Engine Controls - Tests W/codes - 3.2L: Diagnosis Honda Passport I

Testing & Diagnostics 24 illustrations ~1552 words

TROUBLE CODE DEFINITION

CodeSystem AffectedProbable Cause
12System NormalSystem Normal
13O2 SensorSensor or Circuit ECM
14A (1)Coolant Temperature SensorSensor or Circuit, ECM
14B (2)Coolant Temperature SensorSensor or Circuit, ECM
21ATPS Signal (High)TPS, ECM
21BTPS Signal (Low)TPS, ECM
23AMAT Circuit (Low)Sensor or Circuit, ECM
23BMAT Circuit (High)Sensor or Circuit, ECM
24Vehicle Speed SensorSensor or Circuit, ECM
32EGR SystemEGR Valve, Wiring Circuit EGR Solenoid, EGR Filter, EVRV, ECM
33AMAP Sensor Signal (High)Sensor or Circuit, ECM
33BMAP Sensor Signal (Low)Sensor or Circuit, ECM
42Electronic Spark TimingWiring Circuit, Ignition Module, ECM
44O2 Sensor (Lean)Injectors, Fuel Pressure,Exhaust Leaks, O2 Sensor or Circuit, MAP Sensor or ECM
45O2 Sensor (Rich)Injectors, Fuel Pressure,O2 Sensor or Circuit, MAP Sensor, TPS, Canister Purge Ignition Shielding, ECM
51PROM ErrorPROM or ECM
(1) High temperature indicated by temperature sensor. (2) Low temperature indicated by temperature sensor.
(1)High temperature indicated by temperature sensor.
(2)Low temperature indicated by temperature sensor.

CODE IDENTIFICATION

DIAGNOSTIC CIRCUIT CHECK

Scan Position(1) Data Value
A/COff (On With A/C Requested)
Battery13.5-14.5 Volts
BLM (Block Learn Memory)118-138 Counts
Coolant Temperature185-221°F (85-105°C)
IAC1-50 Counts
INT (Integrator)Varied Amount of Counts
Knock SignalNo
MAP(2) 1-2 Volts
Open/Closed LoopClosed Loop (Open At Idle)
Oxygen Sensor(3) .1-.9 Volt
Oxygen Sensor Cross CountsGreater Than One
RPM550-750 RPM
Rich/Lean FlagVaries
Torque Converter ClutchOff (On With TCC Requested)
TPS.42-.54 Volt
VSS0 MPH
(1) With engine idling at normal operating temperature, transmission in Park or Neutral, system in closed loop and all accessories off. (2) Voltage varies with vacuum and barometric pressure. (3) Voltage varies with exhaust temperature.
(1)With engine idling at normal operating temperature, transmission in Park or Neutral, system in closed loop and all accessories off.
(2)Voltage varies with vacuum and barometric pressure.
(3)Voltage varies with exhaust temperature.

SCAN DATA

Diagnostic circuit check will identify problem created by Electronic Engine Control System (EECS) malfunction. It is the starting point for diagnosis. This check will direct you to the next logical step in diagnosing the complaint.

After completing diagnostic circuit check and finding on-board diagnostics functioning properly with no trouble codes displayed, use appropriate SCAN DATA table for comparison. Data values must be taken under these conditions

  1. Engine at normal operating temperature.
  2. Engine running at idle.
  3. Vehicle in Park or Neutral.
  4. System in closed loop.

The values are an average of displayed values recorded from normal operating vehicles. Values represent what a normal functioning system would typically display.

Note. Only parameters supplied by manufacturer are used in this article. If a scan tester reads other parameters, values are not recommended by manufacturer for diagnostic use. A scan tester displaying faulty data should not be used, or misdiagnosis will occur. Report problem to scan tester manufacturer.

Note. Test numbers refer to numbers on diagnostic chart.

  1. This step checks if ECM can provide a ground path for CHECK ENGINE light. This is a bulb check.
  2. This step checks if ECM can perform internal diagnostics.
  3. This step checks if ECM can supply serial data for scan tester.
  4. This step verifies scan data.
  5. This step checks whether ECM or electrical system is cause of no start.
  6. This step checks ECM memory for codes to aid in diagnosis.

Scheme 56

Scheme 56

Diagnostic Aids - Engine Runs Okay

Check for faulty light bulb, open in light driver circuit or defective fuse. This will result in no oil indicator light, alternator light, seat belt reminder light, etc.

