Engine Controls - Service & Adjustment Specifications: Other Hyundai Accent II рестайлинг

Specifications 6 illustrations ~189 words

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature, at specified cranking speed, all spark plugs removed and throttle wide open.

Application(1) Specification
Compression Pressure
Accent
Standard Value218 psi (15.3 kg/cm 2 )
Limit Value203 psi (14.3 kg/cm 2 )
Elantra
Standard Value218 psi (15.3 kg/cm 2 )
Limit Value203 psi (14.3 kg/cm 2 )
Santa Fe (2)
Standard Value170 psi (12.0 kg/cm 2 )
Limit Value150 psi (11.0 kg/cm 2 )
Sonata
Standard Value170 psi (12.0 kg/cm 2 )
Limit Value150 psi (11.0 kg/cm 2 )
Tiburon (2.0L)
Standard Value218 psi (15.3 kg/cm 2 )
Limit Value203 psi (14.3 kg/cm 2 )
Tiburon (2.7L)
Standard Value170 psi (12.0 kg/cm 2 )
Limit Value150 psi (11.0 kg/cm 2 )
XG350
Standard Value170 psi (12.0 kg/cm 2 )
Limit Value150 psi (11.0 kg/cm 2 )
Maximum Variation Between Cylinders
All Models14 psi (1.0 kg/cm 2 )
(1) Checked with engine coolant temperature at 176-205°F (80-96°C) and engine speed at 250-400 RPM. (2) This information applies only to 2.4L & 2.7L. Information on 3.5L is not available from manufacturer.
(1)Checked with engine coolant temperature at 176-205°F (80-96°C) and engine speed at 250-400 RPM.
(2)This information applies only to 2.4L & 2.7L. Information on 3.5L is not available from manufacturer.

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. All models are equipped with hydraulic lash adjusters. No adjustments are required.

IGNITION COIL

ApplicationPrimarySecondary
Accent0.78-0.96 Ohm11,000-15,000 Ohms
Elantra0.45-0.55 Ohm10,300-13,900 Ohms
Santa Fe
2.4L0.78-0.96 Ohm (1)10,200-13,900 Ohms
2.7L0.67-0.81 Ohm11,300-15,300 Ohms
3.5L0.78 Ohm10,400-15,600 Ohms
Sonata
2.4L0.77-0.99 Ohm (1)10,300-13,900 Ohms
2.7L0.67-0.81 Ohm11,300-15,300 Ohms
Tiburon
2.0L0.45-0.55 Ohm10,300-13,900 Ohms
2.7L0.67-0.81 Ohm11,300-15,300 Ohms
XG3500.67-0.81 Ohm (1)10,400-15,600 Ohms
(1) Value is approximate with coil energized. See IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.
(1)Value is approximate with coil energized. See IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH-TENSION WIRE RESISTANCE

Wire Application(1) Ohms
Accent
BOUGI
No. 1 (22" - 560 mm)2.51-3.76
No. 2 (17" - 440 mm)1.97-2.96
No. 3 (14" - 360 mm)1.61-2.42
No. 4 (12" - 310 mm)1.39-2.08
R16AIPS
No. 1 (22" - 560 mm)5.60-11.76
No. 2 (17" - 440 mm)4.40-9.24
No. 3 (14" - 360 mm)3.60-7.56
No. 4 (12" - 310 mm)3.10-6.51
Elantra
BOUGI
No. 1 (24" - 605 mm)2.71-4.07
No. 2 (21" - 545 mm)2.44-3.66
No. 3 (18" - 450 mm)2.02-3.02
No. 4 (15" - 370 mm)1.66-2.49
R16AIPS
No. 1 (24" - 605 mm)6.05-12.71
No. 2 (21" - 545 mm)5.45-11.45
No. 3 (18" - 450 mm)4.50-9.45
No. 4 (15" - 370 mm)3.70-7.77
Santa Fe
2.4L(1) (2) (3)
2.7L
No. 14.39-6.59
No. 22.28-3.43
No. 33.49-5.24
No. 41.90-2.86
No. 53.25-4.87
No. 61.30-1.95
3.5L(3)
Sonata
2.4L(1) (2) (3)
2.7L
No. 14.39-6.59
No. 22.28-3.43
No. 33.49-5.24
No. 41.90-2.86
No. 53.25-4.87
No. 61.30-1.95
Tiburon
2.0L(3)
2.7L
No. 14.39-6.59
No. 22.28-3.43
No. 33.49-5.24
No. 41.90-2.86
No. 53.25-4.87
No. 61.30-1.95
XG350(3)
(1) Resistance should not be more than 10,000 ohms per foot of spark plug cable. (2) 2.4L engine uses 2 ignition coils with an internal power transistor. Ignition coil No. 1 is located on cylinder No. 1 spark plug. Ignition coil No. 2 is located on cylinder No. 2 spark plug. (3) Information is not available from manufacturer.
(1)Resistance should not be more than 10,000 ohms per foot of spark plug cable.
(2)2.4L engine uses 2 ignition coils with an internal power transistor. Ignition coil No. 1 is located on cylinder No. 1 spark plug. Ignition coil No. 2 is located on cylinder No. 2 spark plug.
(3)Information is not available from manufacturer.

