Data Communication Schematic Icons
Data Communication Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR DISABLING AND ENABLING . Failure to observe the correct procedure could cause deployment of the SIR components, personal injury or unnecessary SIR system repairs
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
| Callout | Component Name |
|---|---|
| 1 | Body Control Module (BCM) |
| 2 | Body Control Module (BCM) C1 (Body Harness) |
| 3 | Body Control Module (BCM) C2 (I/P Harness) |
| 4 | C204 I/P Harness to Body Harness |
Scheme 7
| Callout | Component Name |
|---|---|
| 1 | C203 I/P Harness to HVAC Module Harness |
| 2 | C205 I/P Harness to HVAC Module Harness |
| 3 | Body Control Module (BCM) Connector |
| 4 | C204 I/P Harness to Body Harness |
| 5 | Trailer Blunt-Cut Harness Wires |
| 6 | Data Link Connector (DLC) |
| 7 | C208 I/P Harness to Body Harness |
| 8 | C200 I/P Harness to Body Harness |
| 9 | C207 I/P Harness to Body Harness |
| 10 | C201 I/P Harness to Steering Column Harness |
Scheme 8
| Connector Part Information OEM: 15480437 Service: 88988604 Description: 56-Way F GT 280/Micro 64 Series (BK) |
|---|
| Terminal Part Information Pins: A2-A6, A8-A48 Terminal/Tray: 15359541/4 Core/Insulation Crimp: M/M Release Tool/Test Probe: 15381651-2/J-35616-64A (L-BU) Pins: A7, B1-B8 Terminal/Tray: 15304711/8 Core/Insulation Crimp: Pins B3-B4, B6-B8: E/A, Pins A7, B1-B2, B5: 2/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
Body Control Module (BCM) C1 Connector Parts Identification
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| A1 | Not Used | ||
| A2 | YE | 317 | Fog Lamp Relay Control |
| A3 | L-BU | 14 | Left Turn Signal Lamp Supply Voltage |
| A4 | Not Used | ||
| A5 | PK/WH | 1970 | Headlamp Relay Control |
| A6 | BK | 755 | RAP Relay Coil Control |
| A7 | OG | 2040 | Battery Positive Voltage |
| A8 | D-GN | 113 | Windshield Wiper Switch Signal 2 |
| A9 | YE | 1977 | Fog Lamp Relay Output Coil Rear |
| A10 | WH | 193 | Rear Defog Relay Control |
| A11 | L-BU | 244 | Passenger Door Lock Switch Lock Control |
| A12 | WH | 194 | Door Unlock Control |
| A13-A17 | Not Used | ||
| A18 | BK/WH | 1969 | Headlamp High Beam Relay Control |
| A19 | D-BU | 15 | Right Turn Signal Lamps Supply Voltage |
| A20 | YE | 196 | Windshield Wiper Motor Park Switch Signal |
| A21-A23 | Not Used | ||
| A24 | BN/WH | 301 | Park Lamp Relay Control |
| A25 | Not Used | ||
| A26 | RD/BK | 1594 | Ignition 3 Relay Control |
| A27-A28 | Not Used | ||
| A29 | OG | 1732 | Inadvertent Power Supply Voltage |
| A30 | OG | 1732 | Inadvertent Power Supply Voltage |
| A31 | L-BU | 1134 | Park Brake Switch Signal |
| A32 | GY/BK | 745 | Left Front Door Ajar Switch Signal (LHD) |
| L-GN/BK | 748 | Right Front Door Ajar Switch Signal (RHD) | |
| A33-A35 | Not Used | ||
| A36 | L-BU | 74 | Front Position Lamp Relay Control (Export) |
| A37 | L-BU | 20 | Stop Lamp Supply Voltage |
| A38 | L-GN/BK | 748 | Right Front Door Ajar Switch Signal (LHD) |
| GY/BK | 745 | Left Front Door Ajar Switch Signal (RHD) | |
| A39 | BK/WH | 746 | Left Rear Door Ajar Switch Signal |
| A40 | BK | 28 | Horn Relay Control |
| A41 | PU | 1807 | Class 2 Serial Data |
| A42 | PU | 1807 | Class 2 Serial Data |
| A43 | D-GN/WH | 762 | A/C Request Signal |
| A44 | L-BU/BK | 747 | Right Rear Door Ajar Switch Signal |
| A45 | Not Used | ||
| A46 | WH | 156 | Courtesy Lamp Low Control |
| A47 | PU | 1807 | Class 2 Serial Data |
| A48 | BN | 2509 | Left Rear Park Lamps Supply Voltage |
| B1 | YE | 18 | Left Rear Stop/Turn Lamp Supply Voltage (Domestic) |
| YE | 618 | Left Rear Stop/Turn Lamp Supply Voltage (Export) | |
| B2 | D-GN | 19 | Right Rear Stop/Turn Lamp Supply Voltage (Domestic) |
| D-GN | 619 | Right Rear Stop/Turn Lamp Supply Voltage (Export) | |
| B3 | BK/WH | 1251 | Ground |
| B4 | RD | 228 | Windshield Washer Pump Control |
| B5 | OG | 840 | Battery Positive Voltage |
| B6 | D-BU | 338 | Run/Crank Voltage |
| B7 | BN | 4 | Accessory Voltage |
| B8 | OG | 1340 | Battery Positive Voltage |
Body Control Module (BCM) C1 Connector Terminal Identification
Circuit/System Description
The body control module (BCM) stores the last 4 digits of the sensing and diagnostic module (SDM) part number, also called restraints ID. After the BCM is reprogrammed the restraints ID is set to zero. A restraints ID relearn must be performed for the BCM to learn the restraints ID.
