Removal & Installation - A/t Hyundai Elantra I

Automatic Trans 3 illustrations ~291 words

Scheme 71

Scheme 71: Removal

Scheme 72

Scheme 72

Scheme 73

Scheme 73
  1. Remove drain plug and drain transmission fluid into appropriate container. Remove air cleaner assembly. Disconnect fluid cooler hoses on top of transaxle and plug all fittings and lines.
  2. Remove control cable and speedometer cable. Disconnect all harness connectors from transaxle case. Remove starter. Remove top transaxle-to-engine mounting bolts "A". (Scheme 71)
  3. On Elantra, remove transaxle top mounting bracket. (Scheme 72) Ensure transaxle is in Neutral.
  4. Support engine from top, or by suitable jack from bottom, using care not to damage engine oil pan. Remove centermember support under engine. (Scheme 73) Remove lower bellhousing cover to access torque converter bolts.
  5. Index mark torque converter to flywheel/drive plate and remove special torque converter bolts. Push torque converter away from engine into transaxle. Reinstall centermember support under engine, but only snug tighten bolts.
  6. Remove undercover panel(s). Remove both axle shaft assemblies. See FWD AXLE SHAFTS article in DRIVE AXLES. Support transaxle with appropriate type jack. Remove lower transaxle-to-engine mounting bolts. Remove transaxle from vehicle.
  1. To install, reverse removal procedure. Before installing transaxle to engine, be sure to install torque converter into transaxle first, aligning torque converter to transaxle pump drive.
  2. Install transaxle-to-engine mounting bolts in correct locations. (Scheme 71) Tighten to proper specification. Refer to the «TRANSAXLE MOUNTING BOLT TORQUE SPECIFICATIONS»(/hyundai/elantra/i-1990-1995/remont/automatic-trans/#removal-installation-at) table.
  3. Tighten all mounting bolts to specification. Refer to the «TORQUE SPECIFICATIONS»(/hyundai/elantra/i-1990-1995/remont/automatic-trans/#removal-installation-at) table at the end of this article. Refill transaxle fluid to correct level on dipstick. Adjust control cable. Check neutral safety switch adjustment. Refer to ADJUSTMENTS information in SERVICING article. Recheck fluid level after engine is brought to operating temperature before driving vehicle.
LocationBolt Size (mm)Ft. Lbs. (N.m)
"A"10 x 4032-41 (43-55)
"B"10 x 6532-41 (43-55)
"C"10 x 5520-25 (27-34)
"D"8 x 6022-26 (30-35)
"E"6 x 127-9 (10-12)
"F"8 x 1222-26 (30-35)
"G"(1)34-39 (46-53)
(1) These short shank bolts are special torque converter bolts.
(1)These short shank bolts are special torque converter bolts.

TRANSAXLE MOUNTING BOLT TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Centermember End Mounting Bolt44-59 (60-80)
Centermember-To-Front Engine Mount Bolt22-30 (30-40)
Centermember-To-Rear Engine Mount Bolt33-44 (45-60)
Drain Plug22-26 (30-35)
Lower Ball Joint Nut44-53 (60-72)
Starter Bolt20-25 (27-34)
Strut Bar Nut55-66 (75-90)
Tie Rod End Nut18-26 (24-35)
Torque Converter-To-Drive Plate Special Bolt34-39 (46-53)
Transaxle Top Mounting
Bracket-To-Transaxle Bolt44-59 (60-80)
Bracket-To-Body Sidemember Bolt22-30 (30-40)
Bracket Long Through Bolt66-80 (90-108)
INCH Lbs. (N.m)
Air Cleaner Mounting Bolt71-89 (8-10)
Bellhousing Lower Cover Bolt89-106 (10-12)
Neutral Safety Switch Bolts89-106 (10-12)
Oil Pan Bolts89-106 (10-12)
Speedometer Sleeve Locking Bolt27-44 (3-5)

TORQUE SPECIFICATIONS
