Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Air Cleaner Outlet Duct Clamp Screw | 7 N.m | 62 lb in |
| Coolant Air Bleed Pipe Bolt/Stud | 12 N.m | 106 lb in |
| Coolant Heater Cord Retainer Bolt | 8 N.m | 71 lb in |
| Coolant Heater | 50 N.m | 37 lb ft |
| Engine Block Coolant Drain Plug | 60 N.m | 44 lb ft |
| Engine Protection Shield Bolt | 20 N.m | 15 lb ft |
| Fan Clutch Bolt | 23 N.m | 17 lb ft |
| Fan Clutch Nut | 59 N.m | 49 lb ft |
| Fan Shroud Bolt | 9 N.m | 80 lb in |
| Oil Cooler Hose Adapter Bolt | 12 N.m | 106 lb in |
| Oil Cooler Hose Bracket Bolt | 25 N.m | 18 lb ft |
| Radiator Bolt | 25 N.m | 18 lb ft |
| Surge Tank Bolt/Nut | 9 N.m | 80 lb in |
| Thermostat Housing Bolt | 15 N.m | 11 lb ft |
| Water Pump Bolt |
| First Pass | 15 N.m | 11 lb ft |
| Final Pass | 30 N.m | 22 lb ft |
Scheme 1
Scheme 1: Engine Cooling Schematics
