Front Back View Camera System: Overview Hyundai Azera II

Collision/avoidance 4 illustrations ~181 words

Scheme 29

Scheme 29: Component Location
Scheme 29: Component Location

Scheme 30

Scheme 30: Circuit Diagram
Scheme 30: Circuit Diagram

Description

Front blind camera is a supplemental system that shows blind spot in front of the vehicle through the AV monitor. The front blind camera will operate when you push the button and shift the transaxle into N (Neutral) or D (Drive) while driving less then 10km/h. After the vehicle stops for 4 minutes with the transaxle in N (Neutral) or D (Drive), it will bring up the previous screen.

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the REVERSE position.

This system is a supplemental system that shows behind the vehicle through the AV monitor while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver to always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there may be blind spot that can't be seen by the camera.

Scheme 31

Scheme 31: Front View Camera
Scheme 31: Front View Camera
  1. Remove the front bumper. (Refer to " «FRONT BUMPER COVER»(ref-585003-S14086501462013110700000) ")
  2. Loosen 3 screws and disconnect the connector (6 pins). Remove the front view camera (A).

Scheme 32

Scheme 32: Back View Camera
Scheme 32: Back View Camera
  1. Open the trunk and remove the rear garnish assembly. (Refer to " «REAR COMBINATION LAMP»(ref-585044-S23530685612013110700000) ")
  2. Disconnect the connector and loosen 2 screws. And remove the back view camera (A).
