Water Pump
| Symptoms | Possible Causes | Remedy | ||
|---|---|---|---|---|
| Coolant leakage | From the bleed hole of the water pump | Visually check | Check leaks after about ten-minute warming up. | If coolant still leaks, replace a water pump. |
| If leakage stops, reuse the water pump (Do not replace the pump with a new one). | ||||
| From gaskets or bolts | Check the tightening of the water pump mounting bolts. | Retighten the mounting bolts. | ||
| Check damage of gaskets or inflow of dust. | Replace the gasket and clean dust off. | |||
| From outer surface of water pump | Check the material or any cracks of the water pump. | Poor material. If any crack found, replace the water pump. | ||
| Noise | From bearings From mechanical seals Impeller interference | Inspection with a stethoscope | After starting the engine, check noise with a stethoscope. | If there is no noise, reuse the water pump (do not replace it). |
| If there is any noise from the water pump, remove the drive belt and recheck. | ||||
| Inspection after removing a drive belt | After removing a water pump and a drive belt, check noise again. | If there is noise, reuse the water pump. Check other drive line parts. | ||
| If there is no noise, replace the water pump with a new one. | ||||
| Inspection after removing a water pump | After removing a water pump and a drive belt, check noise again. | If there is any interference between them, replace the water pump with a new one. | ||
| Overheating | Damaged impeller Loosened impeller | Loosened impeller | Corrosion of the impeller wing | Check engine coolant. Poor coolant quality/Maintenance check |
| Impeller separation from the shaft | Replace the water pump. | |||
SYMPTOM REFERENCE CHART
Scheme 36
Scheme 37
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
Scheme 44
Scheme 45
- Disconnect the negative terminal (A) from the battery.
- Remove the engine room cover (A), engine cover (B) and radiator grill upper cover (C).
- Loosen the drain plug (A) and drain the engine coolant. Remove the radiator cap (B) to speed draining. WARNING: Never remove the radiator cap when the engine is hot. Serious scalding could be caused by hot fluid under high pressure escaping from the radiator.
- Remove the air cleaner assembly. Remove the air duct (A). Disconnect the air flow sensor (AFS) connector (C). Disconnect the breather hose (B). Remove the resonator (F), the intake air hose (E) and air cleaner assembly (D).
- Disconnect the ETC module connector (A).
- Disconnect the positive crankcase ventilation (PCV) hose (A), the purge control solenoid valve (PCSV) hose (B) and the water hoses (C) from the intake manifold module and the throttle body.
- Remove the throttle body.
- Remove the engine coolant temperature control assembly (A).
- Remove the O-ring (A).
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
- Install the O-ring (A).
- Install the engine coolant temperature control assembly (A). Tightening torque: 16.7 ~ 19.6N.m (1.7 ~ 2.0kgf.m, 12.3 ~ 14.5lb-ft) NOTE: The protrusion of the gasket must be face the front of the engine.
- Install the throttle body. (Refer to «INSTALLATION»(ref-417731-S31092154492011083000000) )
- Reconnect the positive crankcase ventilation (PCV) hose (A), the purge control solenoid valve (PCSV) hose (B) and the water hoses (C) to the intake manifold module and the throttle body.
- Reconnect the ETC module connector (A).
- Install the air cleaner assembly. Install the resonator (F), the intake air hose (E) and air cleaner assembly (D). Reconnect the breather hose (B). Reconnect the air flow sensor (AFS) connector (C). Install the air duct (A). Tightening torque Hose clamp bolt: 2.9 ~ 4.9N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft)
- Install the engine room cover (A), the engine cover (B) and the radiator grill upper cover (C).
- Connect the battery negative terminal (A). Tightening torque: 4.0~6.0N.m (0.4~0.6kgf.m, 3.0~4.4lb-ft)
- Fill the radiator with coolant and check for leaks.
