializing could be failed.) If initialize the safety power window in jamming status, could occur below conditions. Safety function is not available Position control To detect the window position and direction of motor rotation, hall sensors are employed. ECU recognizes the fully closed position of the window and sets this relative window position value as "0". When the window goes downwards, based on the information from the hall sensor, the relative position value increments. On the contrary, when the window goes upwards, it decrements. NOTE: Motor position is only valid if the system stays in normalized state. (see initialization force limitation). Recall and storing the normalization information ECU records the normalization information into the specified location in Flash ROM. (as long as Flash ROM valid) Storing conditions: 1 second after the motor stops Recall conditions: Engine = on OR Power On Reset Switch signal filtering Debouncing time: 14ms T1, t2 and t3: Measured with signal that debouncing is done. In case T1 > 6ms, motor shall operate. In case T2 > 22ms, motor might operate in manual mode. When Auto up switch input is active, auto up mode is active till 300ms. After this and until switch is released, panic mode is enable. In the end when the switch is released, auto up mode is enabled again. The conditions for terminating the motor control by the (Semi) Auto Up/Down or Manual Up/Down: Out of the operation voltage range OR Thermal protection ON OR Anti-pinch function OR De-normalization OR Engine = OFF OR Other key input occurs
2. Thermal protection Software provides an algorithm in order to prevent the motor from thermal overheating under the specified conditions like the valid Flash ROM Data. After power on reset, the software thermal counter starts to count from the initial value. In case of motor running, software increases the thermal counter by using the motor heating characteristic, otherwise the thermal counter decreases by using the motor cooling characteristic. There exist 2 thermal protection limits. If the software thermal counter is over the first limit, the motor movement stops until the software thermal counter decrease to the release limit temperature value, but still allows the current movement to finish. If the software thermal counter is over the second limit (while motor running), the movement stops at once until the release temperature value is reached (reversing will not be interrupted by software thermal protection). The motor is able to continue to operate at least "15" cycles without a break under the above conditions and after thermal protection is activated, the motor turns to the operational condition within "35±5" seconds. Test starts with SW-thermal counter at the initial value. Cycle: Full closed --> 1sec. rest --> Full opened --> 1sec. rest

Scheme 5

Scheme 6

1. Remove (-) negative battery terminal.
2. Remove the front door trim. (Refer to the «FRONT DOOR»(ref-590394-S42377900762013121700000) )
3. Disconnect the motor connector from the motor.
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 7

Scheme 8

1. Remove (-) negative battery terminal.
2. Remove the rear door trim. (Refer to the «REAR DOOR»(ref-590394-S35155738422013121700000) )
3. Disconnect the motor connector from the motor.
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. When checking the driver power window switch, select a vehicle type and "BODY CONTROL MODULE" menu.
2. Select "DRIVER DOOR MODULE (DDM)".
3. Select option "Input/Output monitoring".
4. To check the input value of power window switch in force mode, select option "ACTUATION TEST".

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. When checking the assist power window switch, select a vehicle type and "BODY CONTROL MODULE" menu.
2. Select "ASSIST DOOR MODULE(ADM)".
3. Select option "Input/Output monitoring".
4. To check the input value of power window switch in force mode, select option "ACTUATION TEST".
