Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Door Check Link Bolts | 9 N.m | 7 ft lb |
| Door Check Link Nuts | 9 N.m | 7 ft lb |
| Door Handle Nuts | 9 N.m | 7 ft lb |
| Door Hinge Bolts | 25 N.m | 18 ft lb |
| Lock Actuator Bolts - Door | 9 N.m | 7 ft lb |
| Lock Striker Bolts | 27 N.m | 20 ft lb |
| Outside Mirror Bolts | 25 N.m | 19 ft lb |
| Window Clamp Bolts | 9 N.m | 7 ft lb |
| Window Regulator Bolts | 9 N.m | 7 ft lb |
| Window Run Channel Bolts | 9 N.m | 7 ft lb |
| Window Stabilizer Bolts | 9 N.m | 7 ft lb |
Fastener Tightening Specifications
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
| Callout | Component Name |
|---|---|
| 1 | DDM |
| 2 | DDM - C1 (Black) |
| 3 | DDM - C2 (Black) |
| 4 | Mirror Harness Connector - C3 (Blue) |
| 5 | Memory/Heated Seat Switch Connector - C5 (Green) |
| 6 | Mirror Harness Connector - C4 (Black) |
Scheme 7
| Callout | Component Name |
|---|---|
| 1 | FPDM |
| 2 | Mirror Harness Connector - C4 (Black) |
| 3 | Memory/Heated Seat Switch Connector - C5 (Green) |
| 4 | Mirror Harness Connector - C3 (Blue) |
| 5 | FPDM - C2 (Black) |
| 6 | FPDM - C1 (Black) |
Scheme 8
| Callout | Component Name |
|---|---|
| 1 | Driver Door |
| 2 | Outside Rearview Mirror |
| 3 | Memory/Heated Seat Switch |
| 4 | Memory/Heated Seat Switch Connector - C5 (Green) |
| 5 | Driver Door Module (DDM) |
| 6 | Fuse Block - I/P - C3 |
| 7 | Speaker - LF Door |
| 8 | Window Motor - Driver |
| 9 | Courtesy Lamp - Left Door |
| 10 | Door Latch Assembly - Driver |
| 11 | Door Latch Assembly Connector - Driver |
Scheme 9
| Callout | Component Name |
|---|---|
| 1 | Passenger Door |
| 2 | Outside Rearview Mirror |
| 3 | Passenger Door Module (PDM) |
| 4 | Door Latch Assembly - Passenger |
| 5 | Courtesy Lamp - Right Door |
| 6 | Window Motor - Front Passenger |
| 7 | Speaker - RF Door |
| 8 | Junction Block - I/P - C2 |
| 9 | Junction Block - I/P - C7 |
| 10 | Heated Seat Switch |
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Door Window Motor - LR |
| 2 | Door Window Motor Connector - LR |
| 3 | Door Harness Pass-Through Grommet |
| 4 | Door Window Switch - LR |
| 5 | Door Window Switch Connector - LR |
| 6 | Door Latch Assembly - LR |
| 7 | Speaker - LR Door |
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Right B-Pillar |
| 2 | C390 |
| 3 | G306 |
| 4 | Liftgate Lock Relay |
| 5 | Courtesy Lamp - Right B-Pillar |
| 6 | Body Harness |
Scheme 12
| Callout | Component Name |
|---|---|
| 1 | Door Lock Switch Connector - Rear |
| 2 | Door Lock Switch - Rear |
| 3 | Rear Storage Bin |
Scheme 13
| Callout | Component Name |
|---|---|
| 1 | Center High Mounted Stop Lamp (CHMSL) Connector |
| 2 | Rear Window Defogger Grid Connector |
| 3 | Rear Window Defogger Grid Connector |
| 4 | Splice S900 |
| 5 | Rear Window Wiper Module - w/Motor |
| 6 | Door Lock Actuator - Liftgate |
| 7 | Liftgate Ajar Switch - Left |
| 8 | Liftgate Ajar Switch - Right |
| 9 | Splice S902 |
| 10 | Splice S901 |
Door Latch Assembly Terminal Identification - Driver Connector Part Information 10768367 10-Way F SLD AMP (BK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 TN 294 Door Lock Actuator Unlock Control 3 GY 295 Door Lock Actuator Lock Control 4-5 - - Not Used 6 GY/BK 745 Left Front Door Ajar Switch Signal 7 - - Not Used 8 BN 1183 Left Front Door Switch Low Reference 9 L-GN 262 Driver Door Key Switch Signal 10 - - Not Used
Door Latch Assembly Terminal Identification - Front Passenger Connector Part Information 10768367 10-Way F AMP SLD (BK) Pin Wire Color Circuit No. Function 1 BK/WH 746 Right Front Door Ajar Switch Signal 2 - - Not Used 3 D-GN 1178 Right Front Door Switch Low Reference 4 L-GN 265 Passenger Door Key Switch Signal 5-6 - - Not Used 7 TN 294 Door Lock Actuator Unlock Control 8 GY 295 Door Lock Actuator Lock Control 9-10 - - Not Used
