Audio System: Diagnosis Honda S2000 AP1

Entertainment Systems 3 illustrations ~1277 words

Symptom Troubleshooting Index

SymptomDiagnostic procedureAlso check for
Poor AM or FM radio reception or interferenceSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Antenna lead short or open in the wire
Audio unit power switch will not turn on (No information display and no sound)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) )
Audio unit power switch will not turn offSymptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF )
No sound is heard from the speaker(s) (display is normal)Symptom Troubleshooting (see No sound is heard from the speaker(s) (display is normal) )
Audio system sound is weak or distorted (display is normal)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) )
Audio unit button illumination does not workSymptom Troubleshooting (see AUDIO UNIT BUTTON ILLUMINATION DOES NOT WORK )
Radio preset memory is lostSymptom Troubleshooting (see RADIO PRESET MEMORY IS LOST )Battery condition Battery cable condition
Audio disc does not ejectSymptom Troubleshooting (see AUDIO DISC DOES NOT EJECT )
Volume does not changeSymptom Troubleshooting (see Volume does not change )
Radio tuner does not change stationsSymptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS )
Audio disc does not loadSymptom Troubleshooting (see Audio disc does not load )
Audio disc does not playSymptom Troubleshooting (see AUDIO DISC DOES NOT PLAY )
Audio disc skipsSymptom Troubleshooting (see Audio disc skips )Tire pressure (over-inflated), disc smudged, dirty, or scratched
Audio remote switch does not work properlySymptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY )

SYMPTOM TROUBLESHOOTING INDEX

Sound Quality Diagnosis

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Use the following tests to check sound quality.

Note. Before beginning the following tests, write down the customer's bass, treble, fader and balance settings, then set them to their center positions for the testing.

Phase Test

Do this test to confirm proper speaker phasing.

  1. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
  2. Play track No. 2 (phase) at a normal, or slightly higher than normal, volume level.
  3. The voice should sound centered, and focused when it is in-phase.
  4. The voice should sound diffused, and have less bass when it is out of phase. If the voice changes from in-phase to out of phase as indicated by the prompt, the phasing is correct. Go to electrical noise test (see «ELECTRICAL NOISE TEST»(ref-351956-S26899802682009122900000) ). If the voice always sounds out of phase, phasing is not correct. Check for: Crossed speaker wires Faulty audio unit Special Tools Required Diagnostics CD 07AA2-SDBA100

Electrical Noise Test

Do this test to check for electrical noise being induced into the audio system.

Note. Electrical noise may be caused by outside sources that cannot be handled by the audio system. Make sure you remove any cell phones and/or turn off any aftermarket device before beginning this test.

  1. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
  2. Play track No. 4 (digital zero) at a normal, or slightly higher than normal, volume level.
  3. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  4. Play track No. 5 (near digital zero) at a normal, or slightly higher than normal, volume level.
  5. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  6. Play track No. 6 (SNR) at a normal, or slightly higher than normal, volume level.
  7. Operate any electrical device that may create electrical noise in the audio system, including starting the engine. If no abnormal noise is heard, go to individual speaker test. If the noise is present only during the SNR track, replace the audio unit. If the noise is heard during the digital zero or near digital zero track, check for: Poor ground for the audio unit, engine or battery cable Pinched or shorted speaker or amplifier wire Faulty audio unit Other faulty components causing excessive electrical noise (ignition coils, alternator, door lock actuators, etc.). Disconnect any suspect components, and then replay the tracks that were originally noisy. If the noise is gone, check the component's circuit and the component. Special Tools Required Diagnostics CD 07AAZ-SDBA100

Individual Speaker Test

Do this test to identify a faulty speaker.

  1. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
  2. Play track No. 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level.
  3. Listen to each speaker for poor sound compared to the other speakers. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If the sound quality produced by a specific speaker is poor, substitute it with a known-good speaker (see «AUDIO UNIT REMOVAL/INSTALLATION»(ref-351956-S28419735862009122900000) ). If the poor sound quality continues, go to the sound balance test (see «Sound Balance Test»(ref-351956-S18637632432009122900000) ). If the sound quality is OK, go to the sound balance test (see «Sound Balance Test»(ref-351956-S18637632432009122900000) ).

