Glass: Removal & Installation Honda Odyssey III

Windshield Replacement

Note. Put on gloves to protect your hands. Wear eye protection while cutting the glass adhesive with piano wire. Use seat covers to avoid damaging the seat.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Remove these items: Windshield wiper arms (see «WIPER MOTOR REPLACEMENT»(ref-221005-S28268924152006022200000) ) Cowl covers (see «COWL COVER REPLACEMENT»(ref-220977-S10879455492006022200000) ) Rearview mirror (see «REARVIEW MIRROR REPLACEMENT»(ref-220966-S16295739102006022200000) ) A-pillar trim, both sides (see «A-PILLAR»(ref-220969-S20178217732006022200000) ) Roof molding (see «ROOF MOLDING REPLACEMENT»(ref-220977-S39014692892006022200000) ) Windshield side trim (see «WINDSHIELD SIDE TRIM REPLACEMENT»(ref-220977-S37853052502006022200000) )
2. Remove the molding (A) from the upper edge of the windshield (B). If necessary, cut the molding with a utility knife.
3. If the old windshield is to be reinstalled, make alignment marks across the glass and body with a grease pencil.
4. Pull down the front portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION»(ref-220969-S29622293522006022200000) ). Take care not to bend the headliner excessively, or you may crease or break it.
5. Apply protective tape along the edge of the dashboard and body. Using an awl, make a hole through the rubber dam and adhesive from inside the vehicle at the corner portion of the windshield. Push a piece of piano wire through the hole, and wrap each end around a piece of wood.
6. With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the windshield (B) as possible to prevent damage to the body and dashboard. Carefully cut through the rubber dam and adhesive (C) around the entire windshield.
7. Carefully remove the windshield.
8. With a knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire windshield opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the rubber dam and fasteners from the body. Replace the dashboard seal with a new one.
9. Clean the body bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease and water from getting on the clean surface.
10. If the old windshield is to be reinstalled, use a putty knife to scrape off all of the old adhesive, the clips and the rubber dams from the windshield. Clean the inside face and the edge of the windshield with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil and grease.
11. Attach the rubber dam (A) and clips (B) with adhesive tape to the inside face of the windshield (C) (Scheme 5) Be sure the rubber dams and clips line up with the alignment marks (D). Be careful not to touch the windshield where adhesive will be applied. Rubber dam adhesive tape: Thickness 0.2 mm (0.008 in.) Width 4.5 mm (0.18 in.) Clips adhesive tape: Thickness 0.4 mm (0.016 in.) Width 10 mm (0.39 in.)
12. Attach the molding (A) with adhesive tape (B) to the upper edge of the windshield (C). Be careful not to touch the windshield where adhesive will be applied. Be careful not to touch the windshield where adhesive will be applied. Molding adhesive tape: Thickness 0.8 mm (0.03 in.) Width 4 mm (0.16 in.)
13. Apply primer to the molding (A), then attach the molding upper seal (B) with adhesive tape to the inside surface of the molding (Scheme 7) Seals adhesive tape: Thickness 0.16 mm (0.0063 in.) Width 7 mm (0.28 in.)
14. Set the windshield in the opening, and center it. Make alignment marks (A) across the windshield and body with a grease pencil at the four points (Scheme 8) Make sure both clips (B) contact with the edge of the body holes. Be careful not to touch the windshield where adhesive will be applied.
15. Remove the windshield.
16. With a sponge, apply a light coat of glass primer around the edge of the windshield (A) between the rubber dam (B) and molding (C) (Scheme 9), then lightly wipe it off with gauze or cheesecloth: Apply glass primer to the molding. Do not apply body primer to the windshield, and do not get body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the windshield properly, causing a leak after the windshield is installed. Keep water, dust, and abrasive materials away from the primed surface.
17. With a sponge, carefully apply a light coat of body primer to any exposed paint around the flange where new adhesive will be applied. Let the primer dry for at least 10 minutes: Do NOT apply body primer to any remaining original adhesive on the flange. Be careful not to mix up the body and glass primer sponges. Never touch the primed surfaces with your hands. Mask off the dashboard before priming the flange.
18. Cut a "V" in the end of the adhesive cartridge nozzle (A) (Scheme 11)
19. Put the adhesive cartridge in a caulking gun, and run a bead of adhesive (A) around the edge of the windshield (B) between the rubber dam (C) and molding (D) (Scheme 12) Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
20. Use suction cups to hold the windshield over the opening, align it with the alignment marks made in step 14, and set it down on the adhesive. Lightly push on the windshield until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
21. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the windshield, wipe with a soft shop towel dampened with alcohol.
22. Let the adhesive dry for at least 1 hour, then spray water over the windshield and check for leaks. Mark leaking areas, and let the windshield dry, then seal with sealant: Let the vehicle sit for at least 4 hours after windshield installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly. Keep the windshield dry for the first hour after installation.
