Fuses & Relays: Other Hyundai Genesis I

Fuses & Circuit Breakers 11 illustrations ~482 words

Power Relay (Type A)

Check for continuity between the terminals.

Scheme 8

Scheme 8: Power Relay (Type A)
Scheme 8: Power Relay (Type A)

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. There should be continuity between the No.30 and No.87 terminals when power and ground are connected to the No.85 and No.86 terminals.
  2. There should be no continuity between the No.30 and No.87 terminals when power is disconnected. Stop lamp relay Trunk lid relay ACC socket relay Washer relay Heated glass relay (front) Horn relay Fuel pump relay Room lamp relay

Power Relay (Type C)

Check for continuity between the terminals.

Scheme 12

Scheme 12: Power Relay (Type C)
Scheme 12: Power Relay (Type C)

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. There should be continuity between the No.30 and No.87 terminals when power and ground are connected to the No.85 and No.86 terminals.
  2. There should be continuity between the No.30 and No.87 terminals when power is disconnected. ESCL (ACC) relay ESC compressor relay Cooling fan relay ESCL (IG2) relay ESCL (IG1) relay Blower relay Heated glass relay (rear) Start relay Head lamp (low) relay

Power Relay (Type D)

Check for continuity between the terminals.

Scheme 16

Scheme 16: Power Relay (Type D)
Scheme 16: Power Relay (Type D)

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. There should be continuity between the No.30 and No.87 terminals when power and ground are connected to the No.85 and No.86 terminals.
  2. There should be no continuity between the No.30 and No.87 terminals when power is disconnected. Engine control relay

IG 1 Relay

Check for continuity between the terminals.

  1. There should be continuity between the No.4 in the connector A and No. 12 in the connector B terminals when power and ground are connected to the No.2 in the connector A and No. 14 in the connector B.
  2. There should be no continuity between the No.4 in the connector A and No. 12 in the connector B terminals when power is disconnected.

IG 2 Relay

Check for continuity between the terminals.

  1. There should be continuity between the No.1 in the connector A and No.10 in the connector B terminals when power and ground are connected to the No.7 in the connector A and No. 13 in the connector B.
  2. There should be no continuity between the No.1 in the connector A and No.10 in the connector B terminals when power is disconnected.

ACC Relay

Check for continuity between the terminals.

  1. There should be continuity between the No.3 in the connector A and No.9 in the connector B terminals when power and ground are connected to the No.7 and No.8 in the connector B.
  2. There should be no continuity between the No.3 in the connector A and No.9 in the connector B terminals when power is disconnected.

Sub Start Relay

Check for continuity between the terminals.

  1. There should be continuity between the No.2 and No.3 in the connector B terminals when power and ground are connected to the No.4 and No.5 in the connector B.
  2. There should be no continuity between the No.2 and No.3 in the connector B terminals when power is disconnected.