HIGH-TENSION WIRE RESISTANCE

Scheme 1

Scheme 1: Plug Wires & Ignition Coils (Accent 1.6L & Elantra 2.0L)
Scheme 1: Plug Wires & Ignition Coils (Accent 1.6L & Elantra 2.0L)

Scheme 2

Scheme 2: Plug Wires & Ignition Coils (Santa Fe 2.4L & Sonata 2.4L)
Scheme 2: Plug Wires & Ignition Coils (Santa Fe 2.4L & Sonata 2.4L)

Scheme 3

Scheme 3: Plug Wires & Ignition Coils (Santa Fe 2.7L & Sonata 2.7L)
Scheme 3: Plug Wires & Ignition Coils (Santa Fe 2.7L & Sonata 2.7L)

Scheme 4

Scheme 4: Plug Wires & Ignition Coils (Santa Fe 3.5L & XG350 3.5L)
Scheme 4: Plug Wires & Ignition Coils (Santa Fe 3.5L & XG350 3.5L)

SPARK PLUGS

ApplicationNumber
Accent
ChampionRC10YC4
NGKBKR5ES-11
Elantra
ChampionRC10YC4
NGKBKR5ES-11
Santa Fe
2.4L
ChampionRN10PYP4
NGKPGR5C-11
2.7L & 3.5L
ChampionRC10PYP4
NGKPFR5N-11
Sonata
2.4L
ChampionRN10PYP4
NGKPGR5C-11
2.7L
ChampionRC10PYP4
NGKPFR5N-11
Tiburon
2.0L
ChampionRN10PYP4
NGKPGR5C-11
2.7L
ChampionRC10PYP4
NGKPFR5N-11
XG350
ChampionRC10PYP4
NGKPFR5N-11

SPARK PLUG TYPE

ApplicationGap - In. (mm)Torque - Ft. Lbs. (N.m)
All Models0.039-0.043 (1.0-1.1)15-22 (20-30)

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Note. To determine firing order, refer to appropriate illustration. (Scheme 5)or (Scheme 6).

Scheme 5

Scheme 5: Firing Order (Accent 1.5L & 1.6L, Elantra 2.0L, Santa Fe 2.4L & Sonata 2.4L)
Scheme 5: Firing Order (Accent 1.5L & 1.6L, Elantra 2.0L, Santa Fe 2.4L & Sonata 2.4L)

Scheme 6

Scheme 6: Firing Order (Santa Fe 2.7L & 3.5L, Sonata 2.7L & XG350 3.5L)
Scheme 6: Firing Order (Santa Fe 2.7L & 3.5L, Sonata 2.7L & XG350 3.5L)

IGNITION TIMING

Application(1) Base Timing
Accent4°-14° @ 650-850 RPM
Elantra3°-13° @ 600-800 RPM
Santa Fe
2.4L2°-12° @ 650-850 RPM
2.7L7°-17° @ 600-800 RPM
3.5L(2)
Sonata
2.4L2°-12° @ 600-800 RPM
2.7L7°-17° @ 750-950 RPM
Tiburon
2.0L4°-14° @ 600-800 RPM
2.7L7°-17° @ 650-750 RPM
XG3503°-7° @ 600-800 RPM
(1) Ignition timing is controlled by computer and is not adjustable. Specification is for inspection only. (2) For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.
(1)Ignition timing is controlled by computer and is not adjustable. Specification is for inspection only.
(2)For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.

