Contents Wiring diagrams Section: Frames, Subframes & Crossmembers All sections

Front Suspension System: Overview Hyundai Azera II

Frames, Subframes & Crossmembers 16 illustrations ~356 words

Scheme 1

Scheme 1: Components

Scheme 2

Scheme 2: Components

Scheme 3

Scheme 3: Replacement

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Remove the front wheel & tire (A). Tightening torque: 88.3 ~ 107.9N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Remove the variable damper connector (A) & bracket (B).
  3. Remove the wheel speed sensor & bracket (A) from the front strut assembly by loosening bolts.
  4. Disconnect the stabilizer link (B) with the front strut assembly (A) after loosening the nut. Tightening torque: 98.1 ~ 117.7N.m (10.0 ~ 12.0kgf.m, 72.3 ~ 86.8lb-ft)
  5. Disconnect the front strut assembly (A) with the knuckle by loosening the bolt & nut. Tightening torque: 196.1~215.7N.m (20.0~22.0Kgf.m, 144.7 ~159.1lb-ft)
  6. Loosen the strut upper locking nuts (A) and than remove the front strut assembly. Tightening torque: 53.9~73.5N.m (5.5~7.5Kgf.m, 34.8~54.2lb-ft)
  7. Installation is the reverse of removal.

Scheme 10

Scheme 10: Disassembly
  1. Under the condition of fixed strut (A) on the SST (09546-26000), remove the front strut self-locking nut (B).
  2. Remove the insulator, spring seat, coil spring and dust cover from the strut assembly

Scheme 11

Scheme 11: Inspection
  1. Check the strut bearing for wear and damage.
  2. Check the spring upper and lower seat for damage and deterioration.
  3. Compress and extend the piston rod (A) and check that there is no abnormal resistance or unusual sound during operation.

Scheme 12

Scheme 12: Disposal
  1. Fully extend the piston rod.
  2. Drill a hole on the (A) section to remove gas form the cylinder. CAUTION: The gas coming out is harmless but be careful of chips that may fly when drilling.

Scheme 13

Scheme 13: Replacement

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. Remove the front wheel & tire (A). Tightening torque: 88.3 ~ 107.9N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Loosen the bolt & nut and then remove the lower arm (A). Tightening torque: 98.1~117.7N.m (10.0~12.0kgf.m, 72.3 ~ 86.6lb-ft)
  3. Loosen the bolts & nuts than Remove the front lower arm (A). Tightening torque Front: 117.7~137.3N.m (12.0~14.0Kgf.m, 86.8~101.3lb-ft) Rear: 156.9~176.5N.m (16.0~18.0Kgf.m, 115.7~130.2-ft)
  4. Installation is the reverse of removal.
