Adaptive Front Lighting System: Diagnosis Hyundai Genesis I рестайлинг

Inspection

Initialization and diagnosis sequence by using diagnostic equipment

Below content summarize the procedure for A/S using Diagnostic equipment

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Select "AFLS" menu after selecting "GENESIS" of vehicle lists.
2. Select "Parameter download" menu for define a characteristic of vehicle.
3. Select "Air suspension not apply" if vehicle has a standard suspension
4. Select "Air suspension apply" if vehicle has a Air suspension
5. When "Parameter download" is done, display belows.

Actuator test

When it replace H/Lamp Unit, it necessarily check up by operating actuator test.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Select "AFLS" menu after selecting "GENESIS" of car lists.
2. Select "Actuator test"
3. Select DBL or HLL test by using UP/DOWN key
4. In case select BOTH DBL ACTUATOR DRIVE TO MAX POS (swivelling) In case select F1 key: drive to max position CCW direction (15°) In case select F2 key: back to initial position
5. In case select BOTH DBL ACTUATOR DRIVE TO MAX POS (Leveling) In case select F1 key: drive to max position upper side In case select F2 key: back to initial position
