12 Volt Battery: Other Honda Pilot II

Ordering Information

To order an Electrical System Analyzer, go to the Honda Tool and Equipment catalog on the iN, or call 888-424-6857.

Software Version

Make sure you have the latest software in the ED-18. To check the version on the do this

1. Press the POWER button.
2. Read the version number on the screen. It should appear for about 3 seconds.
3. Or you can select: Language> Options> Info> Version. The version number will appear near the top of the screen.

Write down the version number, then call Midtronics at 800-776-1995 to verify you have the latest software version.

1. Press the POWER button.
2. Read the version number on the screen. It should appear for about 5 seconds.
3. Or from the Main Menu, select: Options> Info> I Version. The version number will appear on the screen. Write down the version number, then call Midtronics at 800-776-1995 to verify you have the latest software version.

Using the ED-18 Battery Tester

Note. For set up, customizations, and other available features, refer to the user's manual.

1. Connect the leads to the positive and negative terminal of the battery.
2. Use the arrow keys to select the battery test, then press ENTER, then follow the prompts. NOTE: Make sure to enter the correct cold cranking ampere rating of the battery. If the number is not entered correctly, the result will not be accurate.
3. Here are the five possible battery conditions

1. Good-Battery-The battery has at least 60 percent of its charge and requires no action.
2. Good-Recharge-The battery condition appears to be good, but charging is recommended and then retest. See your battery charger's instructions to fully charge the battery, then recheck. Do not charge the battery using the vehicle's alternator.
3. Charge and Retest-The battery condition is not known because its charge is too low. Recharge the battery, then retest. See your battery's instructions to fully charge the battery, then recheck. Do not charge the battery using the vehicle's alternator.
4. Replace Battery-The battery condition is poor. Replace it.
5. Bad Cell-There is a problem with the battery. Replace it.

Disconnection

Note. Some system store data in memory (including seat position, mirror position, etc) is lost when the battery is disconnected. Do the following procedures before disconnecting the battery.

1. Make sure you have the anti-theft code(s) for the audio system and/or navigation system (if equipped). NOTE: For some models, it may be necessary to write down the audio the presets (AM and FM), because the audio unit dose not retain the presets after the battery is disconnected.
2. Write down the XM audio presets (if equipped).
3. Make sure the ignition switch is in LOCK (0).
4. Disconnect and isolate the negative cable from the battery. NOTE: Always disconnect the negative battery cable from the battery first.
5. Disconnect the positive cable from the battery.

Reconnection

Note. Some system store data in memory (including seat position, mirror position, etc) is lost when the battery is disconnected. Do the following procedures to restore the system back to normal operation. Be sure to close the power tailgate before reconnecting the battery.

Scheme 65

1. Clean the battery terminals.
2. Test the battery (see «BATTERY TEST»(ref-333608-S35061161722009072100000) ).
3. Reconnect the positive cable (A) to the battery (B) first, then reconnect the negative cable (C) to the battery. NOTE: Always connect the positive cable to the battery first.
4. Apply multipurpose grease to the terminals to prevent corrosion.
5. Enter the anti-theft code(s) for the audio system and/or navigation system (if equipped).
6. Enter the audio presets (if applicable), and enter the XM audio presets (if equipped).
7. Set the clock (for vehicles without navigation).
