A/t Interlock System: Diagnosis Honda Pilot I

Automatic Trans 3 illustrations ~417 words

Key Interlock Solenoid/Switch Test

SRS components are located in this area. Review the SRS components locations, precautions and procedures in 2003 AIR BAG RESTRAINT SYSTEMS or 2004 AIR BAG RESTRAINT SYSTEMS before performing repairs or service.

Scheme 384

Scheme 384: Key Interlock Solenoid/Switch Test
Scheme 384: Key Interlock Solenoid/Switch Test
  1. Remove the steering lower cover (see «STEERING COLUMN REMOVAL & INSTALLATION»(ref-174024-S02398063972005041500000) ).
  2. Disconnect the key switch connector (7P) from the steering lock assembly.
  3. Check for continuity between the No. 5 and No. 7 terminals when the key is pushed, and check for no continuity when the key is released.
  4. Check that the key cannot be removed with power connected to the No. 7 terminal and ground connected to the No. 3 terminals. If the key cannot be removed, the key interlock solenoid is OK. If the key can be removed, replace the steering lock assembly (the key interlock solenoid is not available separately).

Shift Lock Solenoid Test

SRS components are located in this area. Review the SRS components locations, precautions and procedures in 2003 AIR BAG RESTRAINT SYSTEMS or 2004 AIR BAG RESTRAINT SYSTEMS before performing repairs or service.

Scheme 385

Scheme 385: Shift Lock Solenoid Test
Scheme 385: Shift Lock Solenoid Test
  1. Remove the steering column upper cover (see «STEERING COLUMN REMOVAL & INSTALLATION»(ref-174024-S02398063972005041500000) ).
  2. Disconnect the shift lock solenoid 2P connector.
  3. Connect the No. 1 terminal of the shift lock solenoid connector to the battery positive terminal, and connect the No. 2 terminal to the battery negative terminal.
  4. Check that the shift lever can be moved from the P position. Release the battery terminals from the shift lock solenoid connector. Move the shift lever back to the P position, and make sure it locks.
  5. Check that the shift lock releases when the release lever is pushed, and check that it locks when the release lever is released.
  6. If the solenoid does not work, replace it.

Park Pin Switch Test

SRS components are located in this area. Review the SRS components locations, precautions and procedures in 2003 AIR BAG RESTRAINT SYSTEMS or 2004 AIR BAG RESTRAINT SYSTEMS before performing repairs or service.

Scheme 386

Scheme 386: Park Pin Switch Test
Scheme 386: Park Pin Switch Test
  1. Remove the steering column covers (see «STEERING COLUMN REMOVAL & INSTALLATION»(ref-174024-S02398063972005041500000) ).
  2. Disconnect the park pin switch connector.
  3. Shift the shift lever into the P position, then check for continuity between the No. 1 and No. 3 terminals. There should be no continuity.
  4. Move the shift lever out of the P position, and check for continuity the terminals. There should be continuity.
  5. If the park pin switch is faulty, replace the shift lever assembly. The park pin switch is not available separately.
