Scheme 1
Windshield Wiper/Washer (Normally Operation)
The MICU controls the windshield wiper motor and the windshield washer motor based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Windshield wiper switch (INT/LO) Windshield wiper switch (HI/LO) Windshield wiper switch (MIST) Windshield washer switch Windshield wiper intermittent dwell time controller (1) Windshield wiper motor position switch (AUTO STOP) | Windshield wiper motor (INT) Windshield wiper motor (HI) Windshield washer motor |
| B-CAN | IG1 power supply signal | Windshield wiper switch (FRINT) ON/OFF message Windshield wiper switch (FRWIPLO) ON/OFF message Windshield wiper switch (FRWIPHI) ON/OFF message Windshield washer switch (FRWASH) ON/OFF message Windshield wiper switch (FRMIST) ON/OFF message Windshield wiper motor position switch (FRWIPAS) ON/OFF message Windshield wiper intermittent dwell time controller (FRINTVR) resistance message (1) |
| (1) With intermittent dwell time controller | ||
| (1) | With intermittent dwell time controller |
Rear Window Wiper/Washer (Normally Operation)
The MICU controls the rear window wiper motor and the rear washer motor based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Transmission range switch (R) position Windshield washer motor switch Rear window wiper switch Rear window washer motor switch Windshield wiper switch (INT) Windshield wiper switch (LO) Windshield wiper switch (HI) | Rear window wiper motor Rear window washer motor |
| B-CAN | Rear window wiper switch (RRWIPSW) ON/OFF message Rear window washer switch (RRWASH) ON/OFF message |
Windshield Wiper/Washer (Vehicle Speed Operation)
The MICU controls the windshield wiper motor and the windshield washer motor based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Brake pedal position switch Transmission range switch (P) position Windshield wiper switch (INT/LO) Windshield wiper switch (HI/LO) Windshield wiper switch (MIST) Windshield washer switch Windshield wiper intermittent dwell time controller (1) Windshield wiper motor position switch (AUTO STOP) | Windshield wiper motor (INT) Windshield wiper motor (LO) Windshield wiper motor (HI) Windshield washer motor |
| B-CAN | Parking brake switch signal Vehicle speed pulse signal | Windshield wiper switch (FRINT) ON/OFF message Windshield wiper switch (FRWIPLO) ON/OFF message Windshield wiper switch (FRWIPHI) ON/OFF message Windshield washer switch (FRWASH) ON/OFF message Windshield wiper switch (FRMIST) ON/OFF message Windshield wiper intermittent dwell time controller (FRINTVR) resistance message (1) |
| (1) With windshield wiper intermittent dwell time control | ||
| (1) | With windshield wiper intermittent dwell time control |
Power Window Timer (Key-Off Operation)
The MICU controls the power window key-off operation based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | IG1 power supply Ignition key switch Driver's door switch Front passenger's door switch | Power window timer |
Door Lock Response Operation*
The MICU controls the door lock actuators LOCK, UNLOCK, DRIVER'S UNLOCK, HATCH UNLOCK based on B-CAN door lock switch signals.
| Input | Output | |
|---|---|---|
| MICU | Door lock actuators (LOCK/UNLOCK) Driver's door lock actuator (UNLOCK) Hatch release actuator | |
| B-CAN | Door lock signal |
This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.
Answer Back Response Operation*
The MICU controls the lighting system and horn based on keyless signals sent by B-CAN.
| Input | Output | |
|---|---|---|
| MICU | Headlights (LOW) Parking lights Side marker lights Taillights License plate lights Horn | |
| B-CAN | Answer back (PARKING) signal Answer back (HLLO) signal Answer back (HORN) signal |
This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.
Hatch Outer Handle Switch Operation
The MICU controls the hatch release actuator based on inputs from each switch.
| Input | Output | |
|---|---|---|
| MICU | Hatch outer handle switch Driver's door lock knob switch (LOCK/UNLOCK) Front passenger's door lock knob switch (UNLOCK) Left rear door lock knob switch (UNLOCK) Right rear door lock knob switch (UNLOCK) | Hatch release actuator |
