Power Windows: Maintenance Honda Pilot I

Windows 8 illustrations ~2260 words

Resetting the Power Window Control Unit

Resetting the power window control unit is required after performing the following procedures

  1. Disconnecting the battery.
  2. Removing the No. 1 (20 A) fuse in the driver's under-dash fuse/relay box.
  3. Disconnecting the 18P connector from the power window control unit.
  4. Removing the window regulator, glass or glass run channel.
  5. Disconnecting the driver's door wire harness.
  1. Turn the ignition switch OFF, then back ON (II).
  2. Move the driver's window all the way down by holding the driver's switch firmly down to the second detent, when the window reaches the bottom, hold the driver's window switch in the AUTO DOWN position for 2 seconds.
  3. Move the driver's window all the way up without stopping by holding the driver's switch firmly up to the second detent, when the window reaches the top, hold the driver's window switch in the AUTO UP position for 2 seconds.

If the window does not work in AUTO, reset the power window master switch according to the above procedures again.

Scheme 11

Scheme 11: Circuit Diagram

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15: Passenger's Unit

Scheme 16

Scheme 16

Scheme 17

Scheme 17
  1. Before testing the power window control functions, troubleshoot the multiplex control system (see «TROUBLESHOOTING»(ref-243369-S38123892792006082300000) ).
  2. Remove the passenger's multiplex control unit from the passenger's under-dash fuse/relay box, and disconnect its connector.
  3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4 .
  4. With the passenger's multiplex control unit still disconnected, make these input tests at the passenger's under-dash fuse/relay box socket. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5 . PASSENGER'S MULTIPLEX CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained A24 Fuse/relay box socket Under all conditions Check for voltage to ground: There should be battery voltage. Blown No. 13 (7.5 A) fuse in the passenger's under-dash fuse/relay box Faulty passenger's under-dash fuse/relay box A12 Fuse/relay box socket Jump A12 to battery voltage The power window relay should make a click sound and there should be 12 V at fuses 7, 8 and 16. Faulty power window relay Poor ground (G651) Blown No. 51 (40 A) fuse in the under-hood fuse/relay box An open in the wire A8 Fuse/relay box socket Under all conditions Check for continuity to ground: There should be continuity. Poor ground (G651) An open in the wire A19 Fuse/relay box socket With power window main switch ON, jump A12 and A19 to battery voltage Check the front passenger's window motor operation: The window should go down. Poor ground (G601, G651) Blown No. 8 (20 A) fuse in the passenger's under-dash fuse/ relay box Faulty power window master switch Faulty front passenger's switch Faulty window motor An open in the wire A18 . A12 Fuse/relay box socket With power window main switch ON, jump A18 and A12 to battery voltage Check the front passenger's window motor operation: The window should go up. A7 . A12 Fuse/relay box socket With power window main switch ON, jump A7 and A12 to battery voltage Check the right rear window motor operation: The window should go down. Poor ground (G601, G651) Blown No. 16 (20 A) fuse in the passenger's under-dash fuse/ relay box Faulty power window master switch Faulty right rear switch Faulty window motor An open in the wire A6 Fuse/relay box socket With power window main switch ON, jump A6 and A12 to battery voltage Check the right rear window motor operation: The window should go up. C16* WHT/ORN Front passenger's door open Check for voltage to ground: There should be less than 1 V. Faulty front passenger's door switch An open in the wire A short to ground Front passenger's door closed Check for voltage to ground: There should be 5 V or more. * : Reconnect the connector to the passenger's multiplex control unit
  5. Remove the driver's multiplex control unit from the driver's under-dash fuse/relay box.
  6. Inspect all connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 7 .
  7. With the driver's multiplex control unit still disconnected, make these input tests at the driver's under-dash fuse/relay box socket. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 8 . DRIVER'S MULTIPLEX CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained A12 Fuse/relay box socket Under all conditions Check for voltage to ground: There should be battery voltage. Blown No. 13 (7.5 A) fuse in the passenger's under-dash fuse/relay box An open in the wire A14 Check for continuity to ground: There should be continuity. Poor ground (G401) An open in the wire
  8. With the driver's multiplex control unit still disconnected, make these input tests at the driver's under-dash fuse/ relay box socket.
  9. Remove the passenger's multiplex control unit from the passenger's under-dash fuse/relay box and connect fuse/ relay box socket terminal A12 to battery voltage. This turns the power window relay on. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 10 . PASSENGER'S MULTIPLEX CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained A19 Fuse/relay box socket With power window main switch ON, jump A6 to battery voltage Check the left rear window motor operation: The window should go down. Poor ground (G601, G651) Blown No. 7 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty left rear switch Faulty power window master switch An open in the wire A7 Fuse/relay box socket With power window main switch ON, jump A18 to battery voltage Check the left rear window motor operation: The window should go up. Poor ground (G601, G651) Blown No. 7 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty left rear switch Faulty power window master switch An open in the wire E3 GRN/ORN Driver's door open Check for voltage to ground: There should be less than 1 V. Faulty driver's door switch An open in the wire Driver's door closed Check for voltage to ground: There should be 5 V or more. Faulty driver's door switch Short to ground in the wire * : Reconnect the connector to the passenger's multiplex control unit
  10. Remove the door multiplex control unit from the driver's door, and disconnect its connectors.
  11. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 12 .
  12. Reconnect the connector to the door multiplex control unit, and make these input tests at the connectors. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 13 . NOTE: For the terminals A4, A5, A10, A11, and A14, refer to the power window control unit input test (see «POWER WINDOW CONTROL UNIT INPUT TEST»(ref-243312-S30083918622006082300000) ). DOOR MULTIPLEX CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained A1 WHT/RED Under all conditions Check for voltage to ground: There should be battery voltage. Blown No. 13 (7.5 A) fuse in the passenger's under-dash fuse/relay box Faulty passenger's fuse/relay box An open in the wire A2 WHT/YEL Ignition switch ON (II) with power window relay jumped Check for voltage to ground: There should be battery voltage. Blown No. 7 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty passenger's multiplex control unit Faulty power window relay Poor ground (G601) An open in the wire A12 BLK Under all conditions Check for voltage to ground: There should be less than 1 V. Poor ground (G401, G601) An open in the wire A13 B1 A20 WHT/RED Ignition and main switch ON Check for voltage to ground: There should be battery voltage. An open in the wire Blown No. 7 (20 A) fuse in the passenger's under-dash fuse/relay box B2 WHT/RED
  13. If all the input tests prove OK, one of the control units must be faulty. Substitute a known-good control unit for the one that is most likely at fault using «TERMINALS REFERENCE TABLE»(ref-243312-S27628275222006082300000) , then check the system. If the system works properly, the original control unit is faulty; replace it. If there is still a malfunction, substitute a known-good control unit for the next most likely unit to be at fault, and recheck. If the system works properly, the original unit is faulty; replace it. TERMINALS REFERENCE TABLE Affected window Most likely control unit Driver's window Door multiplex control unit or power window control unit Front passenger's window from power window master switch Passenger's multiplex control unit Right rear window from power window master switch Passenger's multiplex control unit Left rear window from power window master switch Driver's multiplex control unit

