Specification
| Items | Specifications |
|---|---|
| Rated voltage | DC 12 V |
| Operating voltage | DC 9 ~ 16 V |
| Operating temperature | 22 °F ~ 176 °F (-30 °C ~ 80 °C) |
| Insulation resistance | 100 Mohms or more |
| Parasitic current draw | Less than 4 mA (12.8 V) - BCM & Receiver Less than 3 mA (12.8 V) - BCM |
| Rated load | |
| Burglar horn | DC 12 V, 200 mA (Inductance load) |
| Burglar relay | DC 12 V, 200 mA (Inductance load) |
| Tail lamp relay | DC 12 V, 200 mA (Inductance load) |
| Rear defogger relay | DC 12 V, 200 mA (Inductance load) |
| Power window timer relay | DC 12 V, 200 mA (Inductance load) |
| Seat belt warning indicator | DC 12 V, 40 ~ 60 mW (LED load) |
| Room lamp | DC 12 V, 30 W (Lamp load) |
| Door lock relay | DC 12 V, 200 mA (Inductance load) |
| Door unlock relay | DC 12 V, 200 mA (Inductance load) |
| Hazard lamp relay | DC 12 V, 200 mA (Inductance load) |
| Driver door actuator | DC 12 V, 10 W (Motor load) |
BODY CONTROL MODULE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
| Terminal No. | Connector A | Connector B |
|---|---|---|
| 1 | Door unlock relay | Assist door switch |
| 2 | Power window relay | 4 door switch |
| 3 | Burglar alarm horn relay | Assist door key unlock switch |
| 4 | Hazard lamp relay | Driver door key unlock switch |
| 5 | Burglar alarm relay | Trunk key unlock switch (4 Doors), Tail gate key unlock switch (3 Doors) |
| 6 | B+ | Door warning switch |
| 7 | Chime bell | IG2 |
| 8 | Code saving | IG1 |
| 9 | B+ | |
| 10 | Trunk switch (4 Doors), Tail gate switch (3 Doors) | |
| 11 | Seat belt switch | Driver door switch |
| 12 | Room lamp switch | Tail lamp switch |
| 13 | Door lock relay | Speed Sensor Signal |
| 14 | Rear defogger relay | Rear door actuator unlock switch (4 Doors), Rear door & tail gate actuator unlock switch (3 Doors) |
| 15 | Tail lamp relay | Assist door actuator unlock switch |
| 16 | Driver door actuator unlock switch | |
| 17 | Ground | Hood switch |
| 18 | Driver door unlock actuator | Alternator (L) |
| 19 | Driver door key lock switch | |
| 20 | Seat belt indicator | Ground |
| 21 | Assist door key lock switch | |
| 22 | Air bag signal (Crash signal) | |
| 23 | Rear fog lamp switch (EC, Australia) | |
| 24 | Rear defogger switch |
BCM CONNECTOR TERMINALS REFERENCE CHART
