Wiring diagram: Ground distribution — Ground distribution circuit Honda Pilot II

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• A/C
• A/T Clutch Pressure Control Solenoid Valve A
• A/T Clutch Pressure Control Solenoid Valve B
• A/T Clutch Pressure Trans- Control Mission Solenoid Range Valve C Switch
• A/T Gear Position Indicator Panel Light/Park Pin
• Automatic Dimming Inside Interior Light Mirror Switch
• Automatic Dimming Inside Mirror Connector 1
• Automatic Lighting Control Unit
• Auxiliary Under-Hood Fuse/Relay Box
• Back Up Light
• Battery
• Brake Fluid Level Switch
• Brake Side Back-Up Light/ Marker Light Taillight Light
• Brake Side Light/ Marker Taillight Light
• Cargo Area Accessory Power Socket Relay
• Climate Control
• Climate Control Unit
• Cmp Sensor
• Console Accessory Power Socket A
• Console Accessory Power Socket A Relay
• Console Accessory Power Socket B
• Console Accessory Power Socket B Relay
• Console Box Light
• Cruise Control Combination Switch
• Driver'S Door Hatch Glass Opener Switch
• Driver'S Driver'S Door Lock Power Actuator/ Window Knob Motor Switch
• Driver'S Driver'S Seat Heater Seat Relay Heater
• Driver'S Power Lumbar Support Switch
• Driver'S Power Seat
• Driver'S Power Seat Adjustment Switch
• Driver'S Seat Belt Buckle Switch
• Driver'S Seat Heater Switch
• Driver'S Vanity Mirror Light
• Driving Position Memory Switch
• EGR Valve, EGR Valve Position Sensor PCM
• Engine
• Engine Mount Control Unit
• Equipped Audio- Ac Havc Inverter Display Unit Unit
• Fan Control Relay
• Front A/F Sensor
• Front Accessory Power Socket
• Front Accessory Power Socket Relay
• Front Blower Condenser Power Transistor Fan Motor
• Front Blower Motor Relay
• Front Hands- Passenger'S Freelink Seat Control Heater Unit Switch
• Front Individual Map Lights
• Front Passenger'S Power Window Switch
• Front Passenger'S Seat Heater
• Front Passenger'S Seat Heater Relay
• Front Passenger'S Vanity Mirror Light
• Front Secondary
• Hatch Hatch Tailgate Glass Glass Release Opener Opener Actuator Actuator Switch
• Homelink Unit
• Horn Switch
• Hvac Control Unit
• Ignition Coil No.1
• Ignition Coil No.6
• Ignition Ignition Coil Coil No.4 No.5
• Ignition Ignition Coil No.2 Coil No.3
• Ignition Key Switch/ Ley Light
• J/C
• Knock Ckp Sensor Sensor Shield
• Left Front Left Fog Side Marker Light Light
• Left Front Turn Signal/ Parking Light
• Left Headlight
• Left Power Mirror
• Left Rear Left Rear Power Door Lock Window Actuator/ Switch Knob Switch
• Left Second Row Seat Heater
• Left Second Row Seat Heater Relay
• Left Taillight Assembly
• Manual A/C
• Mes Gauge Control Module Connector
• Microphone
• Micu Service Check Connector
• Mission
• Moonroof
• Moonroof Control Unit
• Moonroof Switch
• Navigation
• Navigation Interface Display Dial Unit
• Navigation Unit
• P-Gnd P-Gnd P-Gnd
• Park-Pin Switch Switch
• Parking And Back-Up Sensor Control Unit
• Power Mirror Defoggers
• Power Mirror Switch
• Power Seat Control Unit
• Power Tailgate Control Unit
• Power Tailgate Rear Inside Window Beeper Defogger
• Power Window Master Switch
• Psp Switch
• Rear A/F Sensor, Rear Secondary
• Rear Climate Control Panel
• Rear Controller And Screen
• Rear Fuse/Relay Box
• Rear Rear Blower Blower Power Motor Transistor Relay
• Rear Window Wiper Left Motor License Plate Light
• Rear Window Wiper Motor Relay 1
• Rear Window Wiper Motor Relay 2
• Rearview Monitor Mirror
• Right Front Turn Signal/ Parking Light
• Right Headlight
• Right Power Mirror
• Right Right Rear Rear Door Lock Power Actuator/ Window Knob Switch Switch
• Right Second Row Seat Heater Relay
• Right Taillight Assembly
• Rocker Arm Oil Control Solenoid A
• Rocker Arm Oil Control Solenoid B
• Roof Console
• S-Gnd S-Gnd
• Shield Shield
• Steering Wheel
• Stereo Amplifier
• Tailgate Cargo Area Outer Accessory Handle Power Socket Switch
• Tailgate Latch Switch
• Tpms Control Unit
• Trailer Connector
• Trailer Electric Brake Unit
• Trailer In-Line Connector
• Trailer Lighting Control Unit
• Trailer Taillight Relay Trailer
• Trans- Mission
• Turn Signal Light/ Taillight
• Under-Dash Fuse/Relay
• Under-Dash Fuse/Relay Box
• Under-Hood Fuse/Relay Box
• Vsa Modulator Control Unit
• Vsa Off Switch
• Vtm-4 Control Unit
• W/O Front Passenger'S Power Seat
• W/O Navigation
• W/O Power Tailgate
• W/O Touring
• Washer Windshield Fluid Washer Level Motor Switch
• Windshield Wiper Motor
• Yaw Rate, Lateral, Longitudinal Acceleration Sensor
