Multiplex Integrated Control System: Other Honda Insight ZE2 рестайлинг

Using the HDS (Preferred method)

Connect the HDS to the Data Link Connector (DLC).

Note. There are two ways to read B-CAN code with the HDS.

First method: On the HDS, select BODY ELECTRICAL, then select the subsystem that relates to the problem (for example: door locks, keyless, security, ets.), and then last, select the DTCs.

Second method: Ground the SCS circuit with the HDS, then read the DTCs displayed in the multi-information display in the gauge control module, then go to B-CAN SYSTEM DIAGNOSIS TEST MODE A .

How to display DTCs on the MID of the gauge control module

Enter B-CAN System Diagnosis Test Mode 1 (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE 1 AND TEST MODE 2 (WITHOUT THE HDS) ). While in Test Mode 1, the DTCs which have been detected and stored individually by various B-CAN (Body-Controller Area Network) units will be shown one by one on the multi-information display when communication between the MICU and the gauge control module is normal. To scroll through the DTCs, press the SEL/RESET button.

Scheme 6

The unit that has stored the code can be identified by the number shown on the multi-information display.

How to clear DTCs

1. Enter B-CAN System Diagnosis Test Mode 1 (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE 1 AND TEST MODE 2 (WITHOUT THE HDS)»(ref-513195-S21301063682012110700000) ).
2. While in Test Mode 1, press and hold down the SEL/RESET button for at least 10 seconds to clear the DTCs.

Body Controller Area Network (B-CAN) and Fast Controller Area Network (F-CAN)

The body controller area network (B-CAN) and the fast controller area network (F-CAN) share information between multiple electronic control units (ECUs). B-CAN communication moves at a slower speed (33.33 kbps) for convenience related items and for other functions. F-CAN information moves at a faster speed (500 kbps) for "real time" functions such as fuel and emissions data. To allow both systems to share information, the gauge control module translates and relays the information from B-CAN to F-CAN and from F-CAN to B-CAN. This is called the Gateway Function.

Scheme 7

Gateway Function

The gauge control module acts as a gateway to allow both systems to share information. The gauge control module translates and relays the information from B-CAN to F-CAN and from F-CAN to B-CAN.

Scheme 8

Network "Loss of Communication" Error Checking Function

The ECUs on the CAN circuit send messages to each other. If there are any communication malfunctions on the network, the multi-information display on the gauge control module can indicate the error messages by entering the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).

Scheme 9

Wake-up and Sleep Function

The multiplex integrated control system has wake-up and sleep functions to decrease parasitic draw on the battery when the ignition switch is in LOCK (0).

1. In the sleep mode, the multiplex integrated control system stops functioning (communication and CPU control) when it is not necessary for the system to operate.
2. As soon as any operation is requested (for example, a door is unlocked), the related control units in the sleep mode immediately wake up and begin to function.
3. When the ignition switch is turned to LOCK (0) with all the doors and the hatch closed, and the driver's door is opened, then closed, there is a delay of about 40 seconds before the control unit goes from the wake-up mode to the sleep mode.
4. The sleep mode will not function if any door or the hatch is open or if a key is in the ignition switch.

Note. Sleep and Wake-up Mode Test (see SLEEP AND WAKE-UP MODE TEST ).

Fail-safe Function

To prevent improper operation, the MICU has a fail-safe function. In the fail-safe mode, the output signal is fixed when any part of the system malfunctions (for example, a faulty control unit or communication line). Each control unit has a hardware fail-safe function that fixes the output signal when there is a CPU malfunction, and a software fail-safe function that ignores the signal from a malfunctioning control unit, which allows the system to continue operating normally.

When a CPU problem or an abnormal power supply voltage is detected, the MICU moves to the hardware fail-safe mode, and each system output load is set to the pre-programmed fail-safe value.

