Scheme 1
Scheme 2
To identify fuse location refer to component location (Scheme 2)
Note. * Use designated fuses only.
| DESCRIPTION | AMPERAGE | CIRCUIT PROTECTED | |
|---|---|---|---|
| FUSIBLE LINKS | WIPER | 30A | Electronic Control Wiper Module |
| FAM POWER-1 | 40A | FAM | |
| FAM POWER-2 | 40A | FAM | |
| START | 30A | Start Relay | |
| ECU | 30A | Engine Control Relay | |
| BLOWER MOTOR | 40A | Blower Relay | |
| IGN SW-1 | 40A | Ignition Switch (IG 2, START) | |
| HTD GLASS (RR) | 40A | Heated Glass (RR) Relay | |
| IGN SW-2 | 40A | Ignition Switch (IG 1, ACC) | |
| FUSES | A/CON | 10A | A/C Control Module |
| EPB-1 | 15A | Electronic Parking Brake Control | |
| EPB-2 | 15A | Electronic Parking Brake Control | |
| HORN | 15A | Horn Relay | |
| IPM | 10A | IPM | |
| AQS | 10A | AQS Sensor Blower Relay Electronic Control Wiper Module Head Lamp (Low) Relay | |
| HTD GLASS (FR) | 15A | Heated Glass (FR) Relay | |
| WASHER | 15A | Washer Relay | |
| MIRROR HTD | 10A | A/C Control Module Power Outside Mirror & Mirror Folding Motor LH/RH | |
| TCU | 15A | TCM | |
| AFLS | 10A | Head Lamp LH/RH | |
| EHPS | 10A | EHPS Module | |
| EPS | 10A | EPS Control Module Multipurose Check Connector | |
| ECU-2 | 10A | ECM | |
| IGN COIL-1 | 15A | Ignition Coil No. 2, 4, 6 | |
| IGN COIL-2 | 15A | Ignition Coil No. 1, 3, 5 Condenser | |
| ENG SNSR-1 | 10A | ECM MAF Sensor Oxygen Sensor No. 1, 2, 3, 4 | |
| ENG SNSR-2 | 10A | Canister Purge Control Solenoid Valve Cooling Fan Relay ECM Immobilizer Module Oil Control Valve Variable Intake Manifold Valve | |
| ENG SNSR-3 | 15A | ECM Fuel Pump Relay Injectors 1, -6 | |
| H/LP (LO) RH | 15A | Head Lamp RH | |
| H/LP (LO) LH | 15A | ECM Head Lamp LH | |
| INHIBITOR SW | 10A | Transaxle Range Switch | |
| CRUISE | 10A | Smart Cruise Control Module | |
| STOP LAMP | 10A | Generator Stop Lamp Relay Stop Lamp Switch | |
| ECU-1 | 10A | ECM TCM | |
| ROOM LAMP | 10A | Room Lamp Relay | |
| F/PUMP | 20A | Fuel Pump Relay | |
IDENTIFYING FUSIBLE LINKS & FUSES (ENGINE ROOM JUNCTION BOX & FAM)
Scheme 3
To identify fuse location refer to component location (Scheme 3)
Note. * Use designated fuses only.
| FUSE TYPE | No. | FUSE | (A) | CIRCUIT PROTECTED |
|---|---|---|---|---|
| FUSIBLE LINKS | 1 | ALT | 200A | Generator |
| 2 | I/P LH PWR | 60A | I/P Junction Box LH | |
| 3 | I/P RH PWR | 60A | I/P Junction Box RH | |
| 4 | COOLING | 60A | Cooling Fan Relay | |
| 5 | EHPS | 80A | EHPS Module | |
| 6 | AIR ECS | 40A | ESC Compressor Relay | |
| 7 | AMP-1 | 40A | AV JBL AMP | |
| 8 | AMP-2 | 30A | AMP | |
| 9 | ESCL (ACC) | 30A | ESCL (ACC) Relay | |
| 10 | ABS-1 | 30A | ECS Control Module Multipurose Check Connector | |
| 11 | ABS-2 | 30A | ECS Control Module Multipurose Check Connector | |
| 12 | ESCL (IGN1) | 30A | ESCL (IGN 1) Relay | |
| 13 | ESCL (IGN2) | 30A | ESCL (IGN 2) Relay | |
| 14 | P/SEAT FL | 30A | Driver Lumbar Support Switch Driver Power seat Relay Box IMS Control Module | |
| FUSES | 15 | H/LP WASHER | 20A | Head Lamp Washer Relay |
| 16 | B/UP | 10A | ||
| 17 | ACC SOCKET | 25A | ACC Socket Relay | |
| 18 | T/LID | 10A | Trunk Lid Relay | |
| 19 | DRL | 15A | ||
| 20 | STOP LP | 10A | IPM Stop Lamp Relay Stop Lamp Switch | |
| 21 | B/UP | 10A | Camera Module Electro-Chromic Mirror Rear Combination Lamp LH/RH (IN) Rear Curtain Module |
IDENTIFYING FUSIBLE LINKS & FUSES (ENGINE ROOM - FUSE & RELAY BOX)
Description
The PDM, which installed beside the audio head unit, is united with IG1, IG2, ACC and Sub start relay. This module receive signal from IPM and control relay (ACC/IG1/IG2/ST).