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Sound Balance Test

Perform this test to identify a faulty channel or speaker.

  1. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player.
  2. Confirm the bass and treble are set to the center positions.
  3. Play track No. 3 (pink noise) at a normal, or slightly higher then normal, volume level.
  4. A static type sound should be heard through all speakers.
  5. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) into the CD player of a known-good vehicle.
  6. Set the bass and treble to the center position.
  7. Play track No. 3 (pink noise) all the same level as was played in step 3.
  8. Compare the sounds made by the two vehicles. If the sounds made by the two vehicles are very similar, go to the Frequency Sweep Test (see «FREQUENCY SWEEP»(ref-351956-S12581862402009122900000) ). If the sound does not have as much bass, check the speaker circuit. If the sound does not have enough hiss, check the tweeters and their circuits.

Special Tools Required

Diagnostics CD 07AAZ-SDBA100

Seek Stop Test

Do this test to check the performance of the audio unit's AM and FM reception. Refer to symptom troubleshooting: audio sound weak or distorted, or no sound is heard from the speaker(s) (display is normal) (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF ) before continuing with this test.

Note. Window tint, aftermarket theft-recovery devices and other aftermarket accessories may reduce radio reception. Changes in cloud cover and other atmosphere conditions will affect the ability of the audio unit to receive radio signals.

  1. Park the customer's vehicle in an open area away from buildings or other obstructions.
  2. Park a known-good vehicle (same year, model, and trim level) next to the customer's vehicle, facing the same direction.
  3. Start the engine in the customer's vehicle, and turn on the radio.
  4. Set the FM receiver to 87.7 MHz.
  5. Press the Seek + button and record the first station that the audio unit locks onto.
  6. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 5 is reached again.
  7. Set the AM receiver to 530 kHz.
  8. Press the Seek + button, and record the first station that the audio unit locks onto.
  9. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 8 is reached again.
  10. Turn the ignition switch to LOCK (0).
  11. Start the engine in the known-good vehicle, and then perform steps 4 thru 10 on the known-good vehicle.
  12. Compare the number of stations received in steps 6 and 9 in the customer's vehicle with the number of stations received in the known-good vehicle. If the number of stations received is the same, or within 10 %, the audio unit's tuner performance is OK. The problem may be atmospheric conditions, multi path interference, or other obstructions to the radio signal. If the customer's vehicle receives fewer stations by at least 10 %, go to step 2 of poor AM or FM radio reception or interference (see «SYMPTOM TROUBLESHOOTING»(ref-351956-S19539684602009122900000) ).

Scheme 2

Scheme 2: Audio Remote Switch Replacement
  1. Remove the instrument panel (see «INSTRUMENT PANEL REMOVAL/INSTALLATION»(ref-221367-S21557212092006022400000) ).
  2. Disconnect the 6P connector (A) from the audio remote switch.
  3. Remove the three mounting screws (B), and pull out the engine start switch (C).
  4. If necessary, replace the bulb(s) (D).
  5. Install the audio remote switch in the reverse order of removal.

Scheme 3

Scheme 3: Audio Remote Switch Test

Scheme 4

Scheme 4
  1. Remove the instrument panel (see «INSTRUMENT PANEL REMOVAL/INSTALLATION»(ref-221367-S21557212092006022400000) ).
  2. Disconnect the 6P connector from the audio remote switch (see «AUDIO REMOTE SWITCH REPLACEMENT»(ref-351956-S37555081942009122900000) ).
  3. Measure resistance between terminals No. 5 and No. 6 in each switch position according to the table. If the resistance is not as specified, replace the audio remote switch. RESISTANCE CHART Position Resistance (No button pressed) About 10 kohms. VOL. UP (+) About 263 ohms VOL. DOWN (-) About 512 ohms CH About 1.1 kohms MODE About 2.5 kohms
  4. Reconnect audio remote switch 6P connector.
  5. Check for continuity between the terminals in each switch position according to the table. If the continuity is not as specified, replace the illumination bulb(s) or the audio remote switch.
  6. With the MUTE switch ON, check for continuity between terminals No. 2 (+) and No. 1 (-). There should be continuity. If there is no continuity, replace the audio remote switch.