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: A DTC U1001 - U1254 Lost Communications with XXX with a history status may indicate the cause of U1000 or U1255.
- 3: The modules not communicating are the likely cause of U1000 or U1255. The modules that are available on the class 2 serial data circuit are listed in the Circuit Description.
- 7: The module which was not communicating due to a poor connection to the class 2 serial data circuit may have set DTC U1001 - U1254 Lost Communications with XXX for those modules that it was monitoring.
- 10: The modules which can communicate indicate the module which cannot communicate. You must clear the serial data communication DTCs from these modules to avoid future misdiagnosis.
- 13: If all modules are communicating, the module which set U1000 or U1255 may have done so due to some other condition.
- 15: The module which set U1000 or U1255 is the likely cause of the malfunction.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Data Communication Schematics Connector End View Reference: Master Electrical Component List | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. Record the DTCs set in by each module. If using a Tech 2, use the class 2 DTC Check feature to determine which modules have DTCs set. Did you record any DTCs in the range of U1001 - U1254 with a history status? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 3 |
| 3 | Turn ON the ignition, with the engine OFF. Attempt to communicate with each module on the class 2 serial data circuit. If using a Tech 2, obtain this information using the class 2 Message Monitor feature. Record all of the modules communicating on the class 2 serial data circuit. Compare the list of modules which are communicating to the list given in Circuit Description. Does any module on the class 2 serial data circuit not communicate? | Go to Step 4 | Go to Step 13 |
| 4 | Test the following circuits of the module that is not communicating for an open or short to ground: The battery positive voltage supply circuits The switched battery positive supply circuits The battery positive voltage output circuits The ignition voltage input circuits The ignition voltage output circuits Refer to the following: Control Module References for the applicable schematic Circuit Testing Wiring Repairs Did you find and correct the condition? | Go to Step 9 | Go to Step 5 |
| 5 | Turn OFF the ignition. Test the ground circuits of the module that is not communicating for an open. Refer to the following: Control Module References for the applicable schematic Circuit Testing Wiring Repairs Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 6 | IMPORTANT: Inspect all connectors in the serial data communications circuit. Refer to the following: Testing for Intermittent Conditions and Poor Connections Connector Repairs Turn OFF the ignition. Test the class 2 serial data circuits of the module that is not communicating for an open. Refer to the following: Data Communication Schematics Circuit Testing Wiring Repairs Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 7 | Inspect the harness connector of the module that is not communicating for poor connections and terminal tension at the following circuits: The battery positive voltage input circuits The switched battery positive voltage supply The battery positive voltage output circuits The ignition voltage input circuits The ignition voltage output circuits The ground circuits The class 2 serial data circuits Refer to the following: Control Module References for the applicable schematic Testing for Intermittent Conditions and Poor Connections Connector Repairs Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 8 | Replace the module that is not communicating. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 11 | |
| 9 | Install a scan tool. Turn ON the ignition, with the engine OFF. Select the Display DTCs function for the module which was not communicating. Does the scan tool display any DTCs which do not begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 10 |
| 10 | Use the scan tool in order to clear the DTCs. Did you complete the action? | Go to Step 11 | |
| 11 | Select the Display DTCs function for the modules which had U1000 or U1255 set as a current DTC. Does the scan tool display DTCs which do not begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 12 |
