Button Engine Start System: Removal & Installation Hyundai Genesis I рестайлинг

Starter 20 illustrations ~288 words

Installation

  1. Install the connector.
  2. Install the start/stop button.
  3. Install the crash pad lower panel.

Scheme 69

Scheme 69: Component

Scheme 70

Scheme 70: Removal

Scheme 71

Scheme 71

Scheme 72

Scheme 72
  1. Disconnect the negative(-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
  3. Remove the connector (A).
  4. Remove the Fob holder assembly (A) after loosening the mounting screw.
  1. Install the fob holder assembly.
  2. Install the crash pad lower panel.

Scheme 73

Scheme 73: Component

Scheme 74

Scheme 74: Removal

Scheme 75

Scheme 75

Scheme 76

Scheme 76
  1. Disconnect the negative(-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
  3. Disconnect the electronic steering column lock connector (A).
  4. Remove the electronic steering column lock (A). (Refer to Steering system - " «STEERING COLUMN AND SHAFT»(ref-590388-S21780134252013121700000) ")
  1. Install the electronic steering column lock.
  2. Install the crash pad lower panel.

Scheme 77

Scheme 77: Component

Scheme 78

Scheme 78: System circuit diagram

Scheme 79

Scheme 79: Removal

Scheme 80

Scheme 80

Scheme 81

Scheme 81
  1. Disconnect the negative(-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
  3. Remove the reinforcing panel (A).
  4. Remove the power distribution module (A) after loosening a bolt and nut.
  1. Install the power distribution module.
  2. Install the crash pad lower panel.

Scheme 82

Scheme 82: PDM Diagnosis With Scan Tool

Scheme 83

Scheme 83

Scheme 84

Scheme 84

Scheme 85

Scheme 85

Scheme 86

Scheme 86

Scheme 87

Scheme 87

Scheme 88

Scheme 88
  1. It will be able to diagnose defects of Smart key with scan tool quickly. Scan tool can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "Body control module" menu if you want to check PDM.
  3. Select "PDM" in the menu.
  4. Select Input/output monitoring", if you want to check current data of PDM. It provides the input/output status of each module.
  5. If you want to check PDM data operation forcefully, select "Actuation test".
NODescriptionUnit
1Load Battery VoltageV
2Abs Speed Sensor (main)Km/h
3Start Stop Button SWOFF/ON
4ACC inputOFF/ON
5IGN1 InputOFF/ON
6IGN2 InputOFF/ON
7Fob In SwitchRELEASE/INSERT
8Start Relay Monitoring Input
9SSB Ember LED OutputOFF/ON
10SSB Blue LED OutputOFF/ON
11Fob Holder Illumination OutputOFF/ON
12SSB Illumination OutputOFF/ON
13ACC Relay OutputOFF/ON
14IGN1 Relay OutputOFF/ON
15IGN2 Relay OutputOFF/ON
16Start Relay S1 OutputOFF/ON
17ESCL Battery OutputOFF/ON
18ESCL GND OutputOFF/ON
19CPU Battery VoltageV
20Engine SpeedDATA*1.0
21ACC Relay SCBOFF/ON
22IGN1 Relay SCBOFF/ON
23IGN2 Relay SCBOFF/ON
24Start Relay SCBOFF/ON
25SCC Relay OpenOFF/ON
26IGN1 Relay OpenOFF/ON
27IGN2 Relay OpenOFF/ON
28ACC Output SCBOFF/ON
29IGN1 Output SCBOFF/ON
30IGN2 Output SCBOFF/ON
31Start Output SCBOFF/ON
32ACC Output SCGOFF/ON
33IGN1 Output SCGOFF/ON
34IGN2 Output SCGOFF/ON
35Start Output SCGOFF/ON

INPUT/OUTPUT CURRENT DATA

No.Description
1SSB Ember LED
2SSB Blue LED
3Fob Holder Illumination
4SSB Illumination
5ACC Output
6ING1 Output
7ING2 Output
8Start Output
9Perform ESCL Open Check

ACTUATION TEST
