Maintenance Information: Overview Hyundai Accent I

Procedures 2 illustrations ~324 words

Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp A/C Compressor Controls
  2. 2 - 10 Amp Hazard Warning
  3. 3 - 10 Amp ECM
  4. 4 - 15 Amp Stop Lamps
  5. 5 - 10 Amp Courtesy Lamps, Cluster, Audio, Clock, TCM
  6. 6 - 20 Amp Rear Window Defroster
  7. 7 - 10 Amp Rear Wiper/Washer
  8. 8 - 15 Amp Front Wiper/Washer
  9. 9 - 10 Amp Back-up Lights, Turn Signal Lamps
  10. 10 - 10 Amp ABS, Cluster, Seat Belt Timer
  11. 11 - 10 Amp Air Bag
  12. 12 - 10 Amp Air Bag
  13. 13 - 15 Amp Cigarette Lighter
  14. 14 - 10 Amp Clock, Audio, Automatic Transaxle Interlock Control Module
  15. 15 - 10 Amp TCM
  16. 16 - 10 Amp Relay
  17. 17 - 30 Amp Spare Fuse
  18. 18 - 30 Amp Spare Fuse
  19. 19 - 15 Amp Spare Fuse
  20. 20 - 10 Amp Spare Fuse

Scheme 1

Scheme 1: UNDERDASH RELAY PANEL IDENTIFICATION
Scheme 1: UNDERDASH RELAY PANEL IDENTIFICATION

Relay Identification

  1. 1 - Not Used
  2. 2 - Fuel Pump Relay
  3. 3 - Starter Relay
  4. 4 - Not Used
  5. 5 - Blower Control Relay
  6. 6 - Flasher Unit
  7. 7 - Not Used

FUSIBLE LINK IDENTIFICATION

CAUTIONReplacing a fuse with one of a greater rating greatly increases chances of damaging electrical system. If replacement fuse with proper rating for circuit is not available, install one with a lesser rating.

Scheme 2

Scheme 2
Scheme 2
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.

Main Fusible Link Identification

  1. A - 60 Amp (Yellow) Generator
  2. B - 50 Amp (Red) Battery
  3. C - Not Used
  4. D - 20 Amp (Blue) Radiator Fan
  5. E - 20 Amp (Blue) ABS Controls
  6. F - 30 Amp (Pink) Ignition Switch
  7. G - 30 Amp (Pink) ABS Controls
  8. H - 30 Amp (Pink) Lamps
  9. I - 20 Amp (Blue) ECM, MFI System Controls

Fuse Identification

  1. 1 - 10 Amp Tail Lamp RH
  2. 2 - 10 Amp Tail Lamp LH
  3. 3 - 10 Amp Head Lamp RH
  4. 4 - 10 Amp Head Lamp LH
  5. 5 - 10 Amp Air Conditioning
  6. 6 - 30 Amp Blower Control
  7. 7 - 10 Amp Horn
  8. 8 - 20 Amp A/C Condenser
  1. 1 - Radiator Ran Relay
  2. 2 - Headlamp Relay
  3. 3 - Air Conditioning Relay
  4. 4 - Horn Relay
  5. 5 - Taillamp Relay
  6. 6 - Condensor Fan Relay