IGNITION TIMING (Degrees BTDC @ RPM)

REGULATED FUEL PRESSURE (ACCENT & ELANTRA)

ApplicationAt Idle - psi (kg/cm 2 )
Accent & Elantra50 (3.52)
(1) Fuel pressure regulator is an integral part of the fuel pump assembly.
(1)Fuel pressure regulator is an integral part of the fuel pump assembly.

REGULATED FUEL PRESSURE (ACCENT & ELANTRA) (1)

REGULATED FUEL PRESSURE (SANTA FE, SONATA & XG350)

ApplicationAt Idle W/Vacuum - psi (kg/cm 2 )At Idle W/O Vacuum - psi (kg/cm 2 )
Santa Fe38 (2.67)46-49 (3.23-3.45)
Sonata38 (2.67)47-50 (3.31-3.52)
XG35037 (2.57)46-49 (3.26-3.47)

REGULATED FUEL PRESSURE (SANTA FE, SONATA & XG350)

REGULATED FUEL PRESSURE (TIBURON)

ApplicationAt Idle - psi (kg/cm 2 )At Idle W/O Vacuum - psi (kg/cm 2 )
Tiburon
2.0L (1)50 (3.52)N/A
2.7L(2) 38 (2.67)47-50 (3.31-3.52)
(1) Fuel pressure regulator is an integral part of the fuel pump assembly. (2) With vacuum applied.
(1)Fuel pressure regulator is an integral part of the fuel pump assembly.
(2)With vacuum applied.

REGULATED FUEL PRESSURE (TIBURON)

INJECTOR RESISTANCE

Application(1) Ohms
Accent15.55-16.25
Elantra15.55-16.25
Santa Fe
2.4L13.00-16.00
2.7L13.80-15.20
3.5L(2)
Sonata13.00-16.00
Tiburon
2.0L15.55-16.25
2.7L13.00-16.00
XG35013.00-16.00
(1) Resistance measured at 68°F (20°C). (2) For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.
(1)Resistance measured at 68°F (20°C).
(2)For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.

INJECTOR RESISTANCE

IDLE SPEED & MIXTURE

Note. Idle speed and air/fuel mixture are computer-controlled and not adjustable.

Application(1) RPM
Accent650-850
Elantra600-800
Santa Fe
2.4L700-900
2.7L600-800
3.5L(2)
Sonata
2.4L600-800
2.7L750-950
Tiburon
2.0L600-800
2.7L650-750
XG350600-800
(1) Check idle speed with engine warmed up, lights and accessories off, transmission in Park or Neutral, and steering wheel straight ahead. (2) For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.
(1)Check idle speed with engine warmed up, lights and accessories off, transmission in Park or Neutral, and steering wheel straight ahead.
(2)For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.

IDLE SPEED

FAST IDLE SPEED

Note. Fast idle speed is computer-controlled and information not available from manufacturer.

THROTTLE POSITION SENSOR

ApplicationOhms @ IdleVolts @ Idle
Accent700-30000.25-0.80
Elantra700-30000.10-0.88
Santa Fe
2.4L3500-65000.30-0.90
2.7L3500-65000.25-0.80
3.5L(1)(1)
Sonata
2.4L3500-65000.30-0.90
2.7L1600-24000.25-0.80
Tiburon
2.0L700-30000.10-0.88
2.7L700-30000.25-0.80
XG3503500-65000.30-0.90
(1) For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.
(1)For information on Santa Fe with 3.5L, refer to FUEL SYSTEM (3.5L) article.

TP SENSOR SPECIFICATIONS