Software Fail-safe Control

When any of the data from the B-CAN circuit cannot be received within a specified time, or an unusual combination of data is recognized, the MICU moves to the software fail-safe mode. The data that was not received is forced to a pre-programmed value.

Power Supply Voltage Monitoring Function

The MICU monitors the power supply voltage (back-up voltage). If the voltage drops below 10 V, the MICU does not store DTCs.

Headlights

The MICU controls the headlights based on inputs from each switch.

Turn Signal/Hazard Warning Light

The MICU controls the turn signal/hazard warning lights based on inputs from the turn signal switch and the hazard warning switch.

Entry Lights Control System (Ceiling Light)*

The MICU controls the ceiling light ON/OFF based on inputs signals from each switch.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Automatic Lighting

The MICU controls the automatic lighting system based on inputs from the automatic lighting sensor.

Cargo Area Light

The MICU controls the cargo area light based on inputs from the hatch latch switch.

Daytime Running Lights

The MICU controls the headlights as daytime running lights based on inputs from each switch.

Rear Window Wiper/Washer (With Reverse Linked Rear Wiper)

The MICU controls the rear window wiper motor and the rear window washer motor based on inputs from each switch.

Windshield/Rear Window Washer

The MICU controls the windshield and rear window washer motor based on inputs from each switch.

Collision Detection Signal (CDS)

The MICU controls the door lock actuators based on IG1 and SRS (CDS) inputs.

Power Door Locks*

The MICU controls the door lock actuators based on inputs from each switch.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Keyless Entry System*

The MICU controls the door lock actuators based on the inputs signals from each switch.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Key-in Reminder

The MICU controls the door lock actuators based on inputs from each switch.

Key Interlock

The MICU controls the key interlock solenoid based on ignition switch ACCESSORY (I) position, the transmission range switch P position, and the park pin switch inputs.

Security Alarm System

The MICU controls the lighting system and horn based on inputs from each switch.

Keyless Answer Back (Without security)*

The MICU controls the lighting system and horn based on keyless signals sent by B-CAN.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Security Answer Back (With security)*

The MICU controls the lighting system and horn based on keyless signals sent by B-CAN.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Auto Door Lock*

The MICU controls the door lock actuators based on inputs from each switch.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Auto Door Unlock*

The MICU controls of the door lock actuators based on inputs from each switch.

This system can be customized in the multi-information display to suit the customer's needs. For more information about customizing options, refer to the Owner's Manual.

Keyless Panic Function

The MICU controls the keyless PANIC operation based on signals sent by B-CAN.

HDS Inputs and Commands

Certain inputs happen so quickly that the HDS cannot update fast enough. Hold the switch that is being tested while monitoring the Data List. This should give the HDS time to update the signal on the Data List.

Because the HDS software is updated to support the release for newer vehicles it is not uncommon to see system function tests that are not supported.

Make sure that the most current HDS software is loaded.

INPUT

FUNCTION TEST

Troubleshooting - B-CAN System Diagnosis Test Mode A

Check the PCM for DTCs and troubleshoot PCM (see GENERAL TROUBLESHOOTING INFORMATION ) or F-CAN loss of communication errors first, then do this diagnosis if the symptom is related to the B-CAN system.

