STARTER SPECIFICATIONS
| Application | Specification |
|---|
| Armature Maximum Runout |
| Accent & Elantra | (1) |
| Santa Fe, Sonata, Tiburon & XG300 |
| Standard | 0.002" (0.05 mm) |
| Limit | 0.004" (0.10 mm) |
| Brush Length | (2) |
| Commutator Outside Diameter |
| Accent & Elantra | (1) |
| Santa Fe, Sonata, Tiburon & XG300 |
| Standard Diameter | 1.16" (29.4 mm) |
| Wear Limit | 1.12" (28.4 mm) |
| Insulator Depth |
| Accent & Elantra | (1) |
| Santa Fe, Sonata, Tiburon & XG300 |
| Standard Depth | 0.020" (0.50 mm) |
| Wear Limit | 0.008" (0.20 mm) |
| Pinion Gap | 0.02-0.08" (0.5-2.0 mm) |
| (1) Information is not available from manufacturer. (2) Bottom of limit line that is stamped into brush. |
| (1) | Information is not available from manufacturer. |
| (2) | Bottom of limit line that is stamped into brush. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Starter Mounting Bolts | 20-25 (27-34) |
| Solenoid Battery Terminal Nut | 7-12 (10-16) |
Starting System Wiring Diagram (Accent). Scheme 1
Scheme 1: Starting System Wiring Diagram (Accent)
Starting System Wiring Diagram (Elantra). Scheme 2
Scheme 2: Starting System Wiring Diagram (Elantra)
Starting System Wiring Diagram (Santa Fe). Scheme 3
Scheme 3: Starting System Wiring Diagram (Santa Fe)
Starting System Wiring Diagram (Sonata - A/T). Scheme 4
Scheme 4: Starting System Wiring Diagram (Sonata - A/T)
Starting System Wiring Diagram (Sonata - M/T). Scheme 5
Scheme 5: Starting System Wiring Diagram (Sonata - M/T)
Starting System Wiring Diagram (Tiburon). Scheme 6
Scheme 6: Starting System Wiring Diagram (Tiburon)
Starting System Wiring Diagram (XG300). Scheme 7
Scheme 7: Starting System Wiring Diagram (XG300)