Diagnostic Aids

Normal scan tester voltage varies between .1 and 1.0 volt while in closed loop. Code 13 sets in about 40 seconds if voltage remains between .35 and .55 volt, but system will enter open loop in about 15 seconds. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 13 - Schematic (3.2L Passport Oxygen Sensor (Open Circuit). Scheme 57

Scheme 57: Code 13 - Schematic (3.2L Passport Oxygen Sensor (Open Circuit)

Code 13 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Open Circuit). Scheme 58

Scheme 58: Code 13 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Open Circuit)

After engine is started, temperature should rise steadily to about 194°F (90°C), and then stabilize when thermostat opens. When a Code 14A is set, ECM will turn on engine cooling fan. Code 14A will set if circuit is shorted to ground. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 14A - Schematic (3.2L Passport CTS Circuit (High Temperature Indicated). Scheme 59

Scheme 59: Code 14A - Schematic (3.2L Passport CTS Circuit (High Temperature Indicated)

Code 14A - Diagnostic Flowchart (3.2L Passport CTS Circuit (High Temperature Indicated). Scheme 60

Scheme 60: Code 14A - Diagnostic Flowchart (3.2L Passport CTS Circuit (High Temperature Indicated)

After engine is started, temperature should rise steadily to about 194°F (90°C), then stabilize when thermostat opens. Code 14B will set if sensor circuits are open. Check terminals at sensor for good contact. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 14B - Diagnostic Flowchart (3.2L Passport CTS Circuit (Low Temperature Indicated). Scheme 61

Scheme 61: Code 14B - Diagnostic Flowchart (3.2L Passport CTS Circuit (Low Temperature Indicated)

The scan tester reads throttle position in volts. With ignition on, reading should be less than 1.25 volts with throttle closed. Voltage should increase at a steady rate as throttle is moved toward WOT. An open in circuit or a short to voltage will result in Code 21A. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 21A - Schematic (3.2L Passport TPS Circuit (Signal Voltage High). Scheme 62

Scheme 62: Code 21A - Schematic (3.2L Passport TPS Circuit (Signal Voltage High)

Code 21A - Diagnostic Flowchart (3.2L Passport TPS Circuit (Signal Voltage High). Scheme 63

Scheme 63: Code 21A - Diagnostic Flowchart (3.2L Passport TPS Circuit (Signal Voltage High)

A scan tester reads throttle position in volts. With ignition on, reading should be less than one volt with throttle closed. Voltage should increase at a steady rate as throttle is moved toward WOT. An open or short to ground in circuits will cause Code 21B to set. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 21B - Diagnostic Flowchart (3.2L Passport TPS Circuit (Signal Voltage Low). Scheme 64

Scheme 64: Code 21B - Diagnostic Flowchart (3.2L Passport TPS Circuit (Signal Voltage Low)

An open in circuit will cause Code 23A to set. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 23A - Schematic (3.2L Passport MAT Circuit (Low Temperature Indicated). Scheme 65

Scheme 65: Code 23A - Schematic (3.2L Passport MAT Circuit (Low Temperature Indicated)

Code 23A - Diagnostic Flowchart (3.2L Passport MAT Circuit (Low Temperature Indicated). Scheme 66

Scheme 66: Code 23A - Diagnostic Flowchart (3.2L Passport MAT Circuit (Low Temperature Indicated)

A Code 23B will set if circuit becomes open or shorted to ground. For intermittent inspection, see INTERMITTENTS in appropriate TESTS W/O CODES - 3.2L article.

Code 23B - Diagnostic Flowchart (3.2L Passport MAT Circuit (High Temperature Indicated). Scheme 67

Scheme 67: Code 23B - Diagnostic Flowchart (3.2L Passport MAT Circuit (High Temperature Indicated)

A scan tester should indicate vehicle speed whenever vehicle is in motion. A faulty or misadjusted Park/Neutral switch can result in a false Code 24. Use scan tester to check for proper signal while vehicle is in Drive position. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 24 - Schematic (3.2L Passport VSS Circuit. Scheme 68

Scheme 68: Code 24 - Schematic (3.2L Passport VSS Circuit

Code 24 - Diagnostic Flowchart (3.2L Passport VSS Circuit. Scheme 69

Scheme 69: Code 24 - Diagnostic Flowchart (3.2L Passport VSS Circuit

A sluggish oxygen sensor can cause a false Code 32 to set. If EGR valve passage is restricted, Code 32 may set.