| 12 | Use the scan tool in order to clear the DTCs. Did you complete the action? | System OK | |
| 13 | Did you record any other DTCs for the modules which had U1000 or U1255 set as a current DTC? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 14 |
| 14 | Install a scan tool. Turn ON the ignition, with the engine OFF. Use the scan tool in order to clear the DTCs. Turn OFF the ignition for at least 5 seconds. Turn ON the ignition with the engine OFF. Select the Display DTCs function. Does the scan tool display U1000 set as a current DTC? | Go to Step 15 | Go to Diagnostic Aids |
| 15 | Replace the module which had U1000 or U1255 set as a current DTC. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | System OK | |
| IMPORTANT |
|---|
| Inspect all connectors in the serial data communications circuit. Refer to the following: Testing for Intermittent Conditions and Poor Connections Connector Repairs |
DTC U1000 and U1255
The number below refers to the step number on the diagnostic table.
- 7: The module which was not communicating on the class 2 serial data circuit may have set Loss of Communication DTCs for those modules that it was monitoring.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Data Communication Schematics Connector End View Reference: Master Electrical Component List | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | IMPORTANT: Use the control module ID number list in order to determine which module is not communicating. Test the following circuits of the module that is not communicating for an open or a short to ground: The battery positive voltage input circuits The battery positive voltage output circuits The ignition voltage input circuits The ignition voltage output circuits The switched battery positive voltage circuits Refer to the following: Control Module References for the applicable schematic Circuit Testing Wiring Repairs Did you find and correct the condition? | Go to Step 7 | Go to Step 3 |
| 3 | Turn OFF the ignition. Test the ground circuits of the module that is not communicating for an open. Refer to the following: Control Module References for the applicable schematic Circuit Testing Wiring Repairs Did you find and correct the condition? | Go to Step 7 | Go to Step 4 |
| 4 | Test the class 2 serial data circuits of the module that is not communicating for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 7 | Go to Step 5 |
| 5 | Inspect the harness connectors of the module that is not communicating for poor connections and terminal tension at the following circuits: The battery positive voltage input circuits The battery positive voltage output circuits The ignition voltage input circuits The ignition voltage output circuits The switched battery positive voltage supply circuits The ground circuits The class 2 serial data circuits Refer to the following: Control Module References for the applicable schematic Testing for Intermittent Conditions and Poor Connections Connector Repairs Did you find and correct the condition? | Go to Step 7 | Go to Step 6 |
| 6 | Replace the module which is not communicating. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 7 | |
| 7 | Install a scan tool. Turn ON the ignition, with the engine OFF. Select the Display DTCs function for the module which was not communicating. Does the scan tool display any DTCs which do not begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 8 |
| 8 | Select the Display DTCs function for the modules which had the Loss of Communications DTC set. Does the scan tool display any DTCs which do not begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 9 |
| 9 | Use the scan tool in order to clear the DTCs. Continue diagnosing or clearing the DTCs until all the modules have been diagnosed and all the DTCs have been cleared. Did you complete the action? | System OK | |
| IMPORTANT |
|---|
| Use the control module ID number list in order to determine which module is not communicating. |
DTC U1001-U1254
The data link connector (DLC) is a standardized 16 cavity connector. Connector design and location is dictated by an industry wide standard and is required to provide the following
- Scan tool power battery positive voltage at terminal 16
- Scan tool power ground at terminal 4
- Common signal ground at terminal 5
The numbers below refer to the step numbers on the diagnostic table.
