Scheme 53
Overview
The electrical compass shows the azimuth (direction) information in the 8-directions (N, NE, E, SE, S, SW, W, NW) to the audio-HVAC display unit via the audio unit.
Scheme 54
Starting Operation
When the ignition switch is turned to ACCESSORY (I), the electrical compass unit begin to communicate with the audio unit. Then turn the ignition switch to ON (II), the self-test mode begins automatically.
The self-test function checks for the current voltage, non-volatile memory (NVM), and ROM status in the electrical compass unit. If the unit detects a malfunction while in the self-test, it indicates a malfunction by flashing compass information segments (CAL and NW) in the audio-HVAC display unit (see SYMPTOM TROUBLESHOOTING INDEX ).
The electrical compass unit send the azimuth (direction) information to the audio unit. The electrical compass unit receive the VSP signal from the gauge control module via the audio unit. The azimuth information is fixed while parked.
Self-Calibration
The electrical compass unit has a self-calibration function. It detects and compensates for magnetic anomalies caused by bridges, subways and large steel structures. When the vehicle leaves an area with a strong magnetic interference field (2400 mG or more), the electrical compass unit automatically begins calibrating. If needed, you can calibrate the compass.