23. Reinstall all remaining removed parts. NOTE: Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Rear Window Replacement

Note. Put on gloves to protect your hands. Wear eye protection when removing the glass with piano wire. Use seat covers to avoid damaging any surfaces. Do not damage the rear window defogger grid lines and terminals.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Remove these items: Tailgate spoiler trim (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(ref-220969-S25735837752006022200000) ) Tailgate lower trim panel (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(ref-220969-S25735837752006022200000) ) Rear window wiper motor (see «REAR WINDOW WIPER MOTOR REPLACEMENT»(ref-221005-S12496146362006022200000) )
2. Disconnect the rear window defogger connectors (A).
3. If the old rear window is to be reinstalled, make alignment marks across the glass and body with a grease pencil.
4. Apply protective tape along the inside and outside edges of the tailgate. Using an awl, make a hole through the adhesive from inside the vehicle at the corner portion of the rear window. Push the piano wire through the hole, and wrap each end around a piece of wood.
5. With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the rear window (B) as possible to prevent damage to the tailgate, and carefully cut through the adhesive (C) around the entire rear window.
6. Carefully remove the rear window.
7. With a putty knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire rear window opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the fasteners from the tailgate.
8. Clean the tailgate bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease and water from getting on the surface.
9. If the old rear window is to be reinstalled, use a putty knife to scrape off all of the old adhesive, the fasteners and the rubber dams from the rear window. Clean the inside face and the edge of the rear window with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil and grease.
10. Attach the upper rubber dam (A), lower rubber dam (B), and fasteners (C, D) with adhesive tape to the inside face of the rear window (E) (Scheme 15) Before installing the upper rubber dams, apply primer to the area where the adhesive tapes will be applied to the inside face of the rear window: Be sure the fasteners, and upper and lower rubber dams line up with alignment marks (F). If necessary, cut the excess side molding along the lower edge of the rear window. Be careful not to touch the rear window where adhesive will be applied. Rubber dams adhesive tape: Thickness 0.16 mm (0.0063 in.) Width 3.5 mm (0.14 in.) Fasteners adhesive tape: Thickness 0.6 mm (0.024 in.) Width 7.5 mm (0.3 in.)
11. Attach the fasteners (A, B) with adhesive tape to the tailgate (Scheme 16) Fasteners adhesive tape: Thickness 0.6 mm (0.024 in.) Width 7.5 mm (0.3 in.)
12. Set the rear window (A) in the opening, and center it. Make alignment marks (B) across the rear window and body with a grease pencil at the four points (Scheme 17) Be careful not to touch the rear window where adhesive will be applied.
13. With a sponge, apply a light coat of glass primer to the rear window (A) along the edge of the upper rubber dam (B) and lower rubber dam (C) (Scheme 18), then lightly wipe it off with gauze or cheesecloth: With the printed dots (D) on the rear window as a guide, apply the glass primer to both side portions of the rear window. Do not apply body primer to the rear window, and do not get body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the rear window properly, causing a leak after the rear window is installed. Keep water, dust, and abrasive materials away from the primed surface.
14. With a sponge, carefully apply a light coat of body primer to any exposed paint around the flange where new adhesive will be applied. Let the body primer dry for at least 10 minutes: Do NOT apply body primer to any remaining original adhesive on the flange. Be careful not to mix up the body and glass primer sponges. Never touch the primed surfaces with your hands.
15. Cut a "V" in the end of the adhesive cartridge nozzle (A) (Scheme 20)
16. Put the cartridge in a caulking gun, and run a bead of adhesive (A) on the rear window (B) around the edge of the upper rubber dam (C) and lower rubber dam (D) (Scheme 21) Apply the adhesive within 30 minutes after applying the glass primer. Make a slightly thicker bead at each corner.
17. Use suction cups to hold the rear window over the opening, align it with the alignment marks you made in step 12, and set it down on the adhesive. Lightly push on the rear window until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
18. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the rear window, use a soft shop towel dampened with alcohol.
19. Let the adhesive dry for at least 1 hour, then spray water over the rear window and check for leaks. Mark the leaking areas, let the rear window dry, then seal with sealant. Let the vehicle sit for at least 4 hours after rear window installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly.
20. Reinstall all remaining removed parts. NOTE: Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).

Note. Put on gloves to protect your hands. Wear eye protection when removing the glass with piano wire. Use seat covers to avoid damaging any surfaces. Do not damage the antenna grid lines or terminals.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Remove these items: C-pillar trim (see «C-PILLAR»(ref-220969-S25148156582006022200000) ) D-pillar trim (see «D-PILLAR»(ref-220969-S04523066222006022200000) ) Rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(ref-220969-S01876916192006022200000) )
2. Remove the front seal (A) from the front edge of the quarter glass (B). If necessary, cut the rubber dam with a utility knife.
3. Right quarter glass: Disconnect the glass antenna connectors (A).
4. From inside the vehicle, use a knife (A) to cut through the quarter glass adhesive (B) in upper side, rear side, and lower side: If the quarter glass (C) is to be reinstalled, take care not to damage the molding (D). If the molding is damaged, replace the quarter glass, molding, and clips (E) as an assembly. If any of the clips are broken, the quarter glass can be reinstalled using butyl tape (refer to step 12 ). Apply protective tape along the edge of the entire quarter glass opening flange.
