Front Suspension System: Diagnosis Hyundai Azera II

Frames, Subframes & Crossmembers 21 illustrations ~668 words

Inspection

  1. Check the bushing for wear and deterioration.
  2. Check the lower arm for deformation.
  3. Check the all bolts and nuts.
  4. Check the ball joint dust cover for crack

Scheme 17

Scheme 17: Replacement

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28
  1. Remove the front wheel & tire (A). Tightening torque: 88.3 ~ 107.9N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Loosen the bolt (A) and then disconnect the universal joint assembly from the pinion of the steering gear box. Tightening torque: 32.4 ~ 34.3N.m (3.3 ~ 3.5kgf.m, 23.9 ~ 25.3lb-ft) CAUTION: Keep the neutral-range to prevent the damage of the clock spring inner cable when you handle the steering wheel. Make sure when you reassemble the universal joint and pinion shaft certainly has been inserted.
  3. Remove the under cover (A).
  4. Remove the sprit pin and castle nut and then disconnect the tie-rod end (A) from the front knuckle. Tightening torque: 34.3~44.1N.m (3.5~4.5Kgf.m, 25.3~32.5lb-ft)
  5. Loosen the bolt & nut and then remove the lower arm (A). Tightening torque: 98.1~117.7N.m (10.0~12.0Kgf.m, 72.3~86.8lb-ft)
  6. Disconnect the stabilizer link (B) with the front strut assembly (A) after loosening the nut. Tightening torque: 98.1~117.7N.m (10.0~12.0Kgf.m, 72.3~86.8lb-ft)
  7. Loosen the bolt and then remove the front roll stopper (A). Tightening torque: 107.9~117.7N.m (11.0~13.0Kgf.m, 79.6~94.0lb-ft)
  8. Disconnect the muffler rubber hanger (A).
  9. Loosen the bolts & nuts and then remove the sub frame (A). Tightening torque: Sub frame mounting bolts & nuts: 156.9 ~ 176.5N.m (16.0 ~ 18.0kgf.m, 115.7 ~ 130.2lb-ft) Sub frame bracket bolts & nuts: 44.1 ~ 58.8N.m (4.5 ~ 6.0kgf.m, 32.5 ~ 43.4lb-ft)
  10. Remove the front stabilizer bar (A). Tightening torque: 49.0~63.7N.m (5.0~6.5kgf.m, 36.2~47.0lb-ft)
  11. Loosen the nut and then remove the stabilizer link (A) from the stabilizer bar. Tightening torque: 98.1~117.7N.m (10.0~12.0kgf.m, 72.3~86.8lb-ft)
  12. Installation is the reverse of removal.
  13. Check the alignment. (Refer to " «ALIGNMENT»(ref-585018-S31626126142013110700000) ")
  1. Check the bushing for wear and deterioration.
  2. Check the front stabilizer bar for deformation.

Scheme 29

Scheme 29: Replacement

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37
  1. Remove the front wheel & tire (A). Tightening torque: 88.3 ~ 107.9N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6lb-ft) CAUTION: Be careful not to damage to the hub bolts when removing the front wheel & tire.
  2. Loosen the bolt (A) and then disconnect the universal joint assembly from the pinion of the steering gear box. Tightening torque: 32.4 ~ 34.3N.m (3.3 ~ 3.5kgf.m, 23.9 ~ 25.3lb-ft) CAUTION: Keep the neutral-range to prevent the damage of the clock spring inner cable when you handle the steering wheel. Make sure when you reassemble the universal joint and pinion shaft certainly has been inserted.
  3. Remove the under cover (A).
  4. Remove the sprit pin and castle nut and then disconnect the tie-rod end (A) from the front knuckle. Tightening torque: 34.3~44.1N.m (3.5~4.5Kgf.m, 25.3~32.5lb-ft)
  5. Loosen the bolt & nut and then remove the lower arm (A). Tightening torque: 98.1~117.7N.m (10.0~12.0Kgf.m, 72.3~86.8lb-ft)
  6. Disconnect the stabilizer link (B) with the front strut assembly (A) after loosening the nut. Tightening torque: 98.1~117.7N.m (10.0~12.0Kgf.m, 72.3~86.8lb-ft)
  7. Loosen the bolt and then remove the front roll stopper (A). Tightening torque: 107.9~117.7N.m (11.0~13.0Kgf.m, 79.6~94.0lb-ft)
  8. Disconnect the muffler rubber hanger (A).
  9. Loosen the bolts & nuts and then remove the sub frame (A). Tightening torque: Sub frame mounting bolts & nuts: 156.9 ~ 176.5N.m (16.0 ~ 18.0kgf.m, 115.7 ~ 130.2lb-ft) Sub frame bracket bolts & nuts: 44.1 ~ 58.8N.m (4.5 ~ 6.0kgf.m, 32.5 ~ 43.4lb-ft)
  10. Remove the front lower arm. (Refer to Front Suspension System - " «FRONT LOWER ARM»(ref-585022-S04797640302013110700000) ")
  11. Remove the front strut assembly. (Refer to Front Suspension System - " «FRONT STRUT ASSEMBLY»(ref-585022-S22490419902013110700000) ")
  12. Remove the front stabilizer bar. (Refer to Front Suspension System - " «FRONT STABILIZER BAR»(ref-585022-S11196845792013110700000) ")
  13. Remove the steering gear box. (Refer to " «STEERING GEAR BOX»(ref-585023-S28408487012013110700000) ")
  14. Installation is the reverse of removal.
  15. Check the alignment. (Refer to " «ALIGNMENT»(ref-585018-S31626126142013110700000) ")