- 3: A partial malfunction in the class 2 serial data circuit uses a different procedure from a total malfunction of the class 2 serial data circuit. The following modules communicate on the class 2 serial data circuit: The body control module (BCM) The electronic brake control module (EBCM) The inflatable restraint sensing and diagnostic module (SDM) The instrument panel cluster (IPC) The powertrain control module (PCM) The radio The rear seat entertainment (RSE) assembly The transfer case shift control module (TCSCM) The vehicle communication interface module (VCIM)
- 4: The following DTCs may be retrieved with a history status, but are not the cause of the present condition. U1300 U1301 U1305
- 7: A state of health DTC with a history status may be present along with a U1000 or U1255 code having a current status. This indicates that the malfunction occurred when the ignition was ON.
- 8: Data link connector terminals 2 and 5 provide the connection to the class 2 serial data circuit and the signal ground circuit respectively.
- 18: If there are no current DTCs that begin with a "U", the communication malfunction has been repaired.
- 19: The communication malfunction may have prevented diagnosis of the customer complaint.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Data Communication Schematics Connector End View Reference: Master Electrical Component List | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle |
| 2 | Does the scan tool power up? | Go to Step 3 | Go to Scan Tool Does Not Power Up |
| 3 | Turn ON the ignition leaving the engine OFF. Attempt to communicate with each module on the class 2 serial data circuit. If using a Tech 2, obtain this information using the class 2 Message Monitor feature. Does the scan tool communicate with any module on the class 2 serial data circuit? | Go to Step 4 | Go to Step 9 |
| 4 | Select the Display DTCs function for each module. If using a Tech 2, use the class 2 DTC Check feature in order to determine which modules do have DTCs set. Record all of the displayed DTCs, the DTC status and the module which set the DTC. Did you record any DTCs in the range of U1000 to U1305? | Go to Step 5 | Go to Step 8 |
| 5 | Are the history DTCs U1300, U1301 or U1305 retrieved from any module? | Go to Step 6 | Go to Step 7 |
| 6 | IMPORTANT: Turn ON the ignition, with the engine OFF, when testing for a short to voltage. Use the DMM MIN/MAX function to capture intermittent conditions. Test the class 2 serial data circuit for an intermittent short to ground or an intermittent short to voltage. Refer to the following: Testing for Intermittent Conditions and Poor Connections Circuit Testing Connector Repairs Wiring Repairs Did you find and correct the condition? | Go to Step 18 | Go to Step 7 |
| 7 | Are U1000 or U1255 the only DTCs displayed in the previously specified range? | Go to DTC U1000 and U1255 | Go to DTC U1001-U1254 |
| 8 | Diagnose the non-communicating module by using the DTC U1001-U1254 procedure for the module which is not communicating. Refer to DTC U1001-U1254 . Did you complete the action? | Go to Diagnostic System Check - Vehicle | |
| 9 | Turn OFF the ignition. Disconnect the scan tool from the data link connector (DLC). Inspect for poor connections at the DLC terminals 2 and 5. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Diagnostic System Check - Vehicle | Go to Step 10 |
| 10 | Test the DLC ground circuit at terminal 5 for an open. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Diagnostic System Check - Vehicle | Go to Step 11 |
| 11 | Repeat the following steps on the class 2 serial data circuits until the communication with body control module (BCM) is established or all modules listed below were disconnected. Disconnect the modules one by one, in the following order: Vehicle communication interface module (VCIM) Rear seat entertainment (RSE) assembly Transfer case shift control module (TCSCM) Electronic brake control module (EBCM) Inflatable restraint sensing and diagnostic module (SDM) Radio Instrument panel cluster (IPC) Powertrain control module (PCM) Turn ON the ignition, with the engine OFF. Attempt to communicate with the BCM, after each disconnected module. Does the scan tool communicate with the BCM? | Go to Step 12 | Go to Step 15 |