5. Apply protective tape to along the inside and outside edges of the body. Push a piece of piano wire through the lower cut area in the adhesive, and wrap each end around a piece of wood.
6. With a helper on the outside, pull the piano wire (A) back and forth in a sawing motion. Hold the piano wire as close to the quarter glass (B) as possible to prevent damage to the body, and carefully cut through the adhesive (C) in the front side of the quarter glass. Take care not to drop the quarter glass. If the quarter glass is to be reinstalled, take care not to damage the molding (D). If the molding is damaged, replace the quarter glass, molding, and clips (E) as an assembly. If any of the clips are broken, the quarter glass can be reinstalled using butyl tape (refer to step 12 ).
7. Carefully remove the quarter glass.
8. With a putty knife, scrape the old adhesive smooth to a thickness of about 2 mm (0.08 in.) on the bonding surface around the entire quarter glass opening flange: Do not scrape down to the painted surface of the body; damaged paint will interfere with proper bonding. Remove the clips and fastener from the body.
9. Clean the body bonding surface with a sponge dampened in alcohol. After cleaning, keep oil, grease and water from getting on the surface.
10. If the old quarter glass is to be reinstalled, use a putty knife to scrape off all of the old adhesive, fastener and the rubber dam from the quarter glass. Clean the inside face and the edge of the quarter glass with alcohol where new adhesive is to be applied. Make sure the bonding surface is kept free of water, oil and grease.
11. Attach the fastener (A) and clip (B) with adhesive tape to the inside face of the quarter glass (C): Be sure the fastener and clip line up with the alignment marks (D). Be careful not to touch the quarter glass where adhesive will be applied. Fastener adhesive tape: Thickness 0.6 mm (0.024 in.) Width 7.5 mm (0.3 in.) Clip adhesive tape: Thickness 0.4 mm (0.016 in.) Width 7.5 mm (0.3 in.)
12. If the old quarter glass (A) is to be reinstalled (and either clip is broken off the molding), apply a light coat of primer, then apply butyl tape (B) to the molding (C) as shown (Scheme 27): Be careful not to touch the quarter glass where adhesive will be applied. Do not peel the separator off the butyl tape.
13. Attach the fastener with adhesive tape to the body (Scheme 28) If the old quarter glass is to be reinstalled (and either clip is broken off the molding), seal the body holes with pieces of urethane tape (A). Fastener adhesive tape: Thickness 0.6 mm (0.024 in.) Width 7.5 mm (0.3 in.)
14. If the old quarter glass (A) is to be reinstalled (and either clip is broken off the molding), install the rear fastener (B) and rear clip (C) in the opening flange, set the quarter glass upright in the opening, and make alignment marks (D) across the quarter glass and body with a grease pencil at the four points (Scheme 29) Be careful not to touch the quarter glass where adhesive will be applied.
15. Remove the quarter glass. Take care not to break the rear clip during removal.
16. With a sponge, apply a light coat of glass primer to the inside face of the quarter glass (A) along the molding (B), and to the molding (Scheme 30), then lightly wipe it off with gauze or cheesecloth: With the printed dots (C) on the quarter glass as a guide, apply the glass primer to the upper and lower corner portions of the quarter glass. Do not apply body primer to the quarter glass, and do not get the body and glass primer sponges mixed up. Never touch the primed surfaces with your hands. If you do, the adhesive may not bond to the quarter glass properly, causing a leak after the quarter glass is installed. Keep water, dust, and abrasive materials away from the primed surface.
17. With a sponge, carefully apply a light coat of body primer to any exposed paint around the flange where new adhesive will be applied. Let the body primer dry for at least 10 minutes: Do NOT apply body primer to any remaining original adhesive on the flange. Be careful not to mix up the body and glass primer sponges. Never touch the primed surfaces with your hands.
18. Cut a "V" in the end of the adhesive cartridge nozzle (A) (Scheme 32)
19. Put the cartridge in a caulking gun, and run a bead of adhesive (A) on the quarter glass (B) around the edge of the molding (C) (Scheme 33): After applying the adhesive, peel the separator off the butyl tape. Apply the adhesive within 30 minutes after applying the glass primer. Make slightly thicker bead at each corner.
20. Use suction cups to hold the quarter glass over the opening, align it with the clips or the alignment marks made in step 14, and set it down on the adhesive. Lightly push on the quarter glass until its edges are fully seated on the adhesive all the way around. Do not open or close the doors until the adhesive is dry.
21. Scrape or wipe the excess adhesive off with a putty knife or towel. To remove adhesive from a painted surface or the quarter glass, use a soft shop towel dampened with alcohol.
22. Let the adhesive dry for at least 1 hour, then spray water over the quarter glass and check for leaks. Mark the leaking areas, let the quarter glass dry, then seal with sealant. Let the vehicle stand for at least 4 hours after quarter glass installation. If the vehicle has to be used within the first 4 hours, it must be driven slowly.
23. Reinstall all remaining removed parts. NOTE: Advise the customer not to do the following things for 2 to 3 days: Slam the doors with all the windows rolled up. Twist the body excessively (such as when going in and out of driveways at an angle or driving over rough, uneven roads).
