Computer data lines — Ga-net bus/ga-net audio circuit Honda Pilot II
All systems — 30 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines 3
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 3.5l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission 2
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 10
Click a component to highlight it on every diagram it appears on.
