Starting System: Specifications — Honda Odyssey II (1999-2003)

Starting System: Specifications Honda Odyssey II

Starter 8 illustrations

STARTER SPECIFICATIONS

Application				Specification
Brush Length (Minimum)
Accord
2.3L
A/T				.43" (11.0 mm)
M/T				.39" (10.0 mm)
3.0L				.43" (11.0 mm)
Civic, Odyssey, Prelude & S2000				.43" (11.0 mm)
CR-V				.35" (9.0 mm)
Brush Spring Tension
Accord
2.3L
A/T				3.5-4.0 Lbs. (1.6-1.8 kg)
M/T				3.1-4.4 Lbs. (1.4-2.0 kg)
3.0L				3.5-4.0 Lbs. (1.6-1.8 kg)
Civic, Odyssey, Prelude & S2000				3.5-4.0 Lbs. (1.6-1.8 kg)
CR-V				3.1-4.0 Lbs. (1.4-1.8 kg)
Commutator Diameter (Minimum)
Accord
2.3L
A/T				1.08" (27.5 mm)
M/T				1.14" (29.0 mm)
3.0L				1.08" (27.5 mm)
Civic, Odyssey, Prelude & S2000				1.08" (27.5 mm)
CR-V				1.06" (27.0 mm)
Commutator Mica Depth (Minimum)
Accord
2.3L
A/T				.006" (.15 mm)
M/T				.008" (.20 mm)
3.0L				.006" (.15 mm)
Civic, Odyssey, Prelude & S2000				.006" (.15 mm)
CR-V				.008" (.20 mm)
Commutator Runout (Maximum)				.002" (.05 mm)