Scheme 10

1. Compare the symptom with this list of B-CAN related systems: Gauge control module Immobilizer Climate control HandsFreeLink Exterior lights Entry light control Turn signal/hazard warning lights Horn (security and panic) Wiper/washer Power windows Security Keyless entry Power door locks Key interlock Is the symptom related to the B-CAN system? YES -Go to step 2. NO -Go to the system troubleshooting for the system with the symptom.
2. Connect the HDS to the data link connector (DLC) (A), then turn the ignition switch to ON (II).
3. From the BODY ELECTRICAL SYSTEM SELECT menu, select B-CAN CONTROL UNITS INFORMATION, and then select CHECK CONNECTED CONTROL UNITS listed to see if the following control units are communicating with the HDS. MICU Gauge control module Immobilizer-keyless control unit Climate control unit HandsFreeLink control unit NOTE: If a unit is communicating with the HDS, DETECT is displayed. If a unit is not communicating or the vehicle is not equipped, "NOT AVAILABLE" is displayed. The HDS only checks the status one time when BODY ELECTRICAL is selected. To recheck the status after repair, reboot the HDS. Are all control units communicating with the HDS? YES -Go to step 4. NO -If any of the control units are not communicating, go to «B-CAN SYSTEM DIAGNOSIS TEST MODE B»(ref-513195-S19613541232012110700000) . If all units are not communicating or only the MICU is communicating, go to «DTC B1000 TROUBLESHOOTING»(ref-513195-S36525498162012110700000) .
4. Select the system that has the problem from BODY ELECTRICAL SYSTEM SELECT menu, then select DTCs. Are any DTCs indicated? YES -Go to step 5. NO -If the problem is related to one of the following items, and the system that is malfunctioning does not stop or turn off, go to «B-CAN SYSTEM DIAGNOSIS TEST MODE C»(ref-513195-S11010927132012110700000) . If the problem is related to one of the following items and the system that is malfunctioning does not work or turn on, go to «B-CAN SYSTEM DIAGNOSIS TEST MODE D»(ref-513195-S05370357372012110700000) . Exterior lights Entry light control Horn (security and panic) Wiper/washer Power windows Power door locks Turn signal/hazard warning lights Key interlock If the problem is related to one of the following items, go to the troubleshooting for that individual system. Gauge control module Immobilizer Climate control HandsFreeLink Security Keyless entry
5. Record all DTCs, and sort them by DTC type.
6. Troubleshoot the DTC(s) in the order: Battery voltage DTCs. Internal error DTCs. Loss of communication DTCs. Signal error DTCs.

Troubleshooting - B-CAN System Diagnosis Test Mode B

Do this diagnosis if any of the control units are not communicating (NOT AVAILABLE is displayed on the HDS) as found by the B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

1. Using the HDS, select the system that has the symptom from BODY ELECTRICAL SYSTEM SELECT menu.
2. Select the DTCs, and then check for loss of communication DTCs. Are any loss of communication DTCs indicated? YES -Go to step 3. NO -Faulty MICU; replace the under-dash fuse/relay box. USA model (see «REMOVAL AND INSTALLATION»(ref-513189-S16875978532012110700000) ) Canada model (see «CANADA MODEL»(ref-513189-S10776284102012110700000) )
3. Do the power, ground, and communication part of the input test for the unit(s) not communicating with the HDS. Unit not communicating MICU (see «MICU INPUT TEST»(ref-513195-S20459023412012110700000) ) Gauge control module (see «GAUGE CONTROL MODULE INPUT TEST»(ref-513176-S11072381992012110700000) ) Immobilizer-keyless control unit (see «IMMOBILIZER-KEYLESS CONTROL UNIT INPUT TEST»(ref-513172-S40217143822012110700000) ) Climate control unit (see «CLIMATE CONTROL POWER AND GROUND CIRCUIT TROUBLESHOOTING»(ref-513164-S26333080292012110700000) ) HandsFreeLink control unit (see «HFL SYSTEM TROUBLESHOOTING»(ref-513223-S17379718622012110700000) )

Troubleshooting - B-CAN System Diagnosis Test Mode C

Do this diagnosis if a component that is controlled by the B-CAN system does not stop or turn off.

Note. If the component does not run or turn on, go to B-CAN SYSTEM DIAGNOSIS TEST MODE D . Seethe B-CAN system unit input/output index for a list of input and output devices and the control units that monitor the input and control the output devices (see HDS INPUTS AND COMMANDS ).

