Engine Controls - Specifications: Other Hyundai Elantra II facelift

Specifications 3 illustrations ~153 words

IDLE SPEED & MIXTURE

Note. Idle speed and mixture are computer-controlled.

FAST IDLE SPEED

Note. Fast idle speed is computer-controlled.

THROTTLE POSITION (TP) SENSOR

ApplicationAt IdleWide Open Throttle
Accent, Elantra & Tiburon.10-.884.25-4.8
Sonata.48-.524.5-5.5

TP SENSOR VOLTAGE SPECIFICATIONS

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature at specified cranking speed, all spark plugs removed and throttle wide open.

ApplicationSpecification
Compression Ratio
Accent (1.5L)10.0:1
Elantra (1.8L)10.0:1
Sonata
2.0L9.0:1
3.0L8.9:1
Tiburon (2.0L)10.3:1
Compression Pressure
Accent (1.5L)234 psi (1613 kPa)
Elantra (1.8L)213 psi (1468 kPa)
Sonata
2.0L171 psi (1188 kPa)
3.0L170 psi (1172 kPa)
Tiburon (2.0L)213 psi (1468 kPa)
Maximum Variation Between Cylinders All Models14 psi (97 kPa)

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. All models are equipped with hydraulic lash adjusters. No adjustments are required.

IGNITION COIL

ApplicationPrimarySecondary
Accent (1.5L).45-.5510,300-13,900
Elantra (1.8L).45-.5510,300-13,900
Sonata
2.0L.77-.9510,300-13,900
3.0L.72-.8810,300-13,900
Tiburon.45-.5510,300-13,900

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH-TENSION WIRE RESISTANCE

Wire ApplicationOhms
Accent (1.5L)
No. 14,800
No. 210,000
No. 37,300
No. 412,000
Elantra (1.8L)
No. 115,300
No. 212,400
No. 310,600
No. 48,800
Sonata
2.0L
No. 15,800
No. 28,400
No. 310,600
No. 49,700
3.0L
Coil5,800
No. 18,000
No. 25,400
No. 39,600
No. 46,900
No. 511,000
No. 68,000
Tiburon (2.0L)
No. 115,300
No. 212,400
No. 310,700
No. 48,800

HIGH-TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNumber
Accent (1.5L)
ChampionRC9YC4/RC10YC4
NGKBKR5ES-11
Elantra (1.8L)
ChampionRC9YC4/RC10YC4
NGKBKR5ES-11
Sonata (2.0L)
ChampionRN9YC4
NGKBPR6ES-11
Sonata (3.0L)
NDP16PR-11
NGKPGR5A-11
Tiburon (2.0L)
ChampionRN9YC4/RC10YC4
NGKBKR5ES-11

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
All Models.039-.043 (1.0-1.1)15-21 (20-28)

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Note. Use illustrations to determine firing order. (Scheme 1), (Scheme 2) or (Scheme 3).

Firing Order (1.5L). Scheme 1

Scheme 1: Firing Order (1.5L)
Scheme 1: Firing Order (1.5L)

Firing Order (1.8L & 2.0L). Scheme 2

Scheme 2: Firing Order (1.8L & 2.0L)
Scheme 2: Firing Order (1.8L & 2.0L)

Firing Order & Distributor Rotation (3.0L). Scheme 3

Scheme 3: Firing Order & Distributor Rotation (3.0L)
Scheme 3: Firing Order & Distributor Rotation (3.0L)

IGNITION TIMING

ApplicationBase Timing
Accent (1.5L) (1)9° @ 800
Elantra (1.8L) (1)10° @ 800
Sonata
2.0L (1)5° @ 750
3.0L (2)5° @ 700
Tiburon (2.0L) (1)10° @ 800
(1) Ignition timing is not adjustable. (2) With ignition timing adjustment connector grounded. DO NOT adjust timing with scan tool connected to DLC.
(1)Ignition timing is not adjustable.
(2)With ignition timing adjustment connector grounded. DO NOT adjust timing with scan tool connected to DLC.

IGNITION TIMING (Degrees BTDC @ RPM)

FUEL PUMP

Engine ApplicationAt Idle W/ Vacuum psi (kPa)At Idle W/O Vacuum psi (kPa)
Accent (1.5L)36 (250)44 (300)
Elantra (1.8L)37 (255)44 (300)
Sonata (2.0L & 3.0L)39 (270)46-49 (320-340)
Tiburon (2.0L)37 (255)44 (300)

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
Accent, Elantra & Tiburon15.6-16.3
Sonata13.0-16.0

INJECTOR RESISTANCE
