Integrated Memory System (Ims): Removal & Installation Hyundai Azera II

Communication Devices 12 illustrations ~268 words

Installation

  1. Install the IMS module after reconnecting the connector.
  2. Install the driver seat. NOTE: Make sure the IMS module connectors and related connectors are plugged in properly. Check that IMS system operates normally.

Scheme 42

Scheme 42: Circuit Diagram

Scheme 43

Scheme 43

Scheme 44

Scheme 44: Inspection

Scheme 45

Scheme 45

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Scheme 48

Scheme 48

Scheme 49

Scheme 49

Scheme 50

Scheme 50
  1. It will be able to diagnose defects of IMS with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "IPM - Power seat module".
  3. Select "Input/output monitoring", if you will check current data of body network system. It provides input/output status of each module.
  4. If you will check each module data operation forcefully, select "Actuation test".
  5. To check the DTC of the each module, select "DIAGNOSTIC TROUBLE CODES"
  6. You can turn ON/OFF of Power seat module option with the "User option"
  7. Select the "Data setting" to set the seat position setting when replacing the IMS unit or seat module.
  8. Click the "Set".
  9. Click the "OK" to complete the set up procedure.

Scheme 51

Scheme 51: Removal

Scheme 52

Scheme 52

Scheme 53

Scheme 53
  1. Disconnect the negative (-) battery terminal.
  2. Remove the door trim (A) after loosening mounting screws. (Refer to " «FRONT DOOR TRIM»(ref-585031-S38983803542013110700000) ")
  3. Remove the memory power seat control switch (A) after loosening connector and screws (3EA) from the door trim.

Note. Make sure that the IMS control switch connectors and related connectors are plugged in properly. Check the IMS control switch operates normally.

  1. Install the memory power seat control switch after connecting the switch connector.
  2. Install the driver door trim.
  3. Install the negative (-) battery terminal.