1. Check for DTCs by selecting the MODE MENU from the HDS. Are any DTCs indicated? YES -Go to «B-CAN SYSTEM DIAGNOSIS TEST MODE A»(ref-513195-S38024574182012110700000) . NO -Go to step 2.
2. Turn off the switch that controls the malfunctioning component.
3. Select the applicable system from the system MODE MENU, then select DATA LIST, and check the input of the switch that controls the component. Does the HDS indicate the switch is OFF? YES -Go to step 4. NO -Go to step 6 .
4. In the DATA LIST, check the output signal of the malfunctioning component. Is the output signal OFF? YES -Go to step 5. NO -Replace the control unit that controls the device that will not turn OFF.
5. Check the relay that does not stop or turn off, if applicable, then check for a short in the wire between the relay and the component, the relay and control unit, or the component and control unit. Are the relay and the wire harness OK? YES -Replace the control unit that controls the component that will not stop or turn OFF. NO -Replace the relay or repair/replace the wire harness.
6. Check the switch, then check for a short in the wire between the switch and the control unit that monitors the switch. Are the switch and wire harness OK? YES -Replace the control unit that monitors the switch. NO -Replace the switch, or repair/replace the wire harness.

Troubleshooting - B-CAN System Diagnosis Test Mode D

Do this diagnosis if a component that is controlled by the B-CAN system does not work or come on.

Note. If the component does not turn off or stop, go to B-CAN SYSTEM DIAGNOSIS TEST MODE C . See the B-CAN system unit input/output index for a list of input and output devices and the control units that monitor the input and control the output devices (see HDS INPUTS AND COMMANDS ).

1. Check the fuse of the malfunctioning output device. Is the fuse OK? YES -Go to step 2. NO -Replace the fuse. If the fuse blows again, repair a short to ground on the fuse circuit of the malfunctioning device.
2. Check for DTCs by selecting the MODE MENU from the HDS. Are any DTCs indicated? YES -Go to «B-CAN SYSTEM DIAGNOSIS TEST MODE A»(ref-513195-S38024574182012110700000) . NO -Go to step 3.
3. Turn ON the switch that controls the malfunctioning component.
4. Select the applicable system from the system MODE MENU, then select DATA LIST, and check output signal for the malfunctioning component. Is there an output signal? YES -Go to step 5. NO -Go to step 9 .
5. Check the relay and ground, then check for an open or a short in the circuit for the malfunctioning component. Is the relay and the circuit OK? YES -Go to step 6. NO -Replace the relay, or repair the wire circuit.
6. Do the function test for the malfunctioning component. Does the output device pass the function test? YES -Go to step 7. NO -Replace the component.
7. With the malfunctioning output device connected, connect a voltmeter between the malfunctioning output device input and the ground wire that the control unit uses to control the output device circuit.
8. Select FUNCTIONAL TEST from the MODE MENU, and do the forced operation test of the malfunctioning component. Is there a change in voltage (12 V to 0 V or 0 V to 12 V)? YES -Inspect the ground for the component. If OK, replace the component. NO -Replace the control unit that controls the malfunctioning component.
9. Select DATA LIST from the system MODE MENU, and make sure the switch signal input for the malfunctioning system indicates a change when operated. Does the switch input indicate ON when the switch is ON? YES -Replace the control unit that controls the malfunctioning component. NO -Go to step 10.
10. Check the switch and its ground (if applicable), then check for an open or a short in the wire between the switch and the control unit that monitors it. Is the switch and the wire harness OK? YES -Replace the control unit that monitors the switch. NO -Replace the switch, or repair/replace the wire harness.

Troubleshooting - B-CAN System Diagnosis Test Mode 1 and Test Mode 2 (without the HDS)

Special Tools Required

MPCS (MCIS) Service Connector 07WAZ-001010A

Test Mode 1

Check the PCM for DTCs and troubleshoot PCM (see GENERAL TROUBLESHOOTING INFORMATION ) or F-CAN loss of communication errors first, then do this diagnosis if the HDS is not available.

