Engine Cooling System: Removal & Installation Hyundai Equus II

Removal

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Disconnect the negative terminal (A) from the battery. Tightening torque: 4.0~6.0N.m (0.4~0.6kgf.m, 3.0~4.4lb-ft)
2. Remove the engine room cover (A), engine cover (B) and radiator grill upper cover (C).
3. Loosen the drain plug (A) and drain the engine coolant. Remove the radiator cap (B) to speed draining. WARNING: Never remove the radiator cap when the engine is hot. Serious scalding could be caused by hot fluid under high pressure escaping from the radiator.
4. Remove the air cleaner assembly. Remove the air duct (A). Disconnect the air flow sensor (AFS) connector (C). Disconnect the breather hose (B). Remove the resonator (F), the intake air hose (E) and air cleaner assembly (D). Tightening torque Hose clamp bolt: 2.9 ~ 4.9N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft)
5. Disconnect the radiator upper hose (A) and lower hose (B).
6. Disconnect the ATF cooler hoses (A).
7. Disconnect the fan motor connector (A). If necessary, loosen the fuse box fixing bolt for your convenience.
8. Remove the radiator mounting brackets (A).
9. Remove the radiator & condenser mounting bolts (B). Tightening torque: 7.8 ~ 11.8N.m (0.8 ~ 1.2kgf.m, 5.8 ~ 8.7lb-ft)
10. Remove the radiator & cooling fan assembly from the vehicle.
11. Installation is reverse order of removal. Fill the radiator with coolant and check for leaks.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Disconnect the negative terminal (A) from the battery.
2. Remove the engine room cover (A), engine cover (B) and radiator grill upper cover (C).
3. Loosen the drain plug (A) and drain the engine coolant. Remove the radiator cap (B) to speed draining. WARNING: Never remove the radiator cap when the engine is hot. Serious scalding could be caused by hot fluid under high pressure escaping from the radiator.
4. Remove the air cleaner assembly. Remove the air duct (A). Disconnect the air flow sensor (AFS) connector (C). Disconnect the breather hose (B). Remove the resonator (F), the intake air hose (E) and air cleaner assembly (D).
5. Disconnect the radiator upper hose (A) and lower hose (B).
6. Turn the tensioner (B) clockwise and loosen, then remove the drive belt (A).
7. Remove the water pump pulley (A).
8. Remove the water pump (A).

Scheme 20

Scheme 21

1. Remove the intake manifold module. (Refer to «INTAKE AND EXHAUST SYSTEM»(ref-417717) in this group)
2. Remove the water outlet pipe (A) and the water inlet pipe (B). NOTE: Remove the drain plug (A) and drain the engine coolant.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Install the water pump (A). Tightening torque: 19.6 ~ 24.5N.m (2.0 ~ 2.5kgf.m, 14.5 ~ 18.1lb-ft)
2. Install the water pump pulley (A). Tightening torque: 18.6 ~ 23.5Nm (1.9 ~ 2.4kgf.m, 13.7 ~ 17.4lb-ft) NOTE: Tighten each bolt gradually in a criss-cross pattern until the final tightening torque has been reached.
3. Turn the tensioner (B) clockwise and loosen, then install the drive belt (A).
4. Connect the radiator upper hose (A) and lower hose (B).
5. Install the air cleaner assembly. Install the resonator (F), the intake air hose (E) and air cleaner assembly (D). Reconnect the breather hose (B). Reconnect the air flow sensor (AFS) connector (C). Install the air duct (A). Tightening torque Hose clamp bolt: 2.9 ~ 4.9N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft)
6. Install the engine room cover (A), the engine cover (B) and the radiator grill upper cover (C).
7. Connect the battery negative terminal (A). Tightening torque: 4.0~6.0N.m (0.4~0.6kgf.m, 3.0~4.4lb-ft)
8. Fill the radiator with coolant and check for leaks.

Scheme 29

Scheme 30

1. Install the O-ring to the water pipes. NOTE: Use new O-rings when reassembling. Never apply sort of oil on O-ring and O-ring groove of pipe end. O-ring must be free from scratching damage.
2. Install the water outlet pipe (A) and the water inlet pipe (B). Tightening torque: 9.8 ~ 11.8Nm (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) NOTE: Make clean the contact face before assembly. Insert pipe after to be wetting O-ring or inside of attaching hole by water or antifreeze. NOTE: Install the drain plug (A) with a new gasket. Tightening torque: 96.1~100.0N.m(9.8~10.2kgf.m,70.9~73.8lb-ft)
3. Install the intake manifold module. (Refer to «INTAKE AND EXHAUST SYSTEM»(ref-417717) in this group)