Door Latch Assembly Terminal Identification - LR Connector Part Information 10768369 6-Way F SLD AMP (BK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 TN 294 Door Lock Actuator Unlock Control 3 GY 295 Door Lock Actuator Lock Control 4 L-BU/BK 747 Left Rear Door Ajar Switch Signal 5 - - Not Used 6 BK 1150 Ground
Door Latch Assembly Terminal Identification - RR Connector Part Information 10768369 6-Way F SLD AMP (BK) Pin Wire Color Circuit No. Function 1 L-GN/BK 748 Right Rear Door Ajar Switch Signal 2 - - Not Used 3 BK 1250 Ground 4 - - Not Used 5 TN 294 Door Lock Actuator Unlock Control 6 GY 295 Door Lock Actuator Lock Control
Door Lock Actuator Terminal Identification - Liftgate Connector Part Information 12077900 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A TN 294 Door Lock Actuator Unlock Control B GY 295 Door Lock Actuator Lock Control
Door Lock Terminal Identification Switch - Rear Connector Part Information 12064998 8-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A - - Not Used B BK 2351 Ground C - - Not Used D L-BU 195 Rear Door Lock Switch Signal E-G - - Not Used H WH 194 Rear Door Unlock Switch Signal
Driver Door Module (DDM) Terminal Identification - C1 Connector Part Information 15393410 4-Way F AMP 2.8 mm Sealed (BK) Pin Wire Color Circuit No. Function 1 BN 165 Power Window Motor Left Front Down Control 2 OG 1240 Battery Positive Voltage 3 D-BU 164 Power Window Motor Left Front Up Control 4 BK 1050 Ground
Driver Door Module (DDM) Terminal Identification - C2 Connector Part Information 15398841 26-Way F AMP Lever Assist (BK) Pin Wire Color Circuit No. Function 1-2 - - Not Used 3 BN 1183 Left Front Door Switch Low Reference 4 D-BU 660 Left Front Door Courtesy Lamp Control 5-9 - - Not Used 10 GY 1690 Automatic Day/Night Mirror Signal 11 - - Not Used 12 PK 1691 Automatic Day/Night Mirror Low Reference 13 D-BU/WH 149 Courtesy Lamp - Left Front Door Supply Voltage 14 OG 4140 Battery Positive Voltage 15 L-GN 262 Driver Door Key Switch Signal 16-17 - - Not Used 18 GY/BK 745 Left Front Door Ajar Switch Signal 19 - - Not Used 20 TN 294 Door Lock Actuator Unlock Control 21 GY 295 Door Lock Actuator Lock Control 22 BN 1046 DDM Class 2 Serial Data 23-26 - - Not Used
Driver Door Module (DDM) Terminal Identification - C3 Connector Part Information 6383393-7 10-Way F 0.64 mm Unsealed AMP (BU) Pin Wire Color Circuit No. Function 1-2 - - Not Used 3 BK - Driver Mirror Heating Element Low Reference 4 PU - Mirror Sensor Low Reference 5-6 - - Not Used 7 GY - Automatic Day/Night Mirror Signal 8 PK - Automatic Day/Night Mirror Low Reference 9-10 - - Not Used
Driver Door Module (DDM) Terminal Identification - C4 Connector Part Information 6383393-5 10-Way F 0.64 mm Unsealed AMP (BK) Pin Wire Color Circuit No. Function 1 YE - Driver Folding Mirror Motor Extend Control 2 OG - Mirror Heating Element Supply Voltage 3 RD - Driver Mirror Horizontal Position Sensor Signal 4 D-GN - 5-Volt Reference 5 D-BU - Driver Mirror Vertical Position Sensor Signal 6 L-BU - Driver Folding Mirror Motor Retract Control 7 YE/WH - Driver Mirror Right/Down Motors Common 8 L-BU - Driver Mirror Motor Right Control 9 L-GN - Driver Mirror Motor Down Control 10 - - Not Used
Driver Door Module (DDM) Terminal Identification - C5 Connector Part Information 6383393-4 12-Way F AMP 0.64 mm Unsealed (GN) Pin Wire Color Circuit No. Function 1 WH/BK - Medium Heat Indicator Control 2 YE - Low Heat Indicator Control 3 GY - Back Only Select 4 L-BU - Memory/Heated Seat Backlight 5 PK - Memory 2 Switch Signal 6 - - Not Used 7 D-GN - High Heat Indicator Control 8 BK - Back Only Indicator 9 D-BU - Back and Cushion Select 10 RD - Memory 1 Switch Signal 11 BN - Memory/Heated Switch Supply Voltage 12 - - Not Used