Scheme 11

1. Check the No. 1 (15 A) and the No. 22 (7.5 A) fuses in the under-dash fuse/relay box. Are the fuses OK? YES -Go to step 2. NO -Replace the fuses. If the fuse blows again, repair the short to ground on the fuse circuit(s).
2. Remove the fuse access panel (see «FUSE ACCESS PANEL REMOVAL/INSTALLATION»(ref-513196-S26940559112012110700000) ).
3. Turn the ignition switch to ON (II), and move the ceiling light switch to the middle (DOOR) position.
4. Connect the MPCS service connector (A) to the MICU service check connector socket (B) in the under-dash fuse/relay box.
5. Wait 5 seconds, and watch the ceiling light. When the ceiling light flash quickly once and then goes off, the system is in Test Mode 1.
6. Check for B-CAN DTCs indicated by the multi-information display on the gauge control module while still in Test Mode 1. Press the SEL/RESET button to display the next code. After you get to the last code, the display shows END. If no DTCs are stored, the display will read NO (see «HOW TO DISPLAY DTCS ON THE MID OF THE GAUGE CONTROL MODULE»(ref-513195-S33256994672012110700000) ). NOTE: If the test times out, remove the MPCS service connector, turn the ignition switch to LOCK (0), and repeat steps 3 and 4 . Are any DTCs indicated? YES -Go to step 7. NO -Go to step 11 .
7. Record all DTCs and sort them into these categories: Battery voltage DTCs Internal error DTCs Loss of communication DTCs Signal error DTCs
8. Troubleshoot the DTCs in the order listed above.
9. Clear the DTCs by pressing and holding the SEL/RESET button for at least 10 seconds.
10. You will hear a beep to confirm the codes have been cleared. Operate the devices that failed, and recheck for codes. Test Mode 2
11. Remove the MPCS service connector from the under-dash fuse/relay box MICU service check connector socket for 5-10 seconds, then re-insert it to enter Mode 2. When the system enters Mode 2, the ceiling light flash two times quickly and then goes off. NOTE: If the MPCS service connector is disconnected for too short or too long of a time, or if the ignition switch is turned to LOCK (0), the system returns to Test Mode 1.
12. The following table lists the circuits that can be checked in Test Mode 2. Operate the switch that is most closely related to the problem. If the circuit is OK, the ceiling light blink once. If the circuit is faulty, there is no indication. MICU Item Brake pedal position switch Driver's door switch Driver's rear door switch Trunk lid/Tailgate latch switch Driver's rear door lock knob switch (UNLOCK) Windshield wiper switch (LOW) Windshield wiper switch (HIGH) Windshield wiper switch (INT) Windshield wiper switch (MIST) Rear wiper switch Windshield washer switch Rear washer switch Wiper intermittent dwell time controller Turn signal switch (LEFT) Turn signal switch (RIGHT) Hazard warning switch Headlight switch (OFF) Headlight switch (PARKING) Headlight switch (HEADLIGHT) Headlight switch (High Beam) Headlight switch (PASSING) Trunk handle switch A/C pressure switch/Thermal protector Transmission range switch (P) Ignition key cylinder switch Security hood switch Back-up light switch Windshield wiper motor PARK switch Front passenger's door switch Passenger's rear door switch Passenger's rear door lock knob switch (UNLOCK) Audio unit or Audio-Navigation unit Driver's door lock switch (UNLOCK) Driver's door lock switch (LOCK) Driver's door lock knob switch (UNLOCK) Driver's door lock knob switch (LOCK) Driver's door key cylinder switch (UNLOCK) (1) Driver's door key cylinder switch (LOCK) (1) Front passenger's door lock knob switch (UNLOCK) (1) A second key is necessary to check the key cylinder inputs. Be sure to rotate the key cylinder switch two times to each position (lock and lock, unlock and unlock) to ensure the door lock knob switch is in the appropriate position. Does the ceiling light work properly in all switch positions? YES -Go to function and input test for the system related to the failure. NO -Repair the open, or short, or replace the faulty switch.
