POWER MIRROR SWITCH
Remove power mirror switch. Disconnect harness connector and check for continuity in each switch position, between indicated switch terminals. See POWER MIRROR SWITCH CONTINUITY TEST. (Scheme 1) Replace switch if continuity is not as specified.
| Application | Location |
|---|---|
| Accent | Driver-Side Dash, To Left Of Steering Column |
POWER MIRROR SWITCH LOCATION
Scheme 1
| Application | Terminals No. | |
|---|---|---|
| Left Mirror | ||
| Up | 1 & 6; 4 & 7 | |
| Down | 1 & 7; 4 & 6 | |
| Neutral | No Continuity | |
| Left | 1 & 5; 4 & 7 | |
| Right | 1 & 7; 4 & 5 | |
| Right Mirror | ||
| Up | 1 & 3; 4 & 7 | |
| Down | 1 & 7; 3 & 4 | |
| Neutral | No Continuity | |
| Left | 1 & 2; 4 & 7 | |
| Right | 1 & 7; 2 & 4 | |
POWER MIRROR SWITCH CONTINUITY TEST
POWER MIRROR MOTOR
Access and disconnect power mirror motor connector. (Scheme 2) Apply battery voltage between indicated motor terminals. See POWER MIRROR MOTOR TEST. (Scheme 3) Replace motor if it does not operate as specified.
| Battery + Lead (1) | Battery - Lead (1) | Mirror Operation |
|---|---|---|
| 1 | 3 | Up |
| 3 | 1 | Down |
| 2 | 3 | Left |
| 3 | 2 | Right |
| (1) Connect appropriate battery lead to indicated terminal. | ||
| (1) | Connect appropriate battery lead to indicated terminal. |
POWER MIRROR MOTOR TEST
Scheme 2
Scheme 3
ALL MIRRORS INOPERATIVE
Check for blown fuse or fusible link. Check power mirror switch ground. Check power mirror switch. Check for bad switch connections.
ONE MIRROR INOPERATIVE
Check power mirror switch. Check mirror motor. Check for open circuit between switch and mirror motors.