Scheme 18

Scheme 18: Power Window Control Unit Input Test
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-243346-S33342185312006082300000) ), but leave the driver's door subharness connector connected to the driver's door wire harness.
  2. Disconnect the 18P connector (A) from the power window control unit (B).
  3. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4 .
  4. Reconnect the connector to the control unit, and make these input tests at the connectors. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 5 . CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained 1 BLK Under all conditions Measure the voltage to ground: There should be less than 1 V. Poor ground (G601) An open in the wire 8 GRN Under all conditions (1) Measure the voltage to ground: There should be battery voltage. Blown No. 1 (20 A) fuse in the driver's under-dash fuse/relay box An open in the wire 7 WHT/YEL Ignition switch ON (II) and passenger's multiplex terminal A12 connected to battery voltage Measure the voltage to ground: There should be battery voltage. Blown No. 7 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty power window relay An open in the wire 13 BLK/WHT Ignition switch ON (II) and driver's window switch UP Measure the voltage to ground: There should be battery voltage. Faulty power window master switch An open in the wire 11 YEL/GRN Ignition switch ON (II) and driver's window switch AUTO UP Ignition switch ON (II) and driver's window switch AUTO DOWN 15 RED/GRN Ignition switch ON (II) and driver's window switch DOWN 17 WHT Ignition switch ON (II) Measure the voltage between the No. 17 (+) and No. 9 (-) terminals: There should be battery voltage. Faulty power window motor Faulty pulser An open in the wire Faulty power window control unit 9 BLK 5 YEL While operating the driver's window switch Measure the voltage between the No. 5 (+) and No. 9 (-) terminals: There should be pulse voltage 0-5 V (an analog voltmeter needle should move back and forth alternately; a digital voltmeter should show the average voltage of about 2.5 V). 16 BLU While operating the driver's window switch Measure the voltage between the No. 16 (+) and No. 9 (-) terminals: There should be pulse voltage 0-5 V (an analog voltmeter needle should move back and forth alternately; a digital voltmeter should show the average voltage of about 2.5 V). 17 WHT Ignition switch ON (II) Measure the voltage the voltage between terminal No. 17 and body ground: There should be battery voltage. Faulty power window control unit Short to ground Faulty power window motor (1) Make sure the driver's door subharness is connected (2) Passenger's multiplex control unit connector
  5. Disconnect the 18P connector from the power window control unit, then make these input tests at the connector. If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the control unit must be faulty; replace it. POWER WINDOW CONTROL UNIT Cavity Wire Test condition Test: Desired result Possible cause if result is not obtained 4 BLU/GRN Driver's window switch DOWN Check for continuity to ground: There should be continuity. Poor ground (G401, G601) Faulty power window master switch An open in the wire 4 BLU/GRN Driver's window switch OFF Check for continuity between the No. 4 and No. 14 terminals: There should be continuity. Faulty power window master switch An open in the wire 14 BLU/ORN 3 RED/BLU Connect the battery power to the No. 12 (+) and ground the No. 3 (-) terminals Check for driver's window motor operation: It should run (the window moves down). Faulty power window motor An open in the wire 12 RED/YEL Connect the battery power to the No. 3 (+) and ground the No. 12 (-) terminals Check for driver's window motor operation: It should run (the window moves up). Faulty power window motor An open in the wire