Code 32 - Schematic (3.2L Passport EGR System. Scheme 70

Scheme 70: Code 32 - Schematic (3.2L Passport EGR System

Code 32 - Diagnostic Flowchart (3.2L Passport EGR System. Scheme 71

Scheme 71: Code 32 - Diagnostic Flowchart (3.2L Passport EGR System

An open in circuit will cause Code 33A to set. If circuit to signal terminal is shorted to voltage, or circuit is shorted to circuit voltage, Code 33A will set. With ignition on and engine off, manifold pressure is equal to atmospheric pressure and voltage will be high. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 33A - Schematic (3.2L Passport MAP Sensor (Signal Voltage High). Scheme 72

Scheme 72: Code 33A - Schematic (3.2L Passport MAP Sensor (Signal Voltage High)

Code 33A - Diagnostic Flowchart (3.2L Passport MAP Sensor (Signal Voltage High). Scheme 73

Scheme 73: Code 33A - Diagnostic Flowchart (3.2L Passport MAP Sensor (Signal Voltage High)

An open in ground circuit will cause Code 33B to set. If circuit is shorted to voltage, Code 33B will set. With ignition on and engine off, manifold pressure is equal to atmospheric pressure and voltage will be high. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 33B - Diagnostic Flowchart (3.2L Passport Map Sensor (Signal Voltage Low). Scheme 74

Scheme 74: Code 33B - Diagnostic Flowchart (3.2L Passport Map Sensor (Signal Voltage Low)

If Code 42 is stored and hard start problem occurs, problem is probably a grounded EST circuit. For intermittent inspection, see INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 42 - Schematic (3.2L Passport EST (Electronic Spark Timing). Scheme 75

Scheme 75: Code 42 - Schematic (3.2L Passport EST (Electronic Spark Timing)

Code 42 - Diagnostic Flowchart (3.2L Passport EST (Electronic Spark Timing). Scheme 76

Scheme 76: Code 42 - Diagnostic Flowchart (3.2L Passport EST (Electronic Spark Timing)

Using scan tester, observe block learn values at different RPM. Scan tester also reads block cells, so block learn values can be checked in each of the cells to determine when Code 44 may have been set. If conditions for Code 44 are present, block learn values will be about 150.

  1. Oxygen sensor pigtail may be mispositioned and contacting exhaust manifold.
  2. Check for intermittent ground in wire between connector and sensor.
  3. An output causing ECM to sense a higher than normal vacuum will cause system to go lean. Disconnect MAP sensor. If lean condition is gone, replace sensor.
  4. Water near the in-tank fuel pump inlet can be delivered to the injectors, causing a lean exhaust. This can set Code 44.
  5. Fuel system will be lean if pressure is too low. Monitor fuel pressure while driving vehicle at various speeds and/or loads to confirm a problem (if necessary). Verify correct fuel injectors are installed in vehicle.
  6. If there is an exhaust leak, outside air can be pulled into the exhaust and past the sensor. Vacuum or crankcase leaks can also cause a lean condition.
  7. If the above are okay, problem is a faulty oxygen sensor. For intermittent inspection, see INTERMITTENTS in appropriate «TESTS W/CODES - 3.2L»(ref-15969) article.

Code 44 - Schematic (3.2L Passport Oxygen Sensor (Lean Fuel Mixture). Scheme 77

Scheme 77: Code 44 - Schematic (3.2L Passport Oxygen Sensor (Lean Fuel Mixture)

Code 44 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Lean Fuel Mixture). Scheme 78

Scheme 78: Code 44 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Lean Fuel Mixture)

Code 45 or rich exhaust is most likely caused by one of the following

  1. Check for fuel-contaminated oil.
  2. If an open exists in ground circuit, HEI-induced electrical noise may result, causing simulated reference pulses to be picked up by ECM. Additional pulses result in a higher than actual engine speed signal. The ECM will increase injector pulse width to match fuel requirements of increased RPM signal. Tachometer will show higher than actual RPM, which can help in diagnosing this problem.
  3. Check charcoal canister for fuel saturation. If full of fuel, check canister control and hoses.
  4. An output causing ECM to sense a higher than normal vacuum can cause system to go rich. Disconnecting MAP sensor allows ECM to set a fixed value for the sensor. If rich condition is gone with MAP sensor disconnected, replace sensor.
  5. An intermittent TPS output causes system to go rich due to a false acceleration indication.
  6. Inspect oxygen sensor for silicone contamination from fuel, or use of improper RTV sealant. Sensor may have a White powdery coating and result in a high but false signal voltage (rich exhaust). ECM will reduce amount of fuel delivered to engine, causing a severe surge driveability problem.
  7. Check for EGR valve sticking open at idle, usually accompanied by a rough idle or stall complaint, especially at idle. For intermittent inspection, see appropriate INTERMITTENTS in TESTS W/O CODES - 3.2L article.

Code 45 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Rich Fuel Mixture). Scheme 79

Scheme 79: Code 45 - Diagnostic Flowchart (3.2L Passport Oxygen Sensor (Rich Fuel Mixture)