Front Passenger Door Module (FPDM) Terminal Identification - C1 Connector Part Information 15393410 4-Way F 2.8 mm Sealed AMP (BK) Pin Wire Color Circuit No. Function 1 BN 667 Power Window Motor Right Front Down Control 2 OG 1340 Battery Positive Voltage 3 BK 1050 Ground 4 D-BU 666 Power Window Motor Right Front Up Control
Front Passenger Door Module (FPDM) Terminal Identification - C2 Connector Part Information 15398841 26-Way F AMP Lever Assist (BK) Pin Wire Color Circuit No. Function 1-4 - - Not Used 5 BK/WH 746 Right Front Door Ajar Switch Signal 6-7 - - Not Used 8 WH 156 Courtesy Lamp-Right Front Door Supply Voltage 9 - - Not Used 10 GY 295 Door Lock Actuator Lock Control 11 TN 294 Door Lock Actuator Unlock Control 12-13 - - Not Used 14 OG 4240 Battery Positive Voltage 15-18 - - Not Used 19 L-BU 661 Right Front Door Courtesy Lamp Control 20 D-GN 1178 Right Front Door Switch Low Reference 21 - - Not Used 22 TN 1047 PDM Class 2 Serial Data 23 - - Not Used 24 L-GN 265 Passenger Door Key Switch Signal 25-26 - - Not Used
Front Passenger Door Module (FPDM) Terminal Identification - C3 Connector Part Information 6383393-7 10-Way F 0.64 mm Unsealed AMP (BU) Pin Wire Color Circuit No. Function 1 RD/WH - Passenger Mirror Motor Right Control 2 WH - Passenger Mirror Right/Down Motors Common 3 YE - Passenger Folding Mirror Motor Extend Control 4 L-BU - Passenger Folding Mirror Motor Retract Control 5 - - Not Used 6 PU/WH - Passenger Mirror Motor Down Control 7 OG - Mirror Heating Element Supply Voltage 8 BK - Mirror Heating Element Low Reference 9-10 - - Not Used
Front Passenger Door Module (FPDM) Terminal Identification - C4 Connector Part Information 6383393-5 10-Way F 0.64 mm Unsealed AMP (BK) Pin Wire Color Circuit No. Function 1 D-GN - 5-Volt Reference 2 RD - Passenger Mirror Vertical Position Sensor Signal 3 PU - Low Reference 4 D-BU - Passenger Mirror Horizontal Position Sensor Signal 5-10 - - Not Used
Front Passenger Door Module (FPDM) Terminal Identification - C5 Connector Part Information 6383393-4 12-Way F AMP 0.64 mm Unsealed (GN) Pin Wire Color Circuit No. Function 1 YE - Low Heat Indicator Control 2 D-GN - High Heat Indicator Control 3 D-BU - Back Only Select 4 GY - Back and Cushion Select 5 - - Not Used 6 BN - Memory/Heated Seat Switch Supply Voltage 7 BK - Back Only Indicator Control 8 WH/BK - Medium Heat Indicator Control 9-11 - - Not Used 12 L-BU - Heated Seat Switch Backlight
Liftgate Ajar Terminal Identification Switch - Left Connector Part Information 12052644 2-Way F Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function A BK 1450 Ground B PK/BK 1303 Liftgate Ajar Switch Signal
Liftgate Ajar Terminal Identification Switch - Right Connector Part Information 12052644 2-Way F Metri-Pack 150 Series Sealed (GY) Pin Wire Color Circuit No. Function A BK 1450 Ground B PK/BK 1303 Liftgate Ajar Switch Signal
Door Lock Terminal Identification Relay - Liftgate Connector Part Information 12065978 5-Way F Metri-Pack 480/630 Series Sealed (GY) Pin Wire Color Circuit No. Function 1 WH 1304 Liftgate Lock Relay Control 2 OG 3140 Battery Positive Voltage 3 GY 295 Door Lock Actuator Lock Control 4 BK 1450 Ground 5 OG 3140 Battery Positive Voltage
Outside Rear Mirror - Driver (Driver Door Module (DDM) Terminal Identification - C3) Connector Part Information 6383393-7 10-Way F 0.64 mm Unsealed AMP (BU) Pin Wire Color Circuit No. Function 1-2 - - Not Used 3 BK - Driver Mirror Heating Element Low Reference 4 PU - Mirror Sensor Low Reference 5-6 - - Not Used 7 GY - Automatic Day/Night Mirror Signal 8 PK - Automatic Day/Night Mirror Low Reference 9-10 - - Not Used
