Ims (Integrated Memory System): Removal & Installation Hyundai Genesis I

Installation

1. Reassemble the IMS module after connecting the connectors.
2. Reassemble the seats in the car.

1. Connect the connectors and reassemble the power seat control switch.
2. Reassemble the recliner cover and seat front cover.

Scheme 38

1. Remove the seat control switch.
2. With the power seat control switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the power seat control switch.

Power seat connector switch A

Scheme 39

Driver lumbar connector B

Scheme 40

Assist seat connector switch C

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel (A). (Refer to «FRONT DOOR»(ref-345940-S05482049952009102300000) )
3. Remove the door trim garnish (A) after removing the screws inside the door trim.
4. After removing the mounting screws (3EA) and switch connector, then remove the IMS control switch.

1. Connect the connectors and reassemble the IMS control switch.
2. Install the door trim garnish and door trim.
3. Connect the negative (-) battery terminal.

Scheme 47

Scheme 48

1. Remove the IMS control switch.
2. With the power IMS control switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the IMS control switch.
