Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Front Seat Belt Buckle Nut | 53 N.m | 39 lb ft |
| Rear Seat Belt Anchor Plate Nut | 55 N.m | 41 lb ft |
| Rear Seat Belt Buckle Bolt | 55 N.m | 41 lb ft |
| Rear Seat Belt Buckle Nut | 55 N.m | 41 lb ft |
| Rear Seat Belt Nut | 55 N.m | 41 lb ft |
| Rear Seat Belt Retractor Bolt | 55 N.m | 41 lb ft |
| Rear Seat Belt Retractor Nut | 55 N.m | 41 lb ft |
Scheme 1
Begin the system diagnosis by reviewing the Seat Belt System Description and Operation . Reviewing the Description and Operation will help identify the correct symptom diagnostic procedure when a malfunction exists. The Description and Operation will also assist in determining if the condition described by the customer is normal system operation. Refer to Symptoms - Seat Belts in order to identify the correct procedure for diagnosing the system and where the procedure is located.
