Audio System: Removal & Installation Honda S2000 AP1

Entertainment Systems 6 illustrations ~328 words

Audio Unit Removal/Installation

Note. Eject the disc before removing the audio unit to prevent damaging the CD player's load mechanism.

Scheme 5

Scheme 5: Audio Unit Removal/Installation
Scheme 5: Audio Unit Removal/Installation
  1. Make sure you have the anti-theft code for the audio system, then write down the audio presets.
  2. Remove the radio panel (see «RADIO PANEL REMOVAL/INSTALLATION»(ref-221367-S32922038512006022400000) ).
  3. Remove the four mounting screws (A).
  4. Disconnect the 20P connector (B) and the AM/FM antenna lead (C) from the audio unit.
  5. Install the audio unit in the reverse order of removal.
  6. Enter the anti-theft code for the audio system, then enter the audio presets. Set the clock.

Scheme 6

Scheme 6: Door Speaker Replacement
Scheme 6: Door Speaker Replacement
  1. Remove the door panel (see «DOOR PANEL REMOVAL/INSTALLATION»(ref-221360-S36963092642006022400000) ).
  2. Remove the three mounting screws.
  3. Disconnect the 2P connector from the speaker.
  4. Install the speaker in the reverse order of removal.

Scheme 7

Scheme 7: '06-09 models
Scheme 7: '06-09 models
  1. Remove the roll bar and upper trim assembly (see «TRIM REMOVAL/INSTALLATION - SEAT SIDE AREA»(ref-221365-S09878491562006022400000) ).
  2. Disconnect the 2P or 3P connector (A). When disconnecting the 2P connector, remove the harness clip (B).
  3. Remove the rear speaker grille (C) and the mounting screws.
  4. Carefully pull the rear speaker harness out from the roll bar and upper trim assembly, and remove the rear speaker. Be careful not break the rear speaker harness.
  5. Install the rear speaker in the reverse order of removal.

Scheme 8

Scheme 8: '02-09 models
Scheme 8: '02-09 models
  1. Remove the door panel (see «DOOR PANEL REMOVAL/INSTALLATION»(ref-221360-S36963092642006022400000) ).
  2. Remove the two screws.
  3. Disconnect the 2P connector from the tweeter.
  4. Install the tweeter in the reverse order of removal.

Scheme 9

Scheme 9: AM/FM Antenna Replacement
Scheme 9: AM/FM Antenna Replacement

Scheme 10

Scheme 10
Scheme 10
  1. Open the trunk lid.
  2. Remove the right side trunk trim panel (see «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(ref-221365-S01865343492006022400000) ).
  3. Disconnect the 2P connector (A) from the AM/FM antenna amplifier.
  4. Remove the AM/FM antenna mast (A).
  5. Remove the antenna nut (B) and spacer (C).
  6. Disconnect the AM/FM antenna lead (D) from the AM/FM antenna amplifier (E).
  7. Loosen the mounting bolt from the AM/FM antenna amplifier.
  8. Remove the AM/FM antenna amplifier.
  9. Install the AM/FM antenna in the reverse order of removal.
