A/t Interlock System: Removal & Installation Honda Pilot I

Automatic Trans 1 illustration ~124 words

Shift Lock Solenoid Replacement

SRS components are located in this area. Review the SRS components locations, precautions and procedures in 2003 AIR BAG RESTRAINT SYSTEMS or 2004 AIR BAG RESTRAINT SYSTEMS before performing repairs or service.

Scheme 387

Scheme 387: Shift Lock Solenoid Replacement
Scheme 387: Shift Lock Solenoid Replacement
  1. Remove the shift lever assembly (see «SHIFT LEVER REMOVAL»(ref-174017-S07766438462005050600000) ).
  2. Remove the screws (A) securing the shift lock solenoid (B), then remove the shift lock solenoid.
  3. Install the shift lock solenoid plunger (C) and plunger spring (D) in the new shift lock solenoid.
  4. Install the shift lock solenoid by aligning the joint of the shift lock solenoid with the tip of the shift lock extension (E), then tighten the screws.
  5. Install the shift lever assembly (see «SHIFT LEVER INSTALLATION»(ref-174017-S02810912332005050600000) ).