Outside Rear Mirror - Driver (Driver Door Module (DDM) Terminal Identification - C4) Connector Part Information 6383393-5 10-Way F 0.64 mm Unsealed AMP (BK) Pin Wire Color Circuit No. Function 1 YE - Driver Folding Mirror Motor Extend Control 2 OG - Mirror Heating Element Supply Voltage 3 RD - Driver Mirror Horizontal Position Sensor Signal 4 D-GN - 5-Volt Reference 5 D-BU - Driver Mirror Vertical Position Sensor Signal 6 L-BU - Driver Folding Mirror Motor Retract Control 7 YE/WH - Driver Mirror Right/Down Motors Common 8 L-BU - Driver Mirror Motor Right Control 9 L-GN - Driver Mirror Motor Down Control 10 - - Not Used
Outside Rear Mirror - Passenger (Front Passenger Door Module (FPDM) Terminal Identification - C3) Connector Part Information 6383393-7 10-Way F 0.64 mm Unsealed AMP (BU) Pin Wire Color Circuit No. Function 1 RD/WH - Passenger Mirror Motor Right Control 2 WH - Passenger Mirror Right/Down Motors Common 3 YE - Passenger Folding Mirror Motor Extend Control 4 L-BU - Passenger Folding Mirror Motor Retract Control 5 - - Not Used 6 PU/WH - Passenger Mirror Motor Down Control 7 OG - Mirror Heating Element Supply Voltage 8 BK - Mirror Heating Element Low Reference 9-10 - - Not Used
Outside Rear Mirror - Passenger (Front Passenger Door Module (FPDM) Terminal Identification - C4) Connector Part Information 6383393-5 10-Way F 0.64 mm Unsealed AMP (BK) Pin Wire Color Circuit No. Function 1 D-GN - 5-Volt Reference 2 RD - Passenger Mirror Vertical Position Sensor Signal 3 PU - Low Reference 4 D-BU - Passenger Mirror Horizontal Position Sensor Signal 5-10 - - Not Used
Window Terminal Identification Motor - Driver Connector Part Information 12129487 2-Way F Metri-Pack 280 Series Flexlock Sealed (M-GY) Pin Wire Color Circuit No. Function A D-BU 164 Power Window Motor Left Front Up Control B BN 165 Power Window Motor Left Front Down Control
Window Terminal Identification Motor - Front Passenger Connector Part Information 12129487 2-Way F Metri-Pack 280 Series Flexlock Sealed (M-GY) Pin Wire Color Circuit No. Function A D-BU 666 Power Window Motor Right Front Up Control B BN 667 Power Window Motor Right Front Down Control
Window Terminal Identification Motor - LR Connector Part Information 12129487 2-Way F Metri-Pack 280 Series Flexlock Sealed (M-GY) Pin Wire Color Circuit No. Function A BN 669 Power Window Motor Left Rear Down Control B D-BU 668 Power Window Motor Left Rear Up Control
Window Terminal Identification Motor - RR Connector Part Information 12129487 2-Way F Metri-Pack 280 Series Flexlock Sealed (M-GY) Pin Wire Color Circuit No. Function A BN 671 Power Window Motor Right Rear Down Control B D-BU 670 Power Window Motor Right Rear Up Control
Window Terminal Identification Switch - LR Connector Part Information 12191825 8-Way F Metri-Pack 280 Series (BN) Pin Wire Color Circuit No. Function A OG 1240 Battery Positive Voltage B YE 1187 Power Window Switch Relay Left Rear Down Control C WH 1185 Power Window Switch Relay Left Rear Up Control D L-BU 2265 Power Window Lockout Left Rear Signal E BK 1150 Ground F D-BU 668 Power Window Motor Left Rear Up Control G BN 669 Power Window Motor Left Rear Down Control H BN/WH 230 Instrument Panel Lamps Dimming Control
Window Terminal Identification Switch - RR Connector Part Information 12191825 8-Way F Metri-Pack 280 Series (BN) Pin Wire Color Circuit No. Function A OG 1340 Battery Positive Voltage B D-GN 1188 Power Window Switch Relay Right Rear Down Control C GY/BK 1186 Power Window Switch Relay Right Rear Up Control D L-GN 2266 Power Window Lockout Right Rear Signal E BK 1250 Ground F D-BU 670 Power Window Motor Right Rear Up Control G BN 671 Power Window Motor Right Rear Down Control H BN/WH 230 Instrument Panel Lamps Dimming Control
