Fuse & Circuit Breaker Identification

  1. 1 - 10 Amp Active Torque Transfer System Unit (On Type SH)
  2. 2 - 7.5 Amp Starter Signal
  3. 3 - Not Used
  4. 4 - 10 Amp ACG-S
  5. 5 - 10 Amp RR Speaker
  6. 6 - 15 Amp Heated Seats (Canada)
  7. 7 - 30 Amp Moon Roof
  8. 8 - 7.5 Amp Daytime Running Lights (Canada)
  9. 9 - 7.5 Amp Power Mirror, ABS (ATTS)
  10. 10 - 15 Amp Taillight
  11. 11 - 7.5 Amp Rear Defroster Relay
  12. 12 - 7.5 Amp Daytime Running Lights Unit (Canada)
  13. 13 - 15 Amp Meter
  14. 14 - 15 Amp EAT ECU (TCM), ECU (ECM), Cruise Control
  15. 15 - 20 Amp Front Left Power Window
  16. 16 - 20 Amp Front Right Power Window
  17. 17 - 30 Amp Wiper
  18. 18 - 7.5 Amp ACC
  19. 19 - Not Used
  20. 20 - Not Used
  21. 21 - 15 Amp Fuel Pump
  22. 22 - 10 Amp SRS
  23. 23 - 15 Amp Spare Fuse
  24. 24 - 7.5 Amp Spare Fuse
  25. 25 - 10 Amp Spare Fuse
  26. 26 - 20 Amp Spare Fuse
  27. 27 - 30 Amp Spare Fuse
  28. 28 - 7.5 Amp Active Torque Transfer System (On Type SH)
  29. 29 - Not Used

Scheme 1

Scheme 1: UNDERHOOD FUSE & RELAY PANEL IDENTIFICATION
  1. 1 - 40 Amp Main Fuse (Power Window)
  2. 2 - 50 Amp Main Fuse (Fuse Box)
  3. 3 - 40 Amp Main Fuse (Heater Motor)
  4. 4 - 40 Amp Main Fuse (Rear Defroster)
  5. 5 - 50 Amp Main Fuse (Ignition Switch)
  6. 6 - Not Used
  7. 7 - 100 Amp Main Fuse (Battery)
  8. 8 - 30 Amp Main Fuse (ABS Motor)
  9. 9 - 20 Amp Cooling Fan
  10. 10 - 15 Amp Interior Lights
  11. 11 - 20 Amp Condenser Fan
  12. 12 - 10 Amp Door Lock
  13. 13 - 7.5 Amp Clock, Radio
  14. 14 - 20 Amp Small Light
  15. 15 - 15 Amp Stop, Horn
  16. 16 - 20 Amp ABS +B
  17. 17 - 10 Amp Hazard
  18. 18 - Not Used
  19. 19 - 7.5 Amp ABS Unit
  20. 20 - 20 Amp Left Headlight
  21. 21 - 20 Amp Right Headlight
