Special Tools Required
KTC trim tool set SOJATP2014*
*Available through the American Honda Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the top frame. Put on gloves to protect your hands. Wear eye protection when removing the rivets with a drill. When removing the rivets, drill holes in the rivets with a 4 mm (0.16 in.) drill. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components. This graphic shows the left side of the vehicle, repeat the procedure on the right side in the same manner.
Scheme 10
Scheme 11
- Remove the convertible top assembly (see «CONVERTIBLE TOP ASSEMBLY REPLACEMENT»(ref-221363-S05763000442006022400000) ).
- Remove the convertible top cloth in the numbered sequence.
- Install the cloth in the reverse order of removal, and note these items: To prevent wrinkles when installing the cloth, make sure the material is stretched evenly over the frame before securing the screws and rivets. After installing the cloth, reinstall the top assembly. Check the operation of the top, and inspect the cloth for wrinkles. Check that the weatherstrip fits flush. Check that each door glass contacts the weatherstrips evenly. If necessary, adjust each retainer (see «DOOR GLASS ADJUSTMENT»(ref-221360-S32056919222006022400000) ). Check for water leaks (see step 17 in «DOOR GLASS ADJUSTMENT»(ref-221360-S32056919222006022400000) ). Test-drive and check for wind noise and rattles.