| 12 | IMPORTANT: Perform this step only if the suspected module is IPC or Radio. Turn OFF the ignition. If the IPC is suspected module, test the class 2 serial data circuit between IPC and TCCM for a short to ground or a short to voltage. Turn ON the ignition leaving the engine OFF when testing for a short to voltage. Refer to Circuit Testing and Wiring Repairs . If the radio is suspected module, test the class 2 serial data circuit from Radio to RSE and VCIM for a short to ground or a short to voltage. Turn ON the ignition leaving the engine OFF when testing for a short to voltage. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 18 | Go to Step 13 |
| 13 | Inspect for poor connections at the class 2 serial data circuit of the last disconnected module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 18 | Go to Step 14 |
| 14 | Replace the last disconnected module. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 18 | |
| 15 | Turn OFF the ignition. Disconnect the BCM. Test all of the BCM class 2 serial data circuits for an open, short to voltage or short to ground. Turn ON the ignition leaving the engine OFF when testing for a short to voltage. Refer to Circuit Testing and Wiring Repairs . Did you find and correct the condition? | Go to Step 18 | Go to Step 16 |
| 16 | Inspect for poor connections at the class 2 serial data circuit of the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition? | Go to Step 18 | Go to Step 17 |
| 17 | Replace the BCM. Refer to Control Module References for replacement, setup and programming. Did you complete the replacement? | Go to Step 18 | |
| 18 | Reconnect all of the disconnected modules. Install a scan tool. Turn ON the ignition, leaving the engine OFF. Wait for 10 seconds. The scan tool may require a power up reset before communication will occur due to a short on the class 2 serial data circuit. Turn OFF the scan tool prior to performing this test. Select the Display DTCs function for each module. If using a Tech 2, use the Class 2 DTC Check feature in order to determine which modules do have DTCs set. Record all of the displayed DTCs and the DTC status. Did you record any DTCs which begin with a "U" and with a current status? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 19 |
| 19 | Did you record any DTCs which do not begin with a "U"? | Go to Diagnostic Trouble Code (DTC) List - Vehicle | Go to Step 20 |
| 20 | Use the scan tool in order to clear the DTCs. Did you complete the action? | System OK | |
| IMPORTANT |
|---|
| Turn ON the ignition, with the engine OFF, when testing for a short to voltage. Use the DMM MIN/MAX function to capture intermittent conditions. |
| IMPORTANT |
|---|
| Perform this step only if the suspected module is IPC or Radio. |
Scan Tool Does Not Communicate with Class 2 Device
Scheme 9
| Callout | Component Name |
|---|---|
| IMPORTANT: The ignition switch should be in the OFF position when connecting or disconnecting the connectors to the body control module (BCM). Always disconnect the black body wiring harness connector FIRST and the gray instrument panel (I/P) wiring harness connector LAST. Always connect the black body wiring harness connector FIRST and the gray I/P wiring harness LAST. Preliminary Procedure Remove the right cowl side trim panel. Refer to Cowl Side Trim Panel Replacement . Program the body control module after replacement. Refer to Control Module References . | |
| 1 | Body Control Module Retainer (Qty: 2) |
| 2 | Body Control Module Assembly |
| IMPORTANT |
|---|
| The ignition switch should be in the OFF position when connecting or disconnecting the connectors to the body control module (BCM). Always disconnect the black body wiring harness connector FIRST and the gray instrument panel (I/P) wiring harness connector LAST. Always connect the black body wiring harness connector FIRST and the gray I/P wiring harness LAST. |
Body Control Module Replacement
See also:
• Cowl Side Trim Panel Replacement
