Power Mirror Replacement
Note. Put on gloves to protect your hands. Take care not to scratch the door or the related parts.
Scheme 2
Scheme 3
Scheme 4
- Carefully pull the door mirror cover (A) to release the hooks (B) and detach the clip, then remove the cover.
- Remove the front door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-513204-S07885503932012110700000) ).
- Disconnect the power mirror connector (A), and detach the harness clip (B).
- While holding the power mirror (A), remove the nuts securing the mirror.
- While holding the mirror, pull out the harness through the hole in the door. Take care not to scratch the door.
- Install the power mirror in the reverse order of removal, and note these items: Make sure the connector is plugged in properly. If the clip is damaged or stress-whitened, replace it with a new one. Push the clip and the hooks into place securely.
Mirror Holder Replacement
Note. Put on gloves to protect your hands. Take care not to scratch the power mirror or the related parts. When prying with a flat-tipped screwdriver, wrap it with protective tape to prevent damage.
Scheme 5
Scheme 6
Scheme 7
Scheme 8
- Carefully push on the top edge of the mirror holder (A) by hand.
- Put a shop towel in the opening between the bottom edge of the mirror holder and the mirror housing to prevent scratches, and detach the bottom hooks (B) with a flat-tip screwdriver.
- Separate the mirror holder (A) from the actuator (B) by releasing the hooks (C). If equipped, disconnect the mirror defogger connectors (D). NOTE: If you are only removing the mirror holder, go to step 5 . If you are doing further disassembly of the mirror, proceed to step 4. Mirror housing replacement
- Remove the mirror housing (A). Remove the screws (B, C). Release the hooks (D), then remove the visor (E) and the mirror housing.
- Before reinstalling the mirror holder to the inner holder (A) of the actuator, check the actuator rods (B) and the actuator boots (C). NOTE: Make sure each actuator rod is inserted into the actuator securely, and each actuator boot is fully seated on the actuator.
- Reconnect the mirror defogger connectors (D).
- Reattach the hooks of the mirror holder to the actuator, then position the mirror holder on the actuator. Carefully push on the hook areas of the mirror holder until the mirror holder locks into place.
- Check the actuator operation.
Scheme 9
Scheme 10
- Turn the rearview mirror base (A) 90°.
- Slide the rearview mirror base (A) down toward the bottom of the windshield to detach it from the spring (B) in the mount (C).
- If necessary, remove the spring from the mount.
- Install the rearview mirror in the reverse order of removal.
